9YGW | pdb_00009ygw

Perdeuterated E. coli YajL, 100K


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 0.88 Å
  • R-Value Free:
    0.125 (Depositor), 0.128 (DCC)
  • R-Value Work:
    0.113 (Depositor), 0.116 (DCC)
  • R-Value Observed:
    0.113 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Environmental Contributions to Proton Sharing in Protein Low-Barrier Hydrogen Bonds.

Lin, J.Gerlits, O.Kneller, D.W.Weiss, K.L.Coates, L.Clarke, J.L.Hix, M.A.Effah, S.Y.Kovalevsky, A.Walker, A.R.Wilson, M.A.

(2026) Biochemistry

  • DOI: https://doi.org/10.1021/acs.biochem.5c00762
  • Primary Citation of Related Structures:
    9YFR, 9YFS, 9YGW, 9YGX, 9YH8, 9YKF, 9YZV, 9YZW

  • PubMed Abstract:

    Hydrogen bonds (H-bonds) are central to biomolecular structure and dynamics. Although H-bonds are typically characterized by well-defined proton positions, proton delocalization has been proposed to play a role in facilitating enzyme catalysis and allostery in some systems. Experimentally locating protons is difficult, hampering the study of proton mobility in H-bonds. We used neutron crystallography, atomic resolution X-ray bond length analysis, and large quantum mechanics/molecular mechanics-Born-Oppenheimer molecular dynamics (QM/MM-BOMD) simulations to comprehensively characterize the shared proton/deuteron in a Glu-Asp low-barrier hydrogen bond (LBHB) in the bacterial protein YajL that is a conventional H-bond in the homologous disease-associated human protein DJ-1. X-ray bond length analysis of protiated and perdeuterated DJ-1 and YajL shows no significant effect of deuteron substitution on these carboxylic acid-carboxylate H-bonds but does reveal an effect at the active site glutamic acid near a cysteine thiolate. Residues in an H-bonded network that might favor LBHB formation in YajL were interrogated by the mutation of homologous residues in DJ-1. A distal DJ-1 substitution increases proton delocalization in the Glu-Asp H-bond, demonstrating that mutations within extended H-bond networks can modulate proton transfer barriers in carboxylic acid-carboxylate H-bonds. In addition, proton mobility in the H-bond is correlated with dimer-spanning motions in the QM/MM-BOMD simulations of YajL and DJ-1. Our results show that proton delocalization can be tuned using combined bioinformatic, structural, and computational information, opening the possibility of using engineered proton delocalization as a probe of H-bonding environments and as a tool to test hypotheses about LBHB function.


  • Organizational Affiliation
    • Department of Biochemistry, University of Nebraska, Lincoln, Nebraska 68588, United States.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Chaperone YajLA [auth B],
B [auth A]
199Escherichia coliMutation(s): 0
Gene Names: thiJACU57_11870AM266_04520ERS085365_02411ERS085416_01937ERS139211_01908ERS150873_01827PU15_11320PU38_04800SK85_00449
EC: 3.5.1 (UniProt), 3.1.2 (UniProt), 3.5.1.124 (UniProt)
UniProt
Find proteins for Q46948 (Escherichia coli (strain K12))
Explore Q46948
Go to UniProtKB:  Q46948
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ46948
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 0.88 Å
  • R-Value Free:  0.125 (Depositor), 0.128 (DCC)
  • R-Value Work:  0.113 (Depositor), 0.116 (DCC)
  • R-Value Observed: 0.113 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 43.727α = 90
b = 78.41β = 90
c = 99.51γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35GM153337

Revision History  (Full details and data files)

  • Version 1.0: 2025-11-26
    Type: Initial release
  • Version 1.1: 2026-02-18
    Changes: Database references
