8OIN

55S mammalian mitochondrial ribosome with mtRF1 and P-site tRNA

PDB DOI: https://doi.org/10.2210/pdb8OIN/pdb
EM Map EMD-16894: EMDB EMDataResource
NAKB: 8OIN

Classification: RIBOSOME
Organism(s): Sus scrofa, Homo sapiens
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2023-03-23 Released: 2023-06-14
Deposition Author(s): Saurer, M., Leibundgut, M., Scaiola, A., Schoenhut, T., Ban, N.
Funding Organization(s): Swiss National Science Foundation, European Molecular Biology Organization (EMBO)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.60 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 2.1 of the entry. See complete history.

Literature

Molecular basis of translation termination at noncanonical stop codons in human mitochondria.

Saurer, M., Leibundgut, M., Nadimpalli, H.P., Scaiola, A., Schonhut, T., Lee, R.G., Siira, S.J., Rackham, O., Dreos, R., Lenarcic, T., Kummer, E., Gatfield, D., Filipovska, A., Ban, N.

(2023) Science 380: 531-536

PubMed: 37141370 Search on PubMed
DOI: https://doi.org/10.1126/science.adf9890
Primary Citation of Related Structures:
8OIN, 8OIP, 8OIQ, 8OIR, 8OIS, 8OIT

PubMed Abstract:
The genetic code that specifies the identity of amino acids incorporated into proteins during protein synthesis is almost universally conserved. Mitochondrial genomes feature deviations from the standard genetic code, including the reassignment of two arginine codons to stop codons. The protein required for translation termination at these noncanonical stop codons to release the newly synthesized polypeptides is not currently known. In this study, we used gene editing and ribosomal profiling in combination with cryo-electron microscopy to establish that mitochondrial release factor 1 (mtRF1) detects noncanonical stop codons in human mitochondria by a previously unknown mechanism of codon recognition. We discovered that binding of mtRF1 to the decoding center of the ribosome stabilizes a highly unusual conformation in the messenger RNA in which the ribosomal RNA participates in specific recognition of the noncanonical stop codons.

Organizational Affiliation

Department of Biology, Institute of Molecular Biology and Biophysics, ETH Zürich, 8093 Zürich, Switzerland.

Macromolecule Content

Total Structure Weight: 3,212.94 kDa
Atom Count: 180,624
Modelled Residue Count: 17,833
Deposited Residue Count: 23,285
Unique protein chains: 83
Unique nucleic acid chains: 6

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L12	A [auth B1] B [auth B2] C [auth B3] D [auth B4] E [auth B5] A [auth B1], B [auth B2], C [auth B3], D [auth B4], E [auth B5], F [auth B6]	198	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1U6S6 (Sus scrofa) Explore A0A4X1U6S6 Go to UniProtKB: A0A4X1U6S6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1U6S6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
uL22m	J [auth BA]	210	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1TXR4 (Sus scrofa) Explore A0A4X1TXR4 Go to UniProtKB: A0A4X1TXR4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1TXR4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein L23, mitochondrial	K [auth BB]	150	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A480JJI1 (Sus scrofa) Explore A0A480JJI1 Go to UniProtKB: A0A480JJI1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A480JJI1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
uL24m	L [auth BC]	216	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RHJ1 (Sus scrofa) Explore F1RHJ1 Go to UniProtKB: F1RHJ1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RHJ1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 8
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L27	M [auth BD]	148	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1U0F6 (Sus scrofa) Explore A0A4X1U0F6 Go to UniProtKB: A0A4X1U0F6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1U0F6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 9
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L28	N [auth BE]	256	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A286ZTW8 (Sus scrofa) Explore A0A286ZTW8 Go to UniProtKB: A0A286ZTW8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A286ZTW8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 10
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L47	O [auth BF]	250	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1SGC7 (Sus scrofa) Explore F1SGC7 Go to UniProtKB: F1SGC7
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1SGC7
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 11
Molecule	Chains	Sequence Length	Organism	Details	Image
uL30m	P [auth BG]	161	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A8D1MIP3 (Sus scrofa) Explore A0A8D1MIP3 Go to UniProtKB: A0A8D1MIP3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A8D1MIP3
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 12
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L32	Q [auth BH]	207	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for I3LTC4 (Sus scrofa) Explore I3LTC4 Go to UniProtKB: I3LTC4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	I3LTC4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 13
Molecule	Chains	Sequence Length	Organism	Details	Image
bL33m	R [auth BI]	65	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1TLP9 (Sus scrofa) Explore A0A4X1TLP9 Go to UniProtKB: A0A4X1TLP9
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1TLP9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 14
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L34	S [auth BJ]	95	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1UFR4 (Sus scrofa) Explore A0A4X1UFR4 Go to UniProtKB: A0A4X1UFR4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1UFR4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 15
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L35	T [auth BK]	188	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1SVC5 (Sus scrofa) Explore F1SVC5 Go to UniProtKB: F1SVC5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1SVC5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 16
Molecule	Chains	Sequence Length	Organism	Details	Image
uL2m	U [auth BL]	306	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RRN2 (Sus scrofa) Explore F1RRN2 Go to UniProtKB: F1RRN2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RRN2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 17
Molecule	Chains	Sequence Length	Organism	Details	Image
ICT1	V [auth BM]	399	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A140UHW4 (Sus scrofa) Explore A0A140UHW4 Go to UniProtKB: A0A140UHW4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A140UHW4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 18
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L4	W [auth BN]	294	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287B9C4 (Sus scrofa) Explore A0A287B9C4 Go to UniProtKB: A0A287B9C4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287B9C4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 19
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L9	X [auth BO]	268	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for I3LR45 (Sus scrofa) Explore I3LR45 Go to UniProtKB: I3LR45
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	I3LR45
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 20
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L10	Y [auth BP]	257	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RWJ0 (Sus scrofa) Explore F1RWJ0 Go to UniProtKB: F1RWJ0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RWJ0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 21
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L11	Z [auth BQ]	192	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RU54 (Sus scrofa) Explore F1RU54 Go to UniProtKB: F1RU54
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RU54
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 22
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein L13, mitochondrial	AA [auth BR]	197	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for K7GP19 (Sus scrofa) Explore K7GP19 Go to UniProtKB: K7GP19
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	K7GP19
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 23
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L14	BA [auth BS]	325	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287BMZ6 (Sus scrofa) Explore A0A287BMZ6 Go to UniProtKB: A0A287BMZ6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287BMZ6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 24
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein L15, mitochondrial	CA [auth BT]	296	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A8D0HMG9 (Sus scrofa) Explore A0A8D0HMG9 Go to UniProtKB: A0A8D0HMG9
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A8D0HMG9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 25
Molecule	Chains	Sequence Length	Organism	Details	Image
uL16m	DA [auth BU]	251	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RI89 (Sus scrofa) Explore F1RI89 Go to UniProtKB: F1RI89
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RI89
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 26
Molecule	Chains	Sequence Length	Organism	Details	Image
bL17m	EA [auth BV]	169	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RMQ4 (Sus scrofa) Explore F1RMQ4 Go to UniProtKB: F1RMQ4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RMQ4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 27
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L18	FA [auth BW]	188	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1VX01 (Sus scrofa) Explore A0A4X1VX01 Go to UniProtKB: A0A4X1VX01
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1VX01
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 28
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein L19, mitochondrial	GA [auth BX]	303	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for I3LNJ0 (Sus scrofa) Explore I3LNJ0 Go to UniProtKB: I3LNJ0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	I3LNJ0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 29
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L20	HA [auth BY]	149	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A286ZU56 (Sus scrofa) Explore A0A286ZU56 Go to UniProtKB: A0A286ZU56
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A286ZU56
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 30
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L21	IA [auth BZ]	209	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RY70 (Sus scrofa) Explore F1RY70 Go to UniProtKB: F1RY70
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RY70
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 31
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein L52, mitochondrial	JA [auth Ba]	160	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1S9B7 (Sus scrofa) Explore F1S9B7 Go to UniProtKB: F1S9B7
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1S9B7
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 32
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L53	KA [auth Bb]	112	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A8D0LKT0 (Sus scrofa) Explore A0A8D0LKT0 Go to UniProtKB: A0A8D0LKT0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A8D0LKT0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 33
Molecule	Chains	Sequence Length	Organism	Details	Image
mL54	LA [auth Bc]	138	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for I3LN63 (Sus scrofa) Explore I3LN63 Go to UniProtKB: I3LN63
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	I3LN63
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 34
Molecule	Chains	Sequence Length	Organism	Details	Image
bL31m	MA [auth Bd]	126	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1ULI6 (Sus scrofa) Explore A0A4X1ULI6 Go to UniProtKB: A0A4X1ULI6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1ULI6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 35
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L57	NA [auth Be]	102	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287BP93 (Sus scrofa) Explore A0A287BP93 Go to UniProtKB: A0A287BP93
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287BP93
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 36
Molecule	Chains	Sequence Length	Organism	Details	Image
mL62 (ICT1)	OA [auth Bf]	205	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A286ZJR2 (Sus scrofa) Explore A0A286ZJR2 Go to UniProtKB: A0A286ZJR2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A286ZJR2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 37
Molecule	Chains	Sequence Length	Organism	Details	Image
mL64	PA [auth Bg]	222	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A286ZXA6 (Sus scrofa) Explore A0A286ZXA6 Go to UniProtKB: A0A286ZXA6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A286ZXA6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 38
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S18A	QA [auth Bh]	196	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RRH6 (Sus scrofa) Explore F1RRH6 Go to UniProtKB: F1RRH6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RRH6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 39
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein S30, mitochondrial	RA [auth Bi]	433	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A480QIM3 (Sus scrofa) Explore A0A480QIM3 Go to UniProtKB: A0A480QIM3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A480QIM3
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 40
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein L1, mitochondrial	SA [auth Bj]	304	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287AF82 (Sus scrofa) Explore A0A287AF82 Go to UniProtKB: A0A287AF82
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287AF82
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 41
Molecule	Chains	Sequence Length	Organism	Details	Image
Ribosomal protein	TA [auth Bl]	100	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287A731 (Sus scrofa) Explore A0A287A731 Go to UniProtKB: A0A287A731
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287A731
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 42
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L37	UA [auth Bm]	423	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287BIV6 (Sus scrofa) Explore A0A287BIV6 Go to UniProtKB: A0A287BIV6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287BIV6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 43
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L38	VA [auth Bn]	380	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RW03 (Sus scrofa) Explore F1RW03 Go to UniProtKB: F1RW03
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RW03
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 44
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L39	WA [auth Bo]	334	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1SHP6 (Sus scrofa) Explore F1SHP6 Go to UniProtKB: F1SHP6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1SHP6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 45
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L40	XA [auth Bp]	162	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A286ZP98 (Sus scrofa) Explore A0A286ZP98 Go to UniProtKB: A0A286ZP98
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A286ZP98
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 46
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L41	YA [auth Bq]	135	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A8D1F1K9 (Sus scrofa) Explore A0A8D1F1K9 Go to UniProtKB: A0A8D1F1K9
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A8D1F1K9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 47
Molecule	Chains	Sequence Length	Organism	Details	Image
mL42	ZA [auth Br]	142	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287BQA1 (Sus scrofa) Explore A0A287BQA1 Go to UniProtKB: A0A287BQA1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287BQA1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 48
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein L43, mitochondrial isoform X2	AB [auth Bs]	159	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1S8U4 (Sus scrofa) Explore F1S8U4 Go to UniProtKB: F1S8U4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1S8U4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 49
Molecule	Chains	Sequence Length	Organism	Details	Image
mL44	BB [auth Bt]	332	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1SR64 (Sus scrofa) Explore F1SR64 Go to UniProtKB: F1SR64
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1SR64
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 50
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L45	CB [auth Bu]	306	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for I3LGM5 (Sus scrofa) Explore I3LGM5 Go to UniProtKB: I3LGM5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	I3LGM5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 51
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L46	DB [auth Bv]	279	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1SRT0 (Sus scrofa) Explore F1SRT0 Go to UniProtKB: F1SRT0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1SRT0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 52
Molecule	Chains	Sequence Length	Organism	Details	Image
39S ribosomal protein L48, mitochondrial	EB [auth Bw]	269	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A480J9Z6 (Sus scrofa) Explore A0A480J9Z6 Go to UniProtKB: A0A480J9Z6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A480J9Z6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 53
Molecule	Chains	Sequence Length	Organism	Details	Image
Mrpl34	FB [auth Bx]	166	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A0R4J8D6 (Sus scrofa) Explore A0A0R4J8D6 Go to UniProtKB: A0A0R4J8D6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0R4J8D6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 54
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L50	GB [auth By]	198	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for I3L9H6 (Sus scrofa) Explore I3L9H6 Go to UniProtKB: I3L9H6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	I3L9H6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 55
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein L51	HB [auth Bz]	128	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A8D1P1C8 (Sus scrofa) Explore A0A8D1P1C8 Go to UniProtKB: A0A8D1P1C8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A8D1P1C8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 57
Molecule	Chains	Sequence Length	Organism	Details	Image
28S ribosomal protein S35, mitochondrial isoform 1	JB [auth AB]	366	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1SG95 (Sus scrofa) Explore F1SG95 Go to UniProtKB: F1SG95
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1SG95
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 58
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S24	KB [auth AC]	167	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287ANU4 (Sus scrofa) Explore A0A287ANU4 Go to UniProtKB: A0A287ANU4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287ANU4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 59
Molecule	Chains	Sequence Length	Organism	Details	Image
Aurora kinase A interacting protein 1	LB [auth AD]	199	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A8D2A802 (Sus scrofa) Explore A0A8D2A802 Go to UniProtKB: A0A8D2A802
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A8D2A802
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 60
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitoribosomal protein bs6m, mrps6	MB [auth AE]	124	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A5K1V0G5 (Sus scrofa) Explore A0A5K1V0G5 Go to UniProtKB: A0A5K1V0G5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A5K1V0G5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 61
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S7	NB [auth AF]	242	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A286ZJ25 (Sus scrofa) Explore A0A286ZJ25 Go to UniProtKB: A0A286ZJ25
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A286ZJ25
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 63
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S10	PB [auth AH]	200	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RUU2 (Sus scrofa) Explore F1RUU2 Go to UniProtKB: F1RUU2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RUU2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 65
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S12	RB [auth AJ]	139	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A0M3KL52 (Sus scrofa) Explore A0A0M3KL52 Go to UniProtKB: A0A0M3KL52
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0M3KL52
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 66
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S14	SB [auth AK]	128	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A0M3KL53 (Sus scrofa) Explore A0A0M3KL53 Go to UniProtKB: A0A0M3KL53
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0M3KL53
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 67
Molecule	Chains	Sequence Length	Organism	Details	Image
28S ribosomal protein S15, mitochondrial	TB [auth AL]	259	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287AKS1 (Sus scrofa) Explore A0A287AKS1 Go to UniProtKB: A0A287AKS1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287AKS1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 68
Molecule	Chains	Sequence Length	Organism	Details	Image
28S ribosomal protein S16, mitochondrial	UB [auth AM]	135	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A480JTD7 (Sus scrofa) Explore A0A480JTD7 Go to UniProtKB: A0A480JTD7
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A480JTD7
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 69
Molecule	Chains	Sequence Length	Organism	Details	Image
uS17m	VB [auth AN]	130	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A8D1UDM1 (Sus scrofa) Explore A0A8D1UDM1 Go to UniProtKB: A0A8D1UDM1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A8D1UDM1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 70
Molecule	Chains	Sequence Length	Organism	Details	Image
28S ribosomal protein S18b, mitochondrial	WB [auth AO]	258	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for Q767K8 (Sus scrofa) Explore Q767K8 Go to UniProtKB: Q767K8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q767K8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 71
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S18C	XB [auth AP]	143	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A0M3KL54 (Sus scrofa) Explore A0A0M3KL54 Go to UniProtKB: A0A0M3KL54
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0M3KL54
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 72
Molecule	Chains	Sequence Length	Organism	Details	Image
28S ribosomal protein S21, mitochondrial	YB [auth AQ]	87	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A286ZNB3 (Sus scrofa) Explore A0A286ZNB3 Go to UniProtKB: A0A286ZNB3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A286ZNB3
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 73
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S22	ZB [auth AR]	382	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287AQT5 (Sus scrofa) Explore A0A287AQT5 Go to UniProtKB: A0A287AQT5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287AQT5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 74
Molecule	Chains	Sequence Length	Organism	Details	Image
mS23	AC [auth AS]	190	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287AEW3 (Sus scrofa) Explore A0A287AEW3 Go to UniProtKB: A0A287AEW3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287AEW3
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 75
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S25	BC [auth AT]	173	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A0M3KL55 (Sus scrofa) Explore A0A0M3KL55 Go to UniProtKB: A0A0M3KL55
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0M3KL55
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 76
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S26	CC [auth AU]	205	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287AY01 (Sus scrofa) Explore A0A287AY01 Go to UniProtKB: A0A287AY01
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287AY01
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 77
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S27	DC [auth AV]	395	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A5G2R1I0 (Sus scrofa) Explore A0A5G2R1I0 Go to UniProtKB: A0A5G2R1I0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A5G2R1I0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 78
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitoribosomal protein ms28, mrps28	EC [auth AW]	188	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A0M3KL56 (Sus scrofa) Explore A0A0M3KL56 Go to UniProtKB: A0A0M3KL56
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0M3KL56
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 79
Molecule	Chains	Sequence Length	Organism	Details	Image
Death associated protein 3	FC [auth AX]	410	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A8D1XNL0 (Sus scrofa) Explore A0A8D1XNL0 Go to UniProtKB: A0A8D1XNL0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A8D1XNL0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 80
Molecule	Chains	Sequence Length	Organism	Details	Image
28S ribosomal protein S31, mitochondrial	GC [auth AY]	381	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1RME2 (Sus scrofa) Explore F1RME2 Go to UniProtKB: F1RME2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1RME2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 81
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S33	HC [auth AZ]	148	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1V2H3 (Sus scrofa) Explore A0A4X1V2H3 Go to UniProtKB: A0A4X1V2H3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1V2H3
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 82
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptide chain release factor 1, mitochondrial	IC [auth Aa]	474	Homo sapiens	Mutation(s): 0 Gene Names: MTRF1
UniProt & NIH Common Fund Data Resources
Find proteins for O75570 (Homo sapiens) Explore O75570 Go to UniProtKB: O75570
PHAROS: O75570 GTEx: ENSG00000120662
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O75570
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 83
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S2	JC [auth Ab]	289	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1S001 (Sus scrofa) Explore F1S001 Go to UniProtKB: F1S001
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1S001
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 84
Molecule	Chains	Sequence Length	Organism	Details	Image
Coiled-coil-helix-coiled-coil-helix domain containing 1	KC [auth Ac]	118	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A4X1SZV4 (Sus scrofa) Explore A0A4X1SZV4 Go to UniProtKB: A0A4X1SZV4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A4X1SZV4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 85
Molecule	Chains	Sequence Length	Organism	Details	Image
28S ribosomal protein S5, mitochondrial isoform X2	LC [auth Ad]	430	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for F1SU66 (Sus scrofa) Explore F1SU66 Go to UniProtKB: F1SU66
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F1SU66
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 86
Molecule	Chains	Sequence Length	Organism	Details	Image
mS39	MC [auth Ae]	692	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for K7GKS8 (Sus scrofa) Explore K7GKS8 Go to UniProtKB: K7GKS8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	K7GKS8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 87
Molecule	Chains	Sequence Length	Organism	Details	Image
uS9m	NC [auth Ag]	397	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for I3LU08 (Sus scrofa) Explore I3LU08 Go to UniProtKB: I3LU08
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	I3LU08
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 88
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S11	OC [auth Ai]	196	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A286ZJJ6 (Sus scrofa) Explore A0A286ZJJ6 Go to UniProtKB: A0A286ZJJ6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A286ZJJ6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 89
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitochondrial ribosomal protein S34	PC [auth Aj]	505	Sus scrofa	Mutation(s): 0
UniProt
Find proteins for A0A287AVS9 (Sus scrofa) Explore A0A287AVS9 Go to UniProtKB: A0A287AVS9
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A287AVS9
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Length	Organism	Image
E-site tRNA	G [auth B7]	3	Sus scrofa
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Length	Organism	Image
16S rRNA	H [auth B8]	1,571	Sus scrofa
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff) | 3D Structure

Entity ID: 4
Molecule	Chains	Length	Organism	Image
CP Phe-tRNA	I [auth B9]	73	Sus scrofa
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff) | 3D Structure

Entity ID: 56
Molecule	Chains	Length	Organism	Image
12S rRNA	IB [auth AA]	960	Sus scrofa
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff) | 3D Structure

Entity ID: 62
Molecule	Chains	Length	Organism	Image
P-site Met-tRNA(fMet)	OB [auth AG]	71	Homo sapiens
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence | 3D Structure

Entity ID: 64
Molecule	Chains	Length	Organism	Image
mRNA	QB [auth AI]	9	Homo sapiens
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 10 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ATP Query on ATP Download Ideal Coordinates CCD File SDF format, chain HR [auth AX] MOL2 format, chain HR [auth AX]	HR [auth AX]	ADENOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₃ P₃ ZKHQWZAMYRWXGA-KQYNXXCUSA-N		Interactions Focus chain HR [auth AX] Interactions & Density Focus chain HR [auth AX]
GDP Query on GDP Download Ideal Coordinates CCD File SDF format, chain JR [auth AX] MOL2 format, chain JR [auth AX]	JR [auth AX]	GUANOSINE-5'-DIPHOSPHATE C₁₀ H₁₅ N₅ O₁₁ P₂ QGWNDRXFNXRZMB-UUOKFMHZSA-N		Interactions Focus chain JR [auth AX] Interactions & Density Focus chain JR [auth AX]
SPM Query on SPM Download Ideal Coordinates CCD File SDF format, chain KQ [auth AA] MOL2 format, chain KQ [auth AA]	KQ [auth AA]	SPERMINE C₁₀ H₂₆ N₄ PFNFFQXMRSDOHW-UHFFFAOYSA-N		Interactions Focus chain KQ [auth AA] Interactions & Density Focus chain KQ [auth AA]
FME Query on FME Download Ideal Coordinates CCD File SDF format, chain AR [auth AG] MOL2 format, chain AR [auth AG]	AR [auth AG]	N-FORMYLMETHIONINE C₆ H₁₁ N O₃ S PYUSHNKNPOHWEZ-YFKPBYRVSA-N		Interactions Focus chain AR [auth AG] Interactions & Density Focus chain AR [auth AG]
FES Query on FES Download Ideal Coordinates CCD File SDF format, chain FR [auth AP] SDF format, chain GR [auth AT] SDF format, chain QL [auth Bh] MOL2 format, chain FR [auth AP] MOL2 format, chain GR [auth AT] MOL2 format, chain QL [auth Bh]	FR [auth AP], GR [auth AT], QL [auth Bh]	FE2/S2 (INORGANIC) CLUSTER Fe₂ S₂ NIXDOXVAJZFRNF-UHFFFAOYSA-N		Interactions Focus chain FR [auth AP] Focus chain GR [auth AT] Focus chain QL [auth Bh] Interactions & Density Focus chain FR [auth AP] Focus chain GR [auth AT] Focus chain QL [auth Bh]
PHE Query on PHE Download Ideal Coordinates CCD File SDF format, chain ZK [auth B9] MOL2 format, chain ZK [auth B9]	ZK [auth B9]	PHENYLALANINE C₉ H₁₁ N O₂ COLNVLDHVKWLRT-QMMMGPOBSA-N		Interactions Focus chain ZK [auth B9] Interactions & Density Focus chain ZK [auth B9]
SPD Query on SPD Download Ideal Coordinates CCD File SDF format, chain LQ [auth AA] MOL2 format, chain LQ [auth AA]	LQ [auth AA]	SPERMIDINE C₇ H₁₉ N₃ ATHGHQPFGPMSJY-UHFFFAOYSA-N		Interactions Focus chain LQ [auth AA] Interactions & Density Focus chain LQ [auth AA]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain BL [auth BH] SDF format, chain RL [auth Bl] SDF format, chain ER [auth AO] MOL2 format, chain BL [auth BH] MOL2 format, chain RL [auth Bl] MOL2 format, chain ER [auth AO]	BL [auth BH], ER [auth AO], RL [auth Bl]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain BL [auth BH] Focus chain ER [auth AO] Focus chain RL [auth Bl] Interactions & Density Focus chain BL [auth BH] Focus chain ER [auth AO] Focus chain RL [auth Bl]
K Query on K Download Ideal Coordinates CCD File SDF format, chain AK [auth B8] SDF format, chain BK [auth B8] SDF format, chain FK [auth B8] SDF format, chain HK [auth B8] SDF format, chain IK [auth B8] SDF format, chain IL [auth BU] SDF format, chain KK [auth B8] SDF format, chain LK [auth B8] SDF format, chain NQ [auth AA] SDF format, chain PK [auth B8] SDF format, chain QQ [auth AA] SDF format, chain RK [auth B8] SDF format, chain TQ [auth AA] SDF format, chain UL [auth Bz] SDF format, chain WJ [auth B8] SDF format, chain WQ [auth AA] SDF format, chain YJ [auth B8] SDF format, chain CK [auth B8] SDF format, chain CL [auth BL] SDF format, chain DK [auth B8] SDF format, chain EK [auth B8] SDF format, chain GK [auth B8] SDF format, chain JK [auth B8] SDF format, chain MK [auth B8] SDF format, chain ML [auth BW] SDF format, chain MQ [auth AA] SDF format, chain NK [auth B8] SDF format, chain OK [auth B8] SDF format, chain OQ [auth AA] SDF format, chain PL [auth Be] SDF format, chain PQ [auth AA] SDF format, chain QK [auth B8] SDF format, chain RQ [auth AA] SDF format, chain SK [auth B8] SDF format, chain SQ [auth AA] SDF format, chain TK [auth B8] SDF format, chain UQ [auth AA] SDF format, chain VJ [auth B8] SDF format, chain VQ [auth AA] SDF format, chain XJ [auth B8] SDF format, chain ZJ [auth B8] MOL2 format, chain AK [auth B8] MOL2 format, chain BK [auth B8] MOL2 format, chain FK [auth B8] MOL2 format, chain HK [auth B8] MOL2 format, chain IK [auth B8] MOL2 format, chain IL [auth BU] MOL2 format, chain KK [auth B8] MOL2 format, chain LK [auth B8] MOL2 format, chain NQ [auth AA] MOL2 format, chain PK [auth B8] MOL2 format, chain QQ [auth AA] MOL2 format, chain RK [auth B8] MOL2 format, chain TQ [auth AA] MOL2 format, chain UL [auth Bz] MOL2 format, chain WJ [auth B8] MOL2 format, chain WQ [auth AA] MOL2 format, chain YJ [auth B8] MOL2 format, chain CK [auth B8] MOL2 format, chain CL [auth BL] MOL2 format, chain DK [auth B8] MOL2 format, chain EK [auth B8] MOL2 format, chain GK [auth B8] MOL2 format, chain JK [auth B8] MOL2 format, chain MK [auth B8] MOL2 format, chain ML [auth BW] MOL2 format, chain MQ [auth AA] MOL2 format, chain NK [auth B8] MOL2 format, chain OK [auth B8] MOL2 format, chain OQ [auth AA] MOL2 format, chain PL [auth Be] MOL2 format, chain PQ [auth AA] MOL2 format, chain QK [auth B8] MOL2 format, chain RQ [auth AA] MOL2 format, chain SK [auth B8] MOL2 format, chain SQ [auth AA] MOL2 format, chain TK [auth B8] MOL2 format, chain UQ [auth AA] MOL2 format, chain VJ [auth B8] MOL2 format, chain VQ [auth AA] MOL2 format, chain XJ [auth B8] MOL2 format, chain ZJ [auth B8]	AK [auth B8] BK [auth B8] CK [auth B8] CL [auth BL] DK [auth B8] AK [auth B8], BK [auth B8], CK [auth B8], CL [auth BL], DK [auth B8], EK [auth B8], FK [auth B8], GK [auth B8], HK [auth B8], IK [auth B8], IL [auth BU], JK [auth B8], KK [auth B8], LK [auth B8], MK [auth B8], ML [auth BW], MQ [auth AA], NK [auth B8], NQ [auth AA], OK [auth B8], OQ [auth AA], PK [auth B8], PL [auth Be], PQ [auth AA], QK [auth B8], QQ [auth AA], RK [auth B8], RQ [auth AA], SK [auth B8], SQ [auth AA], TK [auth B8], TQ [auth AA], UL [auth Bz], UQ [auth AA], VJ [auth B8], VQ [auth AA], WJ [auth B8], WQ [auth AA], XJ [auth B8], YJ [auth B8], ZJ [auth B8]	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N		Interactions Focus chain AK [auth B8] Focus chain BK [auth B8] Focus chain CK [auth B8] Focus chain CL [auth BL] Focus chain DK [auth B8] Focus chain EK [auth B8] Focus chain FK [auth B8] Focus chain GK [auth B8] Focus chain HK [auth B8] Focus chain IK [auth B8] Focus chain IL [auth BU] Focus chain JK [auth B8] Focus chain KK [auth B8] Focus chain LK [auth B8] Focus chain MK [auth B8] Focus chain ML [auth BW] Focus chain MQ [auth AA] Focus chain NK [auth B8] Focus chain NQ [auth AA] Focus chain OK [auth B8] Focus chain OQ [auth AA] Focus chain PK [auth B8] Focus chain PL [auth Be] Focus chain PQ [auth AA] Focus chain QK [auth B8] Focus chain QQ [auth AA] Focus chain RK [auth B8] Focus chain RQ [auth AA] Focus chain SK [auth B8] Focus chain SQ [auth AA] Focus chain TK [auth B8] Focus chain TQ [auth AA] Focus chain UL [auth Bz] Focus chain UQ [auth AA] Focus chain VJ [auth B8] Focus chain VQ [auth AA] Focus chain WJ [auth B8] Focus chain WQ [auth AA] Focus chain XJ [auth B8] Focus chain YJ [auth B8] Focus chain ZJ [auth B8] Interactions & Density Focus chain AK [auth B8] Focus chain BK [auth B8] Focus chain CK [auth B8] Focus chain CL [auth BL] Focus chain DK [auth B8] Focus chain EK [auth B8] Focus chain FK [auth B8] Focus chain GK [auth B8] Focus chain HK [auth B8] Focus chain IK [auth B8] Focus chain IL [auth BU] Focus chain JK [auth B8] Focus chain KK [auth B8] Focus chain LK [auth B8] Focus chain MK [auth B8] Focus chain ML [auth BW] Focus chain MQ [auth AA] Focus chain NK [auth B8] Focus chain NQ [auth AA] Focus chain OK [auth B8] Focus chain OQ [auth AA] Focus chain PK [auth B8] Focus chain PL [auth Be] Focus chain PQ [auth AA] Focus chain QK [auth B8] Focus chain QQ [auth AA] Focus chain RK [auth B8] Focus chain RQ [auth AA] Focus chain SK [auth B8] Focus chain SQ [auth AA] Focus chain TK [auth B8] Focus chain TQ [auth AA] Focus chain UL [auth Bz] Focus chain UQ [auth AA] Focus chain VJ [auth B8] Focus chain VQ [auth AA] Focus chain WJ [auth B8] Focus chain WQ [auth AA] Focus chain XJ [auth B8] Focus chain YJ [auth B8] Focus chain ZJ [auth B8]
MG Query on MG Download Ideal Coordinates CCD File SDF format, chain AE [auth B8] SDF format, chain AF [auth B8] SDF format, chain AI [auth B8] SDF format, chain AJ [auth B8] SDF format, chain AM [auth AA] SDF format, chain AN [auth AA] SDF format, chain AO [auth AA] SDF format, chain AP [auth AA] SDF format, chain BD [auth B8] SDF format, chain BJ [auth B8] SDF format, chain BM [auth AA] SDF format, chain BP [auth AA] SDF format, chain BQ [auth AA] SDF format, chain CD [auth B8] SDF format, chain CF [auth B8] SDF format, chain CG [auth B8] SDF format, chain CI [auth B8] SDF format, chain CM [auth AA] SDF format, chain CN [auth AA] SDF format, chain CO [auth AA] SDF format, chain CP [auth AA] SDF format, chain CQ [auth AA] SDF format, chain DH [auth B8] SDF format, chain DJ [auth B8] SDF format, chain DL [auth BL] SDF format, chain DN [auth AA] SDF format, chain DO [auth AA] SDF format, chain DP [auth AA] SDF format, chain ED [auth B8] SDF format, chain EO [auth AA] SDF format, chain EP [auth AA] SDF format, chain EQ [auth AA] SDF format, chain FD [auth B8] SDF format, chain FF [auth B8] SDF format, chain FH [auth B8] SDF format, chain FI [auth B8] SDF format, chain FL [auth BM] SDF format, chain FP [auth AA] SDF format, chain FQ [auth AA] SDF format, chain GD [auth B8] SDF format, chain GF [auth B8] SDF format, chain GG [auth B8] SDF format, chain GI [auth B8] SDF format, chain GJ [auth B8] SDF format, chain GN [auth AA] SDF format, chain HF [auth B8] SDF format, chain HG [auth B8] SDF format, chain HI [auth B8] SDF format, chain HM [auth AA] SDF format, chain HN [auth AA] SDF format, chain HO [auth AA] SDF format, chain HP [auth AA] SDF format, chain IE [auth B8] SDF format, chain IF [auth B8] SDF format, chain II [auth B8] SDF format, chain IN [auth AA] SDF format, chain IO [auth AA] SDF format, chain IP [auth AA] SDF format, chain IQ [auth AA] SDF format, chain JF [auth B8] SDF format, chain JH [auth B8] SDF format, chain JI [auth B8] SDF format, chain JJ [auth B8] SDF format, chain JL [auth BV] SDF format, chain JM [auth AA] SDF format, chain JN [auth AA] SDF format, chain JQ [auth AA] SDF format, chain KD [auth B8] SDF format, chain KH [auth B8] SDF format, chain KN [auth AA] SDF format, chain KO [auth AA] SDF format, chain LD [auth B8] SDF format, chain LF [auth B8] SDF format, chain LG [auth B8] SDF format, chain LJ [auth B8] SDF format, chain LM [auth AA] SDF format, chain LO [auth AA] SDF format, chain LP [auth AA] SDF format, chain MD [auth B8] SDF format, chain MF [auth B8] SDF format, chain MI [auth B8] SDF format, chain MJ [auth B8] SDF format, chain MM [auth AA] SDF format, chain MO [auth AA] SDF format, chain MP [auth AA] SDF format, chain NE [auth B8] SDF format, chain NG [auth B8] SDF format, chain NL [auth BY] SDF format, chain NM [auth AA] SDF format, chain NP [auth AA] SDF format, chain OD [auth B8] SDF format, chain OE [auth B8] SDF format, chain OI [auth B8] SDF format, chain OJ [auth B8] SDF format, chain OM [auth AA] SDF format, chain OO [auth AA] SDF format, chain OP [auth AA] SDF format, chain PD [auth B8] SDF format, chain PE [auth B8] SDF format, chain PG [auth B8] SDF format, chain PH [auth B8] SDF format, chain PI [auth B8] SDF format, chain PM [auth AA] SDF format, chain QG [auth B8] SDF format, chain QH [auth B8] SDF format, chain QI [auth B8] SDF format, chain QO [auth AA] SDF format, chain RH [auth B8] SDF format, chain RI [auth B8] SDF format, chain RM [auth AA] SDF format, chain SC [auth B8] SDF format, chain SD [auth B8] SDF format, chain SE [auth B8] SDF format, chain SF [auth B8] SDF format, chain SG [auth B8] SDF format, chain SM [auth AA] SDF format, chain SP [auth AA] SDF format, chain TD [auth B8] SDF format, chain TE [auth B8] SDF format, chain TF [auth B8] SDF format, chain TH [auth B8] SDF format, chain TM [auth AA] SDF format, chain TN [auth AA] SDF format, chain UF [auth B8] SDF format, chain UG [auth B8] SDF format, chain UJ [auth B8] SDF format, chain UK [auth B8] SDF format, chain UN [auth AA] SDF format, chain VE [auth B8] SDF format, chain VH [auth B8] SDF format, chain VL [auth AA] SDF format, chain VM [auth AA] SDF format, chain VO [auth AA] SDF format, chain WC [auth B8] SDF format, chain WE [auth B8] SDF format, chain WG [auth B8] SDF format, chain WI [auth B8] SDF format, chain WL [auth AA] SDF format, chain XC [auth B8] SDF format, chain XE [auth B8] SDF format, chain XG [auth B8] SDF format, chain XH [auth B8] SDF format, chain XI [auth B8] SDF format, chain XL [auth AA] SDF format, chain YC [auth B8] SDF format, chain YD [auth B8] SDF format, chain YI [auth B8] SDF format, chain YM [auth AA] SDF format, chain YO [auth AA] SDF format, chain YP [auth AA] SDF format, chain ZC [auth B8] SDF format, chain ZD [auth B8] SDF format, chain ZE [auth B8] SDF format, chain ZF [auth B8] SDF format, chain ZI [auth B8] SDF format, chain ZM [auth AA] SDF format, chain ZN [auth AA] SDF format, chain ZP [auth AA] SDF format, chain AD [auth B8] SDF format, chain AG [auth B8] SDF format, chain AH [auth B8] SDF format, chain AL [auth B9] SDF format, chain AQ [auth AA] SDF format, chain BE [auth B8] SDF format, chain BF [auth B8] SDF format, chain BG [auth B8] SDF format, chain BH [auth B8] SDF format, chain BI [auth B8] SDF format, chain BN [auth AA] SDF format, chain BO [auth AA] SDF format, chain BR [auth AG] SDF format, chain CE [auth B8] SDF format, chain CH [auth B8] SDF format, chain CJ [auth B8] SDF format, chain CR [auth AI] SDF format, chain DD [auth B8] SDF format, chain DE [auth B8] SDF format, chain DF [auth B8] SDF format, chain DG [auth B8] SDF format, chain DI [auth B8] SDF format, chain DM [auth AA] SDF format, chain DQ [auth AA] SDF format, chain DR [auth AJ] SDF format, chain EE [auth B8] SDF format, chain EF [auth B8] SDF format, chain EG [auth B8] SDF format, chain EH [auth B8] SDF format, chain EI [auth B8] SDF format, chain EJ [auth B8] SDF format, chain EL [auth BL] SDF format, chain EM [auth AA] SDF format, chain EN [auth AA] SDF format, chain FE [auth B8] SDF format, chain FG [auth B8] SDF format, chain FJ [auth B8] SDF format, chain FM [auth AA] SDF format, chain FN [auth AA] SDF format, chain FO [auth AA] SDF format, chain GE [auth B8] SDF format, chain GH [auth B8] SDF format, chain GL [auth BM] SDF format, chain GM [auth AA] SDF format, chain GO [auth AA] SDF format, chain GP [auth AA] SDF format, chain GQ [auth AA] SDF format, chain HD [auth B8] SDF format, chain HE [auth B8] SDF format, chain HH [auth B8] SDF format, chain HJ [auth B8] SDF format, chain HL [auth BT] SDF format, chain HQ [auth AA] SDF format, chain ID [auth B8] SDF format, chain IG [auth B8] SDF format, chain IH [auth B8] SDF format, chain IJ [auth B8] SDF format, chain IM [auth AA] SDF format, chain IR [auth AX] SDF format, chain JD [auth B8] SDF format, chain JE [auth B8] SDF format, chain JG [auth B8] SDF format, chain JO [auth AA] SDF format, chain JP [auth AA] SDF format, chain KE [auth B8] SDF format, chain KF [auth B8] SDF format, chain KG [auth B8] SDF format, chain KI [auth B8] SDF format, chain KJ [auth B8] SDF format, chain KL [auth BV] SDF format, chain KM [auth AA] SDF format, chain KP [auth AA] SDF format, chain KR [auth Ab] SDF format, chain LE [auth B8] SDF format, chain LH [auth B8] SDF format, chain LI [auth B8] SDF format, chain LL [auth BV] SDF format, chain LN [auth AA] SDF format, chain ME [auth B8] SDF format, chain MG [auth B8] SDF format, chain MH [auth B8] SDF format, chain MN [auth AA] SDF format, chain ND [auth B8] SDF format, chain NF [auth B8] SDF format, chain NH [auth B8] SDF format, chain NI [auth B8] SDF format, chain NJ [auth B8] SDF format, chain NN [auth AA] SDF format, chain NO [auth AA] SDF format, chain OF [auth B8] SDF format, chain OG [auth B8] SDF format, chain OH [auth B8] SDF format, chain OL [auth Be] SDF format, chain ON [auth AA] SDF format, chain PF [auth B8] SDF format, chain PJ [auth B8] SDF format, chain PN [auth AA] SDF format, chain PO [auth AA] SDF format, chain PP [auth AA] SDF format, chain QC [auth B8] SDF format, chain QD [auth B8] SDF format, chain QE [auth B8] SDF format, chain QF [auth B8] SDF format, chain QJ [auth B8] SDF format, chain QM [auth AA] SDF format, chain QN [auth AA] SDF format, chain QP [auth AA] SDF format, chain RC [auth B8] SDF format, chain RD [auth B8] SDF format, chain RE [auth B8] SDF format, chain RF [auth B8] SDF format, chain RG [auth B8] SDF format, chain RJ [auth B8] SDF format, chain RN [auth AA] SDF format, chain RO [auth AA] SDF format, chain RP [auth AA] SDF format, chain SH [auth B8] SDF format, chain SI [auth B8] SDF format, chain SJ [auth B8] SDF format, chain SL [auth Bq] SDF format, chain SN [auth AA] SDF format, chain SO [auth AA] SDF format, chain TC [auth B8] SDF format, chain TG [auth B8] SDF format, chain TI [auth B8] SDF format, chain TJ [auth B8] SDF format, chain TL [auth Bx] SDF format, chain TO [auth AA] SDF format, chain TP [auth AA] SDF format, chain UC [auth B8] SDF format, chain UD [auth B8] SDF format, chain UE [auth B8] SDF format, chain UH [auth B8] SDF format, chain UI [auth B8] SDF format, chain UM [auth AA] SDF format, chain UO [auth AA] SDF format, chain UP [auth AA] SDF format, chain VC [auth B8] SDF format, chain VD [auth B8] SDF format, chain VF [auth B8] SDF format, chain VG [auth B8] SDF format, chain VI [auth B8] SDF format, chain VK [auth B8] SDF format, chain VN [auth AA] SDF format, chain VP [auth AA] SDF format, chain WD [auth B8] SDF format, chain WF [auth B8] SDF format, chain WH [auth B8] SDF format, chain WK [auth B8] SDF format, chain WM [auth AA] SDF format, chain WN [auth AA] SDF format, chain WO [auth AA] SDF format, chain WP [auth AA] SDF format, chain XD [auth B8] SDF format, chain XF [auth B8] SDF format, chain XK [auth B8] SDF format, chain XM [auth AA] SDF format, chain XN [auth AA] SDF format, chain XO [auth AA] SDF format, chain XP [auth AA] SDF format, chain XQ [auth AA] SDF format, chain YE [auth B8] SDF format, chain YF [auth B8] SDF format, chain YG [auth B8] SDF format, chain YH [auth B8] SDF format, chain YK [auth B8] SDF format, chain YL [auth AA] SDF format, chain YN [auth AA] SDF format, chain YQ [auth AA] SDF format, chain ZG [auth B8] SDF format, chain ZH [auth B8] SDF format, chain ZL [auth AA] SDF format, chain ZO [auth AA] SDF format, chain ZQ [auth AD] MOL2 format, chain AE [auth B8] MOL2 format, chain AF [auth B8] MOL2 format, chain AI [auth B8] MOL2 format, chain AJ [auth B8] MOL2 format, chain AM [auth AA] MOL2 format, chain AN [auth AA] MOL2 format, chain AO [auth AA] MOL2 format, chain AP [auth AA] MOL2 format, chain BD [auth B8] MOL2 format, chain BJ [auth B8] MOL2 format, chain BM [auth AA] MOL2 format, chain BP [auth AA] MOL2 format, chain BQ [auth AA] MOL2 format, chain CD [auth B8] MOL2 format, chain CF [auth B8] MOL2 format, chain CG [auth B8] MOL2 format, chain CI [auth B8] MOL2 format, chain CM [auth AA] MOL2 format, chain CN [auth AA] MOL2 format, chain CO [auth AA] MOL2 format, chain CP [auth AA] MOL2 format, chain CQ [auth AA] MOL2 format, chain DH [auth B8] MOL2 format, chain DJ [auth B8] MOL2 format, chain DL [auth BL] MOL2 format, chain DN [auth AA] MOL2 format, chain DO [auth AA] MOL2 format, chain DP [auth AA] MOL2 format, chain ED [auth B8] MOL2 format, chain EO [auth AA] MOL2 format, chain EP [auth AA] MOL2 format, chain EQ [auth AA] MOL2 format, chain FD [auth B8] MOL2 format, chain FF [auth B8] MOL2 format, chain FH [auth B8] MOL2 format, chain FI [auth B8] MOL2 format, chain FL [auth BM] MOL2 format, chain FP [auth AA] MOL2 format, chain FQ [auth AA] MOL2 format, chain GD [auth B8] MOL2 format, chain GF [auth B8] MOL2 format, chain GG [auth B8] MOL2 format, chain GI [auth B8] MOL2 format, chain GJ [auth B8] MOL2 format, chain GN [auth AA] MOL2 format, chain HF [auth B8] MOL2 format, chain HG [auth B8] MOL2 format, chain HI [auth B8] MOL2 format, chain HM [auth AA] MOL2 format, chain HN [auth AA] MOL2 format, chain HO [auth AA] MOL2 format, chain HP [auth AA] MOL2 format, chain IE [auth B8] MOL2 format, chain IF [auth B8] MOL2 format, chain II [auth B8] MOL2 format, chain IN [auth AA] MOL2 format, chain IO [auth AA] MOL2 format, chain IP [auth AA] MOL2 format, chain IQ [auth AA] MOL2 format, chain JF [auth B8] MOL2 format, chain JH [auth B8] MOL2 format, chain JI [auth B8] MOL2 format, chain JJ [auth B8] MOL2 format, chain JL [auth BV] MOL2 format, chain JM [auth AA] MOL2 format, chain JN [auth AA] MOL2 format, chain JQ [auth AA] MOL2 format, chain KD [auth B8] MOL2 format, chain KH [auth B8] MOL2 format, chain KN [auth AA] MOL2 format, chain KO [auth AA] MOL2 format, chain LD [auth B8] MOL2 format, chain LF [auth B8] MOL2 format, chain LG [auth B8] MOL2 format, chain LJ [auth B8] MOL2 format, chain LM [auth AA] MOL2 format, chain LO [auth AA] MOL2 format, chain LP [auth AA] MOL2 format, chain MD [auth B8] MOL2 format, chain MF [auth B8] MOL2 format, chain MI [auth B8] MOL2 format, chain MJ [auth B8] MOL2 format, chain MM [auth AA] MOL2 format, chain MO [auth AA] MOL2 format, chain MP [auth AA] MOL2 format, chain NE [auth B8] MOL2 format, chain NG [auth B8] MOL2 format, chain NL [auth BY] MOL2 format, chain NM [auth AA] MOL2 format, chain NP [auth AA] MOL2 format, chain OD [auth B8] MOL2 format, chain OE [auth B8] MOL2 format, chain OI [auth B8] MOL2 format, chain OJ [auth B8] MOL2 format, chain OM [auth AA] MOL2 format, chain OO [auth AA] MOL2 format, chain OP [auth AA] MOL2 format, chain PD [auth B8] MOL2 format, chain PE [auth B8] MOL2 format, chain PG [auth B8] MOL2 format, chain PH [auth B8] MOL2 format, chain PI [auth B8] MOL2 format, chain PM [auth AA] MOL2 format, chain QG [auth B8] MOL2 format, chain QH [auth B8] MOL2 format, chain QI [auth B8] MOL2 format, chain QO [auth AA] MOL2 format, chain RH [auth B8] MOL2 format, chain RI [auth B8] MOL2 format, chain RM [auth AA] MOL2 format, chain SC [auth B8] MOL2 format, chain SD [auth B8] MOL2 format, chain SE [auth B8] MOL2 format, chain SF [auth B8] MOL2 format, chain SG [auth B8] MOL2 format, chain SM [auth AA] MOL2 format, chain SP [auth AA] MOL2 format, chain TD [auth B8] MOL2 format, chain TE [auth B8] MOL2 format, chain TF [auth B8] MOL2 format, chain TH [auth B8] MOL2 format, chain TM [auth AA] MOL2 format, chain TN [auth AA] MOL2 format, chain UF [auth B8] MOL2 format, chain UG [auth B8] MOL2 format, chain UJ [auth B8] MOL2 format, chain UK [auth B8] MOL2 format, chain UN [auth AA] MOL2 format, chain VE [auth B8] MOL2 format, chain VH [auth B8] MOL2 format, chain VL [auth AA] MOL2 format, chain VM [auth AA] MOL2 format, chain VO [auth AA] MOL2 format, chain WC [auth B8] MOL2 format, chain WE [auth B8] MOL2 format, chain WG [auth B8] MOL2 format, chain WI [auth B8] MOL2 format, chain WL [auth AA] MOL2 format, chain XC [auth B8] MOL2 format, chain XE [auth B8] MOL2 format, chain XG [auth B8] MOL2 format, chain XH [auth B8] MOL2 format, chain XI [auth B8] MOL2 format, chain XL [auth AA] MOL2 format, chain YC [auth B8] MOL2 format, chain YD [auth B8] MOL2 format, chain YI [auth B8] MOL2 format, chain YM [auth AA] MOL2 format, chain YO [auth AA] MOL2 format, chain YP [auth AA] MOL2 format, chain ZC [auth B8] MOL2 format, chain ZD [auth B8] MOL2 format, chain ZE [auth B8] MOL2 format, chain ZF [auth B8] MOL2 format, chain ZI [auth B8] MOL2 format, chain ZM [auth AA] MOL2 format, chain ZN [auth AA] MOL2 format, chain ZP [auth AA] MOL2 format, chain AD [auth B8] MOL2 format, chain AG [auth B8] MOL2 format, chain AH [auth B8] MOL2 format, chain AL [auth B9] MOL2 format, chain AQ [auth AA] MOL2 format, chain BE [auth B8] MOL2 format, chain BF [auth B8] MOL2 format, chain BG [auth B8] MOL2 format, chain BH [auth B8] MOL2 format, chain BI [auth B8] MOL2 format, chain BN [auth AA] MOL2 format, chain BO [auth AA] MOL2 format, chain BR [auth AG] MOL2 format, chain CE [auth B8] MOL2 format, chain CH [auth B8] MOL2 format, chain CJ [auth B8] MOL2 format, chain CR [auth AI] MOL2 format, chain DD [auth B8] MOL2 format, chain DE [auth B8] MOL2 format, chain DF [auth B8] MOL2 format, chain DG [auth B8] MOL2 format, chain DI [auth B8] MOL2 format, chain DM [auth AA] MOL2 format, chain DQ [auth AA] MOL2 format, chain DR [auth AJ] MOL2 format, chain EE [auth B8] MOL2 format, chain EF [auth B8] MOL2 format, chain EG [auth B8] MOL2 format, chain EH [auth B8] MOL2 format, chain EI [auth B8] MOL2 format, chain EJ [auth B8] MOL2 format, chain EL [auth BL] MOL2 format, chain EM [auth AA] MOL2 format, chain EN [auth AA] MOL2 format, chain FE [auth B8] MOL2 format, chain FG [auth B8] MOL2 format, chain FJ [auth B8] MOL2 format, chain FM [auth AA] MOL2 format, chain FN [auth AA] MOL2 format, chain FO [auth AA] MOL2 format, chain GE [auth B8] MOL2 format, chain GH [auth B8] MOL2 format, chain GL [auth BM] MOL2 format, chain GM [auth AA] MOL2 format, chain GO [auth AA] MOL2 format, chain GP [auth AA] MOL2 format, chain GQ [auth AA] MOL2 format, chain HD [auth B8] MOL2 format, chain HE [auth B8] MOL2 format, chain HH [auth B8] MOL2 format, chain HJ [auth B8] MOL2 format, chain HL [auth BT] MOL2 format, chain HQ [auth AA] MOL2 format, chain ID [auth B8] MOL2 format, chain IG [auth B8] MOL2 format, chain IH [auth B8] MOL2 format, chain IJ [auth B8] MOL2 format, chain IM [auth AA] MOL2 format, chain IR [auth AX] MOL2 format, chain JD [auth B8] MOL2 format, chain JE [auth B8] MOL2 format, chain JG [auth B8] MOL2 format, chain JO [auth AA] MOL2 format, chain JP [auth AA] MOL2 format, chain KE [auth B8] MOL2 format, chain KF [auth B8] MOL2 format, chain KG [auth B8] MOL2 format, chain KI [auth B8] MOL2 format, chain KJ [auth B8] MOL2 format, chain KL [auth BV] MOL2 format, chain KM [auth AA] MOL2 format, chain KP [auth AA] MOL2 format, chain KR [auth Ab] MOL2 format, chain LE [auth B8] MOL2 format, chain LH [auth B8] MOL2 format, chain LI [auth B8] MOL2 format, chain LL [auth BV] MOL2 format, chain LN [auth AA] MOL2 format, chain ME [auth B8] MOL2 format, chain MG [auth B8] MOL2 format, chain MH [auth B8] MOL2 format, chain MN [auth AA] MOL2 format, chain ND [auth B8] MOL2 format, chain NF [auth B8] MOL2 format, chain NH [auth B8] MOL2 format, chain NI [auth B8] MOL2 format, chain NJ [auth B8] MOL2 format, chain NN [auth AA] MOL2 format, chain NO [auth AA] MOL2 format, chain OF [auth B8] MOL2 format, chain OG [auth B8] MOL2 format, chain OH [auth B8] MOL2 format, chain OL [auth Be] MOL2 format, chain ON [auth AA] MOL2 format, chain PF [auth B8] MOL2 format, chain PJ [auth B8] MOL2 format, chain PN [auth AA] MOL2 format, chain PO [auth AA] MOL2 format, chain PP [auth AA] MOL2 format, chain QC [auth B8] MOL2 format, chain QD [auth B8] MOL2 format, chain QE [auth B8] MOL2 format, chain QF [auth B8] MOL2 format, chain QJ [auth B8] MOL2 format, chain QM [auth AA] MOL2 format, chain QN [auth AA] MOL2 format, chain QP [auth AA] MOL2 format, chain RC [auth B8] MOL2 format, chain RD [auth B8] MOL2 format, chain RE [auth B8] MOL2 format, chain RF [auth B8] MOL2 format, chain RG [auth B8] MOL2 format, chain RJ [auth B8] MOL2 format, chain RN [auth AA] MOL2 format, chain RO [auth AA] MOL2 format, chain RP [auth AA] MOL2 format, chain SH [auth B8] MOL2 format, chain SI [auth B8] MOL2 format, chain SJ [auth B8] MOL2 format, chain SL [auth Bq] MOL2 format, chain SN [auth AA] MOL2 format, chain SO [auth AA] MOL2 format, chain TC [auth B8] MOL2 format, chain TG [auth B8] MOL2 format, chain TI [auth B8] MOL2 format, chain TJ [auth B8] MOL2 format, chain TL [auth Bx] MOL2 format, chain TO [auth AA] MOL2 format, chain TP [auth AA] MOL2 format, chain UC [auth B8] MOL2 format, chain UD [auth B8] MOL2 format, chain UE [auth B8] MOL2 format, chain UH [auth B8] MOL2 format, chain UI [auth B8] MOL2 format, chain UM [auth AA] MOL2 format, chain UO [auth AA] MOL2 format, chain UP [auth AA] MOL2 format, chain VC [auth B8] MOL2 format, chain VD [auth B8] MOL2 format, chain VF [auth B8] MOL2 format, chain VG [auth B8] MOL2 format, chain VI [auth B8] MOL2 format, chain VK [auth B8] MOL2 format, chain VN [auth AA] MOL2 format, chain VP [auth AA] MOL2 format, chain WD [auth B8] MOL2 format, chain WF [auth B8] MOL2 format, chain WH [auth B8] MOL2 format, chain WK [auth B8] MOL2 format, chain WM [auth AA] MOL2 format, chain WN [auth AA] MOL2 format, chain WO [auth AA] MOL2 format, chain WP [auth AA] MOL2 format, chain XD [auth B8] MOL2 format, chain XF [auth B8] MOL2 format, chain XK [auth B8] MOL2 format, chain XM [auth AA] MOL2 format, chain XN [auth AA] MOL2 format, chain XO [auth AA] MOL2 format, chain XP [auth AA] MOL2 format, chain XQ [auth AA] MOL2 format, chain YE [auth B8] MOL2 format, chain YF [auth B8] MOL2 format, chain YG [auth B8] MOL2 format, chain YH [auth B8] MOL2 format, chain YK [auth B8] MOL2 format, chain YL [auth AA] MOL2 format, chain YN [auth AA] MOL2 format, chain YQ [auth AA] MOL2 format, chain ZG [auth B8] MOL2 format, chain ZH [auth B8] MOL2 format, chain ZL [auth AA] MOL2 format, chain ZO [auth AA] MOL2 format, chain ZQ [auth AD]	AD [auth B8] AE [auth B8] AF [auth B8] AG [auth B8] AH [auth B8] AD [auth B8], AE [auth B8], AF [auth B8], AG [auth B8], AH [auth B8], AI [auth B8], AJ [auth B8], AL [auth B9], AM [auth AA], AN [auth AA], AO [auth AA], AP [auth AA], AQ [auth AA], BD [auth B8], BE [auth B8], BF [auth B8], BG [auth B8], BH [auth B8], BI [auth B8], BJ [auth B8], BM [auth AA], BN [auth AA], BO [auth AA], BP [auth AA], BQ [auth AA], BR [auth AG], CD [auth B8], CE [auth B8], CF [auth B8], CG [auth B8], CH [auth B8], CI [auth B8], CJ [auth B8], CM [auth AA], CN [auth AA], CO [auth AA], CP [auth AA], CQ [auth AA], CR [auth AI], DD [auth B8], DE [auth B8], DF [auth B8], DG [auth B8], DH [auth B8], DI [auth B8], DJ [auth B8], DL [auth BL], DM [auth AA], DN [auth AA], DO [auth AA], DP [auth AA], DQ [auth AA], DR [auth AJ], ED [auth B8], EE [auth B8], EF [auth B8], EG [auth B8], EH [auth B8], EI [auth B8], EJ [auth B8], EL [auth BL], EM [auth AA], EN [auth AA], EO [auth AA], EP [auth AA], EQ [auth AA], FD [auth B8], FE [auth B8], FF [auth B8], FG [auth B8], FH [auth B8], FI [auth B8], FJ [auth B8], FL [auth BM], FM [auth AA], FN [auth AA], FO [auth AA], FP [auth AA], FQ [auth AA], GD [auth B8], GE [auth B8], GF [auth B8], GG [auth B8], GH [auth B8], GI [auth B8], GJ [auth B8], GL [auth BM], GM [auth AA], GN [auth AA], GO [auth AA], GP [auth AA], GQ [auth AA], HD [auth B8], HE [auth B8], HF [auth B8], HG [auth B8], HH [auth B8], HI [auth B8], HJ [auth B8], HL [auth BT], HM [auth AA], HN [auth AA], HO [auth AA], HP [auth AA], HQ [auth AA], ID [auth B8], IE [auth B8], IF [auth B8], IG [auth B8], IH [auth B8], II [auth B8], IJ [auth B8], IM [auth AA], IN [auth AA], IO [auth AA], IP [auth AA], IQ [auth AA], IR [auth AX], JD [auth B8], JE [auth B8], JF [auth B8], JG [auth B8], JH [auth B8], JI [auth B8], JJ [auth B8], JL [auth BV], JM [auth AA], JN [auth AA], JO [auth AA], JP [auth AA], JQ [auth AA], KD [auth B8], KE [auth B8], KF [auth B8], KG [auth B8], KH [auth B8], KI [auth B8], KJ [auth B8], KL [auth BV], KM [auth AA], KN [auth AA], KO [auth AA], KP [auth AA], KR [auth Ab], LD [auth B8], LE [auth B8], LF [auth B8], LG [auth B8], LH [auth B8], LI [auth B8], LJ [auth B8], LL [auth BV], LM [auth AA], LN [auth AA], LO [auth AA], LP [auth AA], MD [auth B8], ME [auth B8], MF [auth B8], MG [auth B8], MH [auth B8], MI [auth B8], MJ [auth B8], MM [auth AA], MN [auth AA], MO [auth AA], MP [auth AA], ND [auth B8], NE [auth B8], NF [auth B8], NG [auth B8], NH [auth B8], NI [auth B8], NJ [auth B8], NL [auth BY], NM [auth AA], NN [auth AA], NO [auth AA], NP [auth AA], OD [auth B8], OE [auth B8], OF [auth B8], OG [auth B8], OH [auth B8], OI [auth B8], OJ [auth B8], OL [auth Be], OM [auth AA], ON [auth AA], OO [auth AA], OP [auth AA], PD [auth B8], PE [auth B8], PF [auth B8], PG [auth B8], PH [auth B8], PI [auth B8], PJ [auth B8], PM [auth AA], PN [auth AA], PO [auth AA], PP [auth AA], QC [auth B8], QD [auth B8], QE [auth B8], QF [auth B8], QG [auth B8], QH [auth B8], QI [auth B8], QJ [auth B8], QM [auth AA], QN [auth AA], QO [auth AA], QP [auth AA], RC [auth B8], RD [auth B8], RE [auth B8], RF [auth B8], RG [auth B8], RH [auth B8], RI [auth B8], RJ [auth B8], RM [auth AA], RN [auth AA], RO [auth AA], RP [auth AA], SC [auth B8], SD [auth B8], SE [auth B8], SF [auth B8], SG [auth B8], SH [auth B8], SI [auth B8], SJ [auth B8], SL [auth Bq], SM [auth AA], SN [auth AA], SO [auth AA], SP [auth AA], TC [auth B8], TD [auth B8], TE [auth B8], TF [auth B8], TG [auth B8], TH [auth B8], TI [auth B8], TJ [auth B8], TL [auth Bx], TM [auth AA], TN [auth AA], TO [auth AA], TP [auth AA], UC [auth B8], UD [auth B8], UE [auth B8], UF [auth B8], UG [auth B8], UH [auth B8], UI [auth B8], UJ [auth B8], UK [auth B8], UM [auth AA], UN [auth AA], UO [auth AA], UP [auth AA], VC [auth B8], VD [auth B8], VE [auth B8], VF [auth B8], VG [auth B8], VH [auth B8], VI [auth B8], VK [auth B8], VL [auth AA], VM [auth AA], VN [auth AA], VO [auth AA], VP [auth AA], WC [auth B8], WD [auth B8], WE [auth B8], WF [auth B8], WG [auth B8], WH [auth B8], WI [auth B8], WK [auth B8], WL [auth AA], WM [auth AA], WN [auth AA], WO [auth AA], WP [auth AA], XC [auth B8], XD [auth B8], XE [auth B8], XF [auth B8], XG [auth B8], XH [auth B8], XI [auth B8], XK [auth B8], XL [auth AA], XM [auth AA], XN [auth AA], XO [auth AA], XP [auth AA], XQ [auth AA], YC [auth B8], YD [auth B8], YE [auth B8], YF [auth B8], YG [auth B8], YH [auth B8], YI [auth B8], YK [auth B8], YL [auth AA], YM [auth AA], YN [auth AA], YO [auth AA], YP [auth AA], YQ [auth AA], ZC [auth B8], ZD [auth B8], ZE [auth B8], ZF [auth B8], ZG [auth B8], ZH [auth B8], ZI [auth B8], ZL [auth AA], ZM [auth AA], ZN [auth AA], ZO [auth AA], ZP [auth AA], ZQ [auth AD]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain AD [auth B8] Focus chain AE [auth B8] Focus chain AF [auth B8] Focus chain AG [auth B8] Focus chain AH [auth B8] Focus chain AI [auth B8] Focus chain AJ [auth B8] Focus chain AL [auth B9] Focus chain AM [auth AA] Focus chain AN [auth AA] Focus chain AO [auth AA] Focus chain AP [auth AA] Focus chain AQ [auth AA] Focus chain BD [auth B8] Focus chain BE [auth B8] Focus chain BF [auth B8] Focus chain BG [auth B8] Focus chain BH [auth B8] Focus chain BI [auth B8] Focus chain BJ [auth B8] Focus chain BM [auth AA] Focus chain BN [auth AA] Focus chain BO [auth AA] Focus chain BP [auth AA] Focus chain BQ [auth AA] Focus chain BR [auth AG] Focus chain CD [auth B8] Focus chain CE [auth B8] Focus chain CF [auth B8] Focus chain CG [auth B8] Focus chain CH [auth B8] Focus chain CI [auth B8] Focus chain CJ [auth B8] Focus chain CM [auth AA] Focus chain CN [auth AA] Focus chain CO [auth AA] Focus chain CP [auth AA] Focus chain CQ [auth AA] Focus chain CR [auth AI] Focus chain DD [auth B8] Focus chain DE [auth B8] Focus chain DF [auth B8] Focus chain DG [auth B8] Focus chain DH [auth B8] Focus chain DI [auth B8] Focus chain DJ [auth B8] Focus chain DL [auth BL] Focus chain DM [auth AA] Focus chain DN [auth AA] Focus chain DO [auth AA] Focus chain DP [auth AA] Focus chain DQ [auth AA] Focus chain DR [auth AJ] Focus chain ED [auth B8] Focus chain EE [auth B8] Focus chain EF [auth B8] Focus chain EG [auth B8] Focus chain EH [auth B8] Focus chain EI [auth B8] Focus chain EJ [auth B8] Focus chain EL [auth BL] Focus chain EM [auth AA] Focus chain EN [auth AA] Focus chain EO [auth AA] Focus chain EP [auth AA] Focus chain EQ [auth AA] Focus chain FD [auth B8] Focus chain FE [auth B8] Focus chain FF [auth B8] Focus chain FG [auth B8] Focus chain FH [auth B8] Focus chain FI [auth B8] Focus chain FJ [auth B8] Focus chain FL [auth BM] Focus chain FM [auth AA] Focus chain FN [auth AA] Focus chain FO [auth AA] Focus chain FP [auth AA] Focus chain FQ [auth AA] Focus chain GD [auth B8] Focus chain GE [auth B8] Focus chain GF [auth B8] Focus chain GG [auth B8] Focus chain GH [auth B8] Focus chain GI [auth B8] Focus chain GJ [auth B8] Focus chain GL [auth BM] Focus chain GM [auth AA] Focus chain GN [auth AA] Focus chain GO [auth AA] Focus chain GP [auth AA] Focus chain GQ [auth AA] Focus chain HD [auth B8] Focus chain HE [auth B8] Focus chain HF [auth B8] Focus chain HG [auth B8] Focus chain HH [auth B8] Focus chain HI [auth B8] Focus chain HJ [auth B8] Focus chain HL [auth BT] Focus chain HM [auth AA] Focus chain HN [auth AA] Focus chain HO [auth AA] Focus chain HP [auth AA] Focus chain HQ [auth AA] Focus chain ID [auth B8] Focus chain IE [auth B8] Focus chain IF [auth B8] Focus chain IG [auth B8] Focus chain IH [auth B8] Focus chain II [auth B8] Focus chain IJ [auth B8] Focus chain IM [auth AA] Focus chain IN [auth AA] Focus chain IO [auth AA] Focus chain IP [auth AA] Focus chain IQ [auth AA] Focus chain IR [auth AX] Focus chain JD [auth B8] Focus chain JE [auth B8] Focus chain JF [auth B8] Focus chain JG [auth B8] Focus chain JH [auth B8] Focus chain JI [auth B8] Focus chain JJ [auth B8] Focus chain JL [auth BV] Focus chain JM [auth AA] Focus chain JN [auth AA] Focus chain JO [auth AA] Focus chain JP [auth AA] Focus chain JQ [auth AA] Focus chain KD [auth B8] Focus chain KE [auth B8] Focus chain KF [auth B8] Focus chain KG [auth B8] Focus chain KH [auth B8] Focus chain KI [auth B8] Focus chain KJ [auth B8] Focus chain KL [auth BV] Focus chain KM [auth AA] Focus chain KN [auth AA] Focus chain KO [auth AA] Focus chain KP [auth AA] Focus chain KR [auth Ab] Focus chain LD [auth B8] Focus chain LE [auth B8] Focus chain LF [auth B8] Focus chain LG [auth B8] Focus chain LH [auth B8] Focus chain LI [auth B8] Focus chain LJ [auth B8] Focus chain LL [auth BV] Focus chain LM [auth AA] Focus chain LN [auth AA] Focus chain LO [auth AA] Focus chain LP [auth AA] Focus chain MD [auth B8] Focus chain ME [auth B8] Focus chain MF [auth B8] Focus chain MG [auth B8] Focus chain MH [auth B8] Focus chain MI [auth B8] Focus chain MJ [auth B8] Focus chain MM [auth AA] Focus chain MN [auth AA] Focus chain MO [auth AA] Focus chain MP [auth AA] Focus chain ND [auth B8] Focus chain NE [auth B8] Focus chain NF [auth B8] Focus chain NG [auth B8] Focus chain NH [auth B8] Focus chain NI [auth B8] Focus chain NJ [auth B8] Focus chain NL [auth BY] Focus chain NM [auth AA] Focus chain NN [auth AA] Focus chain NO [auth AA] Focus chain NP [auth AA] Focus chain OD [auth B8] Focus chain OE [auth B8] Focus chain OF [auth B8] Focus chain OG [auth B8] Focus chain OH [auth B8] Focus chain OI [auth B8] Focus chain OJ [auth B8] Focus chain OL [auth Be] Focus chain OM [auth AA] Focus chain ON [auth AA] Focus chain OO [auth AA] Focus chain OP [auth AA] Focus chain PD [auth B8] Focus chain PE [auth B8] Focus chain PF [auth B8] Focus chain PG [auth B8] Focus chain PH [auth B8] Focus chain PI [auth B8] Focus chain PJ [auth B8] Focus chain PM [auth AA] Focus chain PN [auth AA] Focus chain PO [auth AA] Focus chain PP [auth AA] Focus chain QC [auth B8] Focus chain QD [auth B8] Focus chain QE [auth B8] Focus chain QF [auth B8] Focus chain QG [auth B8] Focus chain QH [auth B8] Focus chain QI [auth B8] Focus chain QJ [auth B8] Focus chain QM [auth AA] Focus chain QN [auth AA] Focus chain QO [auth AA] Focus chain QP [auth AA] Focus chain RC [auth B8] Focus chain RD [auth B8] Focus chain RE [auth B8] Focus chain RF [auth B8] Focus chain RG [auth B8] Focus chain RH [auth B8] Focus chain RI [auth B8] Focus chain RJ [auth B8] Focus chain RM [auth AA] Focus chain RN [auth AA] Focus chain RO [auth AA] Focus chain RP [auth AA] Focus chain SC [auth B8] Focus chain SD [auth B8] Focus chain SE [auth B8] Focus chain SF [auth B8] Focus chain SG [auth B8] Focus chain SH [auth B8] Focus chain SI [auth B8] Focus chain SJ [auth B8] Focus chain SL [auth Bq] Focus chain SM [auth AA] Focus chain SN [auth AA] Focus chain SO [auth AA] Focus chain SP [auth AA] Focus chain TC [auth B8] Focus chain TD [auth B8] Focus chain TE [auth B8] Focus chain TF [auth B8] Focus chain TG [auth B8] Focus chain TH [auth B8] Focus chain TI [auth B8] Focus chain TJ [auth B8] Focus chain TL [auth Bx] Focus chain TM [auth AA] Focus chain TN [auth AA] Focus chain TO [auth AA] Focus chain TP [auth AA] Focus chain UC [auth B8] Focus chain UD [auth B8] Focus chain UE [auth B8] Focus chain UF [auth B8] Focus chain UG [auth B8] Focus chain UH [auth B8] Focus chain UI [auth B8] Focus chain UJ [auth B8] Focus chain UK [auth B8] Focus chain UM [auth AA] Focus chain UN [auth AA] Focus chain UO [auth AA] Focus chain UP [auth AA] Focus chain VC [auth B8] Focus chain VD [auth B8] Focus chain VE [auth B8] Focus chain VF [auth B8] Focus chain VG [auth B8] Focus chain VH [auth B8] Focus chain VI [auth B8] Focus chain VK [auth B8] Focus chain VL [auth AA] Focus chain VM [auth AA] Focus chain VN [auth AA] Focus chain VO [auth AA] Focus chain VP [auth AA] Focus chain WC [auth B8] Focus chain WD [auth B8] Focus chain WE [auth B8] Focus chain WF [auth B8] Focus chain WG [auth B8] Focus chain WH [auth B8] Focus chain WI [auth B8] Focus chain WK [auth B8] Focus chain WL [auth AA] Focus chain WM [auth AA] Focus chain WN [auth AA] Focus chain WO [auth AA] Focus chain WP [auth AA] Focus chain XC [auth B8] Focus chain XD [auth B8] Focus chain XE [auth B8] Focus chain XF [auth B8] Focus chain XG [auth B8] Focus chain XH [auth B8] Focus chain XI [auth B8] Focus chain XK [auth B8] Focus chain XL [auth AA] Focus chain XM [auth AA] Focus chain XN [auth AA] Focus chain XO [auth AA] Focus chain XP [auth AA] Focus chain XQ [auth AA] Focus chain YC [auth B8] Focus chain YD [auth B8] Focus chain YE [auth B8] Focus chain YF [auth B8] Focus chain YG [auth B8] Focus chain YH [auth B8] Focus chain YI [auth B8] Focus chain YK [auth B8] Focus chain YL [auth AA] Focus chain YM [auth AA] Focus chain YN [auth AA] Focus chain YO [auth AA] Focus chain YP [auth AA] Focus chain YQ [auth AA] Focus chain ZC [auth B8] Focus chain ZD [auth B8] Focus chain ZE [auth B8] Focus chain ZF [auth B8] Focus chain ZG [auth B8] Focus chain ZH [auth B8] Focus chain ZI [auth B8] Focus chain ZL [auth AA] Focus chain ZM [auth AA] Focus chain ZN [auth AA] Focus chain ZO [auth AA] Focus chain ZP [auth AA] Focus chain ZQ [auth AD] Interactions & Density Focus chain AD [auth B8] Focus chain AE [auth B8] Focus chain AF [auth B8] Focus chain AG [auth B8] Focus chain AH [auth B8] Focus chain AI [auth B8] Focus chain AJ [auth B8] Focus chain AL [auth B9] Focus chain AM [auth AA] Focus chain AN [auth AA] Focus chain AO [auth AA] Focus chain AP [auth AA] Focus chain AQ [auth AA] Focus chain BD [auth B8] Focus chain BE [auth B8] Focus chain BF [auth B8] Focus chain BG [auth B8] Focus chain BH [auth B8] Focus chain BI [auth B8] Focus chain BJ [auth B8] Focus chain BM [auth AA] Focus chain BN [auth AA] Focus chain BO [auth AA] Focus chain BP [auth AA] Focus chain BQ [auth AA] Focus chain BR [auth AG] Focus chain CD [auth B8] Focus chain CE [auth B8] Focus chain CF [auth B8] Focus chain CG [auth B8] Focus chain CH [auth B8] Focus chain CI [auth B8] Focus chain CJ [auth B8] Focus chain CM [auth AA] Focus chain CN [auth AA] Focus chain CO [auth AA] Focus chain CP [auth AA] Focus chain CQ [auth AA] Focus chain CR [auth AI] Focus chain DD [auth B8] Focus chain DE [auth B8] Focus chain DF [auth B8] Focus chain DG [auth B8] Focus chain DH [auth B8] Focus chain DI [auth B8] Focus chain DJ [auth B8] Focus chain DL [auth BL] Focus chain DM [auth AA] Focus chain DN [auth AA] Focus chain DO [auth AA] Focus chain DP [auth AA] Focus chain DQ [auth AA] Focus chain DR [auth AJ] Focus chain ED [auth B8] Focus chain EE [auth B8] Focus chain EF [auth B8] Focus chain EG [auth B8] Focus chain EH [auth B8] Focus chain EI [auth B8] Focus chain EJ [auth B8] Focus chain EL [auth BL] Focus chain EM [auth AA] Focus chain EN [auth AA] Focus chain EO [auth AA] Focus chain EP [auth AA] Focus chain EQ [auth AA] Focus chain FD [auth B8] Focus chain FE [auth B8] Focus chain FF [auth B8] Focus chain FG [auth B8] Focus chain FH [auth B8] Focus chain FI [auth B8] Focus chain FJ [auth B8] Focus chain FL [auth BM] Focus chain FM [auth AA] Focus chain FN [auth AA] Focus chain FO [auth AA] Focus chain FP [auth AA] Focus chain FQ [auth AA] Focus chain GD [auth B8] Focus chain GE [auth B8] Focus chain GF [auth B8] Focus chain GG [auth B8] Focus chain GH [auth B8] Focus chain GI [auth B8] Focus chain GJ [auth B8] Focus chain GL [auth BM] Focus chain GM [auth AA] Focus chain GN [auth AA] Focus chain GO [auth AA] Focus chain GP [auth AA] Focus chain GQ [auth AA] Focus chain HD [auth B8] Focus chain HE [auth B8] Focus chain HF [auth B8] Focus chain HG [auth B8] Focus chain HH [auth B8] Focus chain HI [auth B8] Focus chain HJ [auth B8] Focus chain HL [auth BT] Focus chain HM [auth AA] Focus chain HN [auth AA] Focus chain HO [auth AA] Focus chain HP [auth AA] Focus chain HQ [auth AA] Focus chain ID [auth B8] Focus chain IE [auth B8] Focus chain IF [auth B8] Focus chain IG [auth B8] Focus chain IH [auth B8] Focus chain II [auth B8] Focus chain IJ [auth B8] Focus chain IM [auth AA] Focus chain IN [auth AA] Focus chain IO [auth AA] Focus chain IP [auth AA] Focus chain IQ [auth AA] Focus chain IR [auth AX] Focus chain JD [auth B8] Focus chain JE [auth B8] Focus chain JF [auth B8] Focus chain JG [auth B8] Focus chain JH [auth B8] Focus chain JI [auth B8] Focus chain JJ [auth B8] Focus chain JL [auth BV] Focus chain JM [auth AA] Focus chain JN [auth AA] Focus chain JO [auth AA] Focus chain JP [auth AA] Focus chain JQ [auth AA] Focus chain KD [auth B8] Focus chain KE [auth B8] Focus chain KF [auth B8] Focus chain KG [auth B8] Focus chain KH [auth B8] Focus chain KI [auth B8] Focus chain KJ [auth B8] Focus chain KL [auth BV] Focus chain KM [auth AA] Focus chain KN [auth AA] Focus chain KO [auth AA] Focus chain KP [auth AA] Focus chain KR [auth Ab] Focus chain LD [auth B8] Focus chain LE [auth B8] Focus chain LF [auth B8] Focus chain LG [auth B8] Focus chain LH [auth B8] Focus chain LI [auth B8] Focus chain LJ [auth B8] Focus chain LL [auth BV] Focus chain LM [auth AA] Focus chain LN [auth AA] Focus chain LO [auth AA] Focus chain LP [auth AA] Focus chain MD [auth B8] Focus chain ME [auth B8] Focus chain MF [auth B8] Focus chain MG [auth B8] Focus chain MH [auth B8] Focus chain MI [auth B8] Focus chain MJ [auth B8] Focus chain MM [auth AA] Focus chain MN [auth AA] Focus chain MO [auth AA] Focus chain MP [auth AA] Focus chain ND [auth B8] Focus chain NE [auth B8] Focus chain NF [auth B8] Focus chain NG [auth B8] Focus chain NH [auth B8] Focus chain NI [auth B8] Focus chain NJ [auth B8] Focus chain NL [auth BY] Focus chain NM [auth AA] Focus chain NN [auth AA] Focus chain NO [auth AA] Focus chain NP [auth AA] Focus chain OD [auth B8] Focus chain OE [auth B8] Focus chain OF [auth B8] Focus chain OG [auth B8] Focus chain OH [auth B8] Focus chain OI [auth B8] Focus chain OJ [auth B8] Focus chain OL [auth Be] Focus chain OM [auth AA] Focus chain ON [auth AA] Focus chain OO [auth AA] Focus chain OP [auth AA] Focus chain PD [auth B8] Focus chain PE [auth B8] Focus chain PF [auth B8] Focus chain PG [auth B8] Focus chain PH [auth B8] Focus chain PI [auth B8] Focus chain PJ [auth B8] Focus chain PM [auth AA] Focus chain PN [auth AA] Focus chain PO [auth AA] Focus chain PP [auth AA] Focus chain QC [auth B8] Focus chain QD [auth B8] Focus chain QE [auth B8] Focus chain QF [auth B8] Focus chain QG [auth B8] Focus chain QH [auth B8] Focus chain QI [auth B8] Focus chain QJ [auth B8] Focus chain QM [auth AA] Focus chain QN [auth AA] Focus chain QO [auth AA] Focus chain QP [auth AA] Focus chain RC [auth B8] Focus chain RD [auth B8] Focus chain RE [auth B8] Focus chain RF [auth B8] Focus chain RG [auth B8] Focus chain RH [auth B8] Focus chain RI [auth B8] Focus chain RJ [auth B8] Focus chain RM [auth AA] Focus chain RN [auth AA] Focus chain RO [auth AA] Focus chain RP [auth AA] Focus chain SC [auth B8] Focus chain SD [auth B8] Focus chain SE [auth B8] Focus chain SF [auth B8] Focus chain SG [auth B8] Focus chain SH [auth B8] Focus chain SI [auth B8] Focus chain SJ [auth B8] Focus chain SL [auth Bq] Focus chain SM [auth AA] Focus chain SN [auth AA] Focus chain SO [auth AA] Focus chain SP [auth AA] Focus chain TC [auth B8] Focus chain TD [auth B8] Focus chain TE [auth B8] Focus chain TF [auth B8] Focus chain TG [auth B8] Focus chain TH [auth B8] Focus chain TI [auth B8] Focus chain TJ [auth B8] Focus chain TL [auth Bx] Focus chain TM [auth AA] Focus chain TN [auth AA] Focus chain TO [auth AA] Focus chain TP [auth AA] Focus chain UC [auth B8] Focus chain UD [auth B8] Focus chain UE [auth B8] Focus chain UF [auth B8] Focus chain UG [auth B8] Focus chain UH [auth B8] Focus chain UI [auth B8] Focus chain UJ [auth B8] Focus chain UK [auth B8] Focus chain UM [auth AA] Focus chain UN [auth AA] Focus chain UO [auth AA] Focus chain UP [auth AA] Focus chain VC [auth B8] Focus chain VD [auth B8] Focus chain VE [auth B8] Focus chain VF [auth B8] Focus chain VG [auth B8] Focus chain VH [auth B8] Focus chain VI [auth B8] Focus chain VK [auth B8] Focus chain VL [auth AA] Focus chain VM [auth AA] Focus chain VN [auth AA] Focus chain VO [auth AA] Focus chain VP [auth AA] Focus chain WC [auth B8] Focus chain WD [auth B8] Focus chain WE [auth B8] Focus chain WF [auth B8] Focus chain WG [auth B8] Focus chain WH [auth B8] Focus chain WI [auth B8] Focus chain WK [auth B8] Focus chain WL [auth AA] Focus chain WM [auth AA] Focus chain WN [auth AA] Focus chain WO [auth AA] Focus chain WP [auth AA] Focus chain XC [auth B8] Focus chain XD [auth B8] Focus chain XE [auth B8] Focus chain XF [auth B8] Focus chain XG [auth B8] Focus chain XH [auth B8] Focus chain XI [auth B8] Focus chain XK [auth B8] Focus chain XL [auth AA] Focus chain XM [auth AA] Focus chain XN [auth AA] Focus chain XO [auth AA] Focus chain XP [auth AA] Focus chain XQ [auth AA] Focus chain YC [auth B8] Focus chain YD [auth B8] Focus chain YE [auth B8] Focus chain YF [auth B8] Focus chain YG [auth B8] Focus chain YH [auth B8] Focus chain YI [auth B8] Focus chain YK [auth B8] Focus chain YL [auth AA] Focus chain YM [auth AA] Focus chain YN [auth AA] Focus chain YO [auth AA] Focus chain YP [auth AA] Focus chain YQ [auth AA] Focus chain ZC [auth B8] Focus chain ZD [auth B8] Focus chain ZE [auth B8] Focus chain ZF [auth B8] Focus chain ZG [auth B8] Focus chain ZH [auth B8] Focus chain ZI [auth B8] Focus chain ZL [auth AA] Focus chain ZM [auth AA] Focus chain ZN [auth AA] Focus chain ZO [auth AA] Focus chain ZP [auth AA] Focus chain ZQ [auth AD]

Modified Residues 3 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
AYA Query on AYA	K [auth BB]	L-PEPTIDE LINKING	C₅ H₉ N O₃		ALA
SAC Query on SAC	AA [auth BR]	L-PEPTIDE LINKING	C₅ H₉ N O₄		SER
THC Query on THC	AB [auth Bs]	L-PEPTIDE LINKING	C₆ H₁₁ N O₄		THR

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.60 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	4
MODEL REFINEMENT	PHENIX	1.20.1

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2023-06-14

Deposition Author(s):

Funding Organization	Location	Grant Number
Swiss National Science Foundation	Switzerland	179190
Swiss National Science Foundation	Switzerland	182341
European Molecular Biology Organization (EMBO)	European Union	1074-2019

Revision History (Full details and data files)

Version 1.0: 2023-06-14
Type: Initial release
Version 2.0: 2023-11-15
Changes: Atomic model, Data collection, Derived calculations, Refinement description
Version 2.1: 2024-04-24
Changes: Data collection, Structure summary

RCSB PDB Core Operations are funded by the National Science Foundation (DBI-1832184), the US Department of Energy (DE-SC0019749), and the National Cancer Institute, National Institute of Allergy and Infectious Diseases, and National Institute of General Medical Sciences of the National Institutes of Health under grant R01GM133198.

Prepare Data

Validate Data

Deposit Data

Help and Resources

8OIN

55S mammalian mitochondrial ribosome with mtRF1 and P-site tRNA

Molecular basis of translation termination at noncanonical stop codons in human mitochondria.

Entity ID: 1

UniProt

Entity Groups

Sequence Annotations

Entity ID: 5

UniProt

Entity Groups

Sequence Annotations

Entity ID: 6

UniProt

Entity Groups

Sequence Annotations

Entity ID: 7

UniProt

Entity Groups

Sequence Annotations

Entity ID: 8

UniProt

Entity Groups

Sequence Annotations

Entity ID: 9

UniProt

Entity Groups

Sequence Annotations

Entity ID: 10

UniProt

Entity Groups

Sequence Annotations

Entity ID: 11

UniProt

Entity Groups

Sequence Annotations

Entity ID: 12

UniProt

Entity Groups

Sequence Annotations

Entity ID: 13

UniProt

Entity Groups

Sequence Annotations

Entity ID: 14

UniProt

Entity Groups

Sequence Annotations

Entity ID: 15

UniProt

Entity Groups

Sequence Annotations

Entity ID: 16

UniProt

Entity Groups

Sequence Annotations

Entity ID: 17

UniProt

Entity Groups

Sequence Annotations

Entity ID: 18

UniProt

Entity Groups

Sequence Annotations

Entity ID: 19

UniProt

Entity Groups

Sequence Annotations

Entity ID: 20

UniProt

Entity Groups

Sequence Annotations

Entity ID: 21

UniProt

Entity Groups

Sequence Annotations

Entity ID: 22
