7ZUS

Crystal structure of ternary complex of Pol theta polymerase domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.26 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.201

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Discovery, Characterization, and Structure-Based Optimization of Small-Molecule In Vitro and In Vivo Probes for Human DNA Polymerase Theta.

Stockley, M.L.Ferdinand, A.Benedetti, G.Blencowe, P.Boyd, S.M.Calder, M.Charles, M.D.Edwardes, L.V.Ekwuru, T.Finch, H.Galbiati, A.Geo, L.Grande, D.Grinkevich, V.Holliday, N.D.Krajewski, W.W.MacDonald, E.Majithiya, J.B.McCarron, H.McWhirter, C.L.Patel, V.Pedder, C.Rajendra, E.Ranzani, M.Rigoreau, L.J.M.Robinson, H.M.R.Schaedler, T.Sirina, J.Smith, G.C.M.Swarbrick, M.E.Turnbull, A.P.Willis, S.Heald, R.A.

(2022) J Med Chem 65: 13879-13891

  • DOI: https://doi.org/10.1021/acs.jmedchem.2c01142
  • Primary Citation of Related Structures:
    7ZUS, 7ZX0, 7ZX1

  • PubMed Abstract:

    Human DNA polymerase theta (Polθ), which is essential for microhomology-mediated DNA double strand break repair, has been proposed as an attractive target for the treatment of BRCA deficient and other DNA repair pathway defective cancers. As previously reported, we recently identified the first selective small molecule Polθ in vitro probe, 22 (ART558), which recapitulates the phenotype of Polθ loss, and in vivo probe, 43 (ART812), which is efficacious in a model of PARP inhibitor resistant TNBC in vivo. Here we describe the discovery, biochemical and biophysical characterization of these probes including small molecule ligand co-crystal structures with Polθ. The crystallographic data provides a basis for understanding the unique mechanism of inhibition of these compounds which is dependent on stabilization of a "closed" enzyme conformation. Additionally, the structural biology platform provided a basis for rational optimization based primarily on reduced ligand conformational flexibility.


  • Organizational Affiliation

    Artios Pharma Ltd., B940, Babraham Research Campus, CambridgeCB22 3FH, U. K.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase thetaA [auth AAA],
B [auth BBB],
C [auth CCC]
726Homo sapiensMutation(s): 1
Gene Names: POLQPOLH
EC: 2.7.7.7
UniProt & NIH Common Fund Data Resources
Find proteins for O75417 (Homo sapiens)
Explore O75417
Go to UniProtKB:  O75417
PHAROS:  O75417
GTEx:  ENSG00000051341
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO75417
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(P*TP*TP*CP*CP*AP*AP*TP*GP*AP*CP*AP*GP*CP*CP*GP*C)-3')D [auth DDD],
F [auth FFF],
H [auth HHH]
16synthetic construct
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*CP*GP*GP*CP*TP*GP*TP*CP*AP*TP*TP*(DDG))-3')E [auth EEE],
G [auth GGG],
I [auth III]
13synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.26 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.201
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 288.81α = 90
b = 172.91β = 90.89
c = 58.75γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
xia2data reduction
xia2data scaling
PHASERphasing
Cootmodel building

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other private--

Revision History  (Full details and data files)

  • Version 1.0: 2022-10-12
    Type: Initial release
  • Version 1.1: 2022-10-19
    Changes: Database references
  • Version 1.2: 2022-11-09
    Changes: Database references
  • Version 1.3: 2024-01-31
    Changes: Data collection, Refinement description
