7PE9

cryo-EM structure of DEPTOR bound to human mTOR complex 2, DEPt-bound subset local refinement


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Regulation of human mTOR complexes by DEPTOR.

Walchli, M.Berneiser, K.Mangia, F.Imseng, S.Craigie, L.M.Stuttfeld, E.Hall, M.N.Maier, T.

(2021) Elife 10

  • DOI: https://doi.org/10.7554/eLife.70871
  • Primary Citation of Related Structures:
    7PE7, 7PE8, 7PE9, 7PEA, 7PEB, 7PEC, 7PED

  • PubMed Abstract:

    The vertebrate-specific DEP domain-containing mTOR interacting protein (DEPTOR), an oncoprotein or tumor suppressor, has important roles in metabolism, immunity, and cancer. It is the only protein that binds and regulates both complexes of mammalian target of rapamycin (mTOR), a central regulator of cell growth. Biochemical analysis and cryo-EM reconstructions of DEPTOR bound to human mTOR complex 1 (mTORC1) and mTORC2 reveal that both structured regions of DEPTOR, the PDZ domain and the DEP domain tandem (DEPt), are involved in mTOR interaction. The PDZ domain binds tightly with mildly activating effect, but then acts as an anchor for DEPt association that allosterically suppresses mTOR activation. The binding interfaces of the PDZ domain and DEPt also support further regulation by other signaling pathways. A separate, substrate-like mode of interaction for DEPTOR phosphorylation by mTOR complexes rationalizes inhibition of non-stimulated mTOR activity at higher DEPTOR concentrations. The multifaceted interplay between DEPTOR and mTOR provides a basis for understanding the divergent roles of DEPTOR in physiology and opens new routes for targeting the mTOR-DEPTOR interaction in disease.


  • Organizational Affiliation

    Biozentrum, University of Basel, Basel, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Serine/threonine-protein kinase mTOR2,571Homo sapiensMutation(s): 0
Gene Names: MTORFRAPFRAP1FRAP2RAFT1RAPT1
EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for P42345 (Homo sapiens)
Explore P42345
Go to UniProtKB:  P42345
PHAROS:  P42345
GTEx:  ENSG00000198793
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42345
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Target of rapamycin complex subunit LST8B [auth C]326Homo sapiensMutation(s): 0
Gene Names: MLST8GBLLST8
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BVC4 (Homo sapiens)
Explore Q9BVC4
Go to UniProtKB:  Q9BVC4
PHAROS:  Q9BVC4
GTEx:  ENSG00000167965
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BVC4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Rapamycin-insensitive companion of mTORC [auth E]1,708Homo sapiensMutation(s): 0
Gene Names: RICTORKIAA1999
UniProt & NIH Common Fund Data Resources
Find proteins for Q6R327 (Homo sapiens)
Explore Q6R327
Go to UniProtKB:  Q6R327
PHAROS:  Q6R327
GTEx:  ENSG00000164327
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6R327
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Target of rapamycin complex 2 subunit MAPKAP1D [auth G]522Homo sapiensMutation(s): 0
Gene Names: MAPKAP1MIP1SIN1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BPZ7 (Homo sapiens)
Explore Q9BPZ7
Go to UniProtKB:  Q9BPZ7
PHAROS:  Q9BPZ7
GTEx:  ENSG00000119487
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BPZ7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
DEP domain-containing mTOR-interacting proteinE [auth I]409Homo sapiensMutation(s): 2
Gene Names: DEPTORDEPDC6
UniProt & NIH Common Fund Data Resources
Find proteins for Q8TB45 (Homo sapiens)
Explore Q8TB45
Go to UniProtKB:  Q8TB45
PHAROS:  Q8TB45
GTEx:  ENSG00000155792
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8TB45
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.19-4092
RECONSTRUCTIONcryoSPARC3.2.0

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerland179323

Revision History  (Full details and data files)

  • Version 1.0: 2021-09-08
    Type: Initial release
  • Version 1.1: 2021-09-29
    Changes: Data collection, Database references
