8AIM

Ugi-2 SAUNG complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.202

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

A Multimodal Approach towards Genomic Identification of Protein Inhibitors of Uracil-DNA Glycosylase.

Muselmani, W.Kashif-Khan, N.Bagneris, C.Santangelo, R.Williams, M.A.Savva, R.

(2023) Viruses 15

  • DOI: https://doi.org/10.3390/v15061348
  • Primary Citation of Related Structures:
    8AIL, 8AIM, 8AIN

  • PubMed Abstract:

    DNA-mimicking proteins encoded by viruses can modulate processes such as innate cellular immunity. An example is Ung-family uracil-DNA glycosylase inhibition, which prevents Ung-mediated degradation via the stoichiometric protein blockade of the Ung DNA-binding cleft. This is significant where uracil-DNA is a key determinant in the replication and distribution of virus genomes. Unrelated protein folds support a common physicochemical spatial strategy for Ung inhibition, characterised by pronounced sequence plasticity within the diverse fold families. That, and the fact that relatively few template sequences are biochemically verified to encode Ung inhibitor proteins, presents a barrier to the straightforward identification of Ung inhibitors in genomic sequences. In this study, distant homologs of known Ung inhibitors were characterised via structural biology and structure prediction methods. A recombinant cellular survival assay and in vitro biochemical assay were used to screen distant variants and mutants to further explore tolerated sequence plasticity in motifs supporting Ung inhibition. The resulting validated sequence repertoire defines an expanded set of heuristic sequence and biophysical signatures shared by known Ung inhibitor proteins. A computational search of genome database sequences and the results of recombinant tests of selected output sequences obtained are presented here.


  • Organizational Affiliation

    Institute of Structural and Molecular Biology, Department of Biological Sciences, Birkbeck, University of London, Malet Street, London WC1E 7HX, UK.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Uracil-DNA glycosylase inhibitorA [auth B],
B [auth G]
89Bacillus phage vB_BpuM-BpSpMutation(s): 0
Gene Names: Bp8pS_259
UniProt
Find proteins for A0A141HSF0 (Bacillus phage vB_BpuM-BpSp)
Explore A0A141HSF0
Go to UniProtKB:  A0A141HSF0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A141HSF0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Uracil-DNA glycosylaseC [auth A],
D [auth E]
226Staphylococcus aureusMutation(s): 0
Gene Names:
EC: 3.2.2.27
UniProt
Find proteins for Q6GJ88 (Staphylococcus aureus (strain MRSA252))
Explore Q6GJ88
Go to UniProtKB:  Q6GJ88
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6GJ88
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.202
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 137.652α = 90
b = 142.816β = 90
c = 82.759γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Birkbeck CollegeUnited Kingdom--

Revision History  (Full details and data files)

  • Version 1.0: 2023-06-21
    Type: Initial release
  • Version 1.1: 2023-07-12
    Changes: Database references
  • Version 1.2: 2024-02-07
    Changes: Data collection, Refinement description
