8U23

A Highly Stable Variant of Corynactis Californica Green Fluorescent Protein, ccGFP 8


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.78 Å
  • R-Value Free: 0.185
  • R-Value Work: 0.165
  • R-Value Observed: 0.165

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Engineering highly stable variants of Corynactis californica green fluorescent proteins.

Hung, L.W.Terwilliger, T.C.Waldo, G.S.Nguyen, H.B.

(2024) Protein Sci 33: e4886-e4886

  • DOI: https://doi.org/10.1002/pro.4886
  • Primary Citation of Related Structures:
    8U20, 8U21, 8U22, 8U23, 8U24

  • PubMed Abstract:

    Fluorescent proteins (FPs) are versatile biomarkers that facilitate effective detection and tracking of macromolecules of interest in real time. Engineered FPs such as superfolder green fluorescent protein (sfGFP) and superfolder Cherry (sfCherry) have exceptional refolding capability capable of delivering fluorescent readout in harsh environments where most proteins lose their native functions. Our recent work on the development of a split FP from a species of strawberry anemone, Corynactis californica, delivered pairs of fragments with up to threefold faster complementation than split GFP. We present the biophysical, biochemical, and structural characteristics of five full-length variants derived from these split C. californica GFP (ccGFP). These ccGFP variants are more tolerant under chemical denaturation with up to 8 kcal/mol lower unfolding free energy than that of the sfGFP. It is likely that some of these ccGFP variants could be suitable as biomarkers under more adverse environments where sfGFP fails to survive. A structural analysis suggests explanations of the variations in stabilities among the ccGFP variants.


  • Organizational Affiliation

    Bioscience Division, MS M888, Los Alamos National Laboratory, Los Alamos, New Mexico, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Green Fluorescent Protein Variant #8, ccGFP 8
A, B, C, D, E
A, B, C, D, E, F, G, H
219Corynactis californicaMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
C12
Query on C12
A, B, C, D, E
A, B, C, D, E, F, G, H
L-PEPTIDE LINKINGC15 H18 N3 O4THR, TYR, GLY
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.78 Å
  • R-Value Free: 0.185
  • R-Value Work: 0.165
  • R-Value Observed: 0.165
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.753α = 90
b = 145.623β = 104.7
c = 106.959γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
SCALEPACKdata scaling
DENZOdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2024-01-31
    Type: Initial release
  • Version 1.1: 2024-02-07
    Changes: Database references
