8RQU

Structure of TEM1 beta-lactamase variant 70.a


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.220
  • R-Value Observed: 0.222

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Simultaneous enhancement of multiple functional properties using evolution-informed protein design.

Fram, B.Truebridge, I.Su, Y.Riesselman, A.J.Ingraham, J.B.Passera, A.Napier, E.Thadani, N.N.Lim, S.Roberts, K.Kaur, G.Stiffler, M.Marks, D.S.Bahl, C.D.Khan, A.R.Sander, C.Gauthier, N.P.

(2023) Biorxiv

  • DOI: https://doi.org/10.1101/2023.05.09.539914
  • Primary Citation of Related Structures:
    8RQU

  • PubMed Abstract:

    Designing optimized proteins is important for a range of practical applications. Protein design is a rapidly developing field that would benefit from approaches that enable many changes in the amino acid primary sequence, rather than a small number of mutations, while maintaining structure and enhancing function. Homologous protein sequences contain extensive information about various protein properties and activities that have emerged over billions of years of evolution. Evolutionary models of sequence co-variation, derived from a set of homologous sequences, have proven effective in a range of applications including structure determination and mutation effect prediction. In this work we apply one of these models (EVcouplings) to computationally design highly divergent variants of the model protein TEM-1 β-lactamase, and characterize these designs experimentally using multiple biochemical and biophysical assays. Nearly all designed variants were functional, including one with 84 mutations from the nearest natural homolog. Surprisingly, all functional designs had large increases in thermostability and most had a broadening of available substrates. These property enhancements occurred while maintaining a nearly identical structure to the wild type enzyme. Collectively, this work demonstrates that evolutionary models of sequence co-variation (1) are able to capture complex epistatic interactions that successfully guide large sequence departures from natural contexts, and (2) can be applied to generate functional diversity useful for many applications in protein design.


  • Organizational Affiliation

    Department of Systems Biology, Harvard Medical School, Boston, MA, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Beta-lactamase TEM-1
A, B
266Escherichia coliMutation(s): 0
Gene Names: TEM-1
EC: 3.5.2.6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download Ideal Coordinates CCD File
C [auth B]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.220
  • R-Value Observed: 0.222
  • Space Group: P 43
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 114.618α = 90
b = 114.618β = 90
c = 48.882γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Science Foundation IrelandIrelandSFI-20/FFP-A/8446

Revision History  (Full details and data files)

  • Version 1.0: 2024-02-14
    Type: Initial release
