8J3Y | pdb_00008j3y

Crystal structure of CBM6E E168Q in complex with oligosaccharides


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.28 Å
  • R-Value Free:
    0.168 (Depositor), 0.170 (DCC)
  • R-Value Work:
    0.149 (Depositor), 0.150 (DCC)
  • R-Value Observed:
    0.150 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Structural insights into curdlan degradation via a glycoside hydrolase containing a disruptive carbohydrate-binding module.

Lv, T.Feng, J.Jia, X.Wang, C.Li, F.Peng, H.Xiao, Y.Liu, L.He, C.

(2024) Biotechnol Biofuels Bioprod 17: 45-45

  • DOI: https://doi.org/10.1186/s13068-024-02494-5
  • Primary Citation of Related Structures:
    8J3X, 8J3Y

  • PubMed Abstract:

    Degradation via enzymatic processes for the production of valuable β-1,3-glucooligosaccharides (GOS) from curdlan has attracted considerable interest. CBM6E functions as a curdlan-specific β-1,3-endoglucanase, composed of a glycoside hydrolase family 128 (GH128) module and a carbohydrate-binding module (CBM) derived from family CBM6. Crystallographic analyses were conducted to comprehend the substrate specificity mechanism of CBM6E. This unveiled structures of both apo CBM6E and its GOS-complexed form. The GH128 and CBM6 modules constitute a cohesive unit, binding nine glucoside moieties within the catalytic groove in a singular helical conformation. By extending the substrate-binding groove, we engineered CBM6E variants with heightened hydrolytic activities, generating diverse GOS profiles from curdlan. Molecular docking, followed by mutation validation, unveiled the cooperative recognition of triple-helical β-1,3-glucan by the GH128 and CBM6 modules, along with the identification of a novel sugar-binding residue situated within the CBM6 module. Interestingly, supplementing the CBM6 module into curdlan gel disrupted the gel's network structure, enhancing the hydrolysis of curdlan by specific β-1,3-glucanases. This study offers new insights into the recognition mechanism of glycoside hydrolases toward triple-helical β-1,3-glucans, presenting an effective method to enhance endoglucanase activity and manipulate its product profile. Furthermore, it discovered a CBM module capable of disrupting the quaternary structures of curdlan, thereby boosting the hydrolytic activity of curdlan gel when co-incubated with β-1,3-glucanases. These findings hold relevance for developing future enzyme and CBM cocktails useful in GOS production from curdlan degradation.


  • Organizational Affiliation
    • School of Life Sciences and Anhui Key Laboratory of Modern Biomanufacturing, Anhui University, Hefei, Anhui, China.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative polysaccharide-binding protein
A, B
392Saccharophagus degradans 2-40Mutation(s): 1
Gene Names: cbm6ESde_1445
UniProt
Find proteins for Q21KS2 (Saccharophagus degradans (strain 2-40 / ATCC 43961 / DSM 17024))
Explore Q21KS2
Go to UniProtKB:  Q21KS2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ21KS2
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-glucopyranose-(1-3)-beta-D-glucopyranose-(1-3)-beta-D-glucopyranose-(1-3)-beta-D-glucopyranose-(1-3)-beta-D-glucopyranose
C
5N/A
Glycosylation Resources
GlyTouCan:  G03330ED
GlyCosmos:  G03330ED
Entity ID: 3
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-glucopyranose-(1-3)-beta-D-glucopyranose-(1-3)-beta-D-glucopyranose-(1-3)-beta-D-glucopyranose
D, E, F
4N/A
Glycosylation Resources
GlyTouCan:  G87841AX
GlyCosmos:  G87841AX
GlyGen:  G87841AX
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.28 Å
  • R-Value Free:  0.168 (Depositor), 0.170 (DCC)
  • R-Value Work:  0.149 (Depositor), 0.150 (DCC)
  • R-Value Observed: 0.150 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 63.479α = 90
b = 97.802β = 108.4
c = 72.421γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data scaling
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data

  • Released Date: 2024-04-24
  • Deposition Author(s): He, C., Li, F.

Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2024-04-24
    Type: Initial release
  • Version 1.1: 2024-10-23
    Changes: Structure summary
  • Version 1.2: 2024-11-06
    Changes: Database references
