7WT8 | pdb_00007wt8

SARS-CoV-2 Omicron variant spike in complex with Fab 9A8 (State 2)

PDB DOI: https://doi.org/10.2210/pdb7WT8/pdb
EM Map EMD-32771: EMDB EMDataResource

Classification: VIRAL PROTEIN/IMMUNE SYSTEM
Organism(s): Severe acute respiratory syndrome coronavirus 2, Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2022-02-04 Released: 2023-06-07
Deposition Author(s): Wang, X., Wang, L.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.60 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

A broader neutralizing antibody against all the current VOCs and VOIs targets unique epitope of SARS-CoV-2 RBD.

Liu, S., Jia, Z., Nie, J., Liang, Z., Xie, J., Wang, L., Zhang, L., Wang, X., Wang, Y., Huang, W.

(2022) Cell Discov 8: 81-81

PubMed: 35977939 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1038/s41421-022-00443-w
Primary Citation Related Structures:
7WT7, 7WT8, 7WT9

Organizational Affiliation

Division of HIV/AIDS and Sex-transmitted Virus Vaccines, Institute for Biological Product Control, National Institutes for Food and Drug Control (NIFDC), Beijing, China.

Macromolecule Content

Total Structure Weight: 487.11 kDa
Atom Count: 30,240
Modeled Residue Count: 3,752
Deposited Residue Count: 4,268
Unique protein chains: 3

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,270	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 38 Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2 Go to UniProtKB: P0DTC2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0DTC2
Glycosylation
Glycosylation Sites: 15	Glycosylation Focus chain A Focus chain B Focus chain C	Go to GlyGen: P0DTC2-1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
light chain of Fab 9A8	D, F [auth I]	107	Homo sapiens	Mutation(s): 0

Find similar proteins by:

| 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Heavy chain of Fab 9A8	E [auth H], G [auth J]	122	Homo sapiens	Mutation(s): 0

Oligosaccharides

Help

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	H [auth E], I [auth F], J [auth G], K, L, H [auth E], I [auth F], J [auth G], K, L, M, N, O, P, Q, R, S, T, U, V, W	2		N-Glycosylation	Interactions Focus chain H [auth E] Focus chain I [auth F] Focus chain J [auth G] Focus chain K Focus chain L Focus chain M Focus chain N Focus chain O Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain T Focus chain U Focus chain V Focus chain W Interactions & Density Focus chain H [auth E] Focus chain I [auth F] Focus chain J [auth G] Focus chain K Focus chain L Focus chain M Focus chain N Focus chain O Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain T Focus chain U Focus chain V Focus chain W
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain AA [auth A] SDF format, chain AB [auth C] SDF format, chain BA [auth A] SDF format, chain BB [auth C] SDF format, chain CA [auth A] SDF format, chain DA [auth A] SDF format, chain EA [auth A] SDF format, chain FA [auth A] SDF format, chain GA [auth B] SDF format, chain HA [auth B] SDF format, chain IA [auth B] SDF format, chain JA [auth B] SDF format, chain KA [auth B] SDF format, chain LA [auth B] SDF format, chain MA [auth B] SDF format, chain NA [auth B] SDF format, chain OA [auth B] SDF format, chain PA [auth B] SDF format, chain QA [auth B] SDF format, chain RA [auth C] SDF format, chain SA [auth C] SDF format, chain TA [auth C] SDF format, chain UA [auth C] SDF format, chain VA [auth C] SDF format, chain WA [auth C] SDF format, chain X [auth A] SDF format, chain XA [auth C] SDF format, chain Y [auth A] SDF format, chain YA [auth C] SDF format, chain Z [auth A] SDF format, chain ZA [auth C] MOL2 format, chain AA [auth A] MOL2 format, chain AB [auth C] MOL2 format, chain BA [auth A] MOL2 format, chain BB [auth C] MOL2 format, chain CA [auth A] MOL2 format, chain DA [auth A] MOL2 format, chain EA [auth A] MOL2 format, chain FA [auth A] MOL2 format, chain GA [auth B] MOL2 format, chain HA [auth B] MOL2 format, chain IA [auth B] MOL2 format, chain JA [auth B] MOL2 format, chain KA [auth B] MOL2 format, chain LA [auth B] MOL2 format, chain MA [auth B] MOL2 format, chain NA [auth B] MOL2 format, chain OA [auth B] MOL2 format, chain PA [auth B] MOL2 format, chain QA [auth B] MOL2 format, chain RA [auth C] MOL2 format, chain SA [auth C] MOL2 format, chain TA [auth C] MOL2 format, chain UA [auth C] MOL2 format, chain VA [auth C] MOL2 format, chain WA [auth C] MOL2 format, chain X [auth A] MOL2 format, chain XA [auth C] MOL2 format, chain Y [auth A] MOL2 format, chain YA [auth C] MOL2 format, chain Z [auth A] MOL2 format, chain ZA [auth C] mmCIF format, chain AA [auth A] mmCIF format, chain AB [auth C] mmCIF format, chain BA [auth A] mmCIF format, chain BB [auth C] mmCIF format, chain CA [auth A] mmCIF format, chain DA [auth A] mmCIF format, chain EA [auth A] mmCIF format, chain FA [auth A] mmCIF format, chain GA [auth B] mmCIF format, chain HA [auth B] mmCIF format, chain IA [auth B] mmCIF format, chain JA [auth B] mmCIF format, chain KA [auth B] mmCIF format, chain LA [auth B] mmCIF format, chain MA [auth B] mmCIF format, chain NA [auth B] mmCIF format, chain OA [auth B] mmCIF format, chain PA [auth B] mmCIF format, chain QA [auth B] mmCIF format, chain RA [auth C] mmCIF format, chain SA [auth C] mmCIF format, chain TA [auth C] mmCIF format, chain UA [auth C] mmCIF format, chain VA [auth C] mmCIF format, chain WA [auth C] mmCIF format, chain X [auth A] mmCIF format, chain XA [auth C] mmCIF format, chain Y [auth A] mmCIF format, chain YA [auth C] mmCIF format, chain Z [auth A] mmCIF format, chain ZA [auth C]	AA [auth A] AB [auth C] BA [auth A] BB [auth C] CA [auth A] AA [auth A], AB [auth C], BA [auth A], BB [auth C], CA [auth A], DA [auth A], EA [auth A], FA [auth A], GA [auth B], HA [auth B], IA [auth B], JA [auth B], KA [auth B], LA [auth B], MA [auth B], NA [auth B], OA [auth B], PA [auth B], QA [auth B], RA [auth C], SA [auth C], TA [auth C], UA [auth C], VA [auth C], WA [auth C], X [auth A], XA [auth C], Y [auth A], YA [auth C], Z [auth A], ZA [auth C]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth A] Focus chain AB [auth C] Focus chain BA [auth A] Focus chain BB [auth C] Focus chain CA [auth A] Focus chain DA [auth A] Focus chain EA [auth A] Focus chain FA [auth A] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain LA [auth B] Focus chain MA [auth B] Focus chain NA [auth B] Focus chain OA [auth B] Focus chain PA [auth B] Focus chain QA [auth B] Focus chain RA [auth C] Focus chain SA [auth C] Focus chain TA [auth C] Focus chain UA [auth C] Focus chain VA [auth C] Focus chain WA [auth C] Focus chain X [auth A] Focus chain XA [auth C] Focus chain Y [auth A] Focus chain YA [auth C] Focus chain Z [auth A] Focus chain ZA [auth C] Interactions & Density Focus chain AA [auth A] Focus chain AB [auth C] Focus chain BA [auth A] Focus chain BB [auth C] Focus chain CA [auth A] Focus chain DA [auth A] Focus chain EA [auth A] Focus chain FA [auth A] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain LA [auth B] Focus chain MA [auth B] Focus chain NA [auth B] Focus chain OA [auth B] Focus chain PA [auth B] Focus chain QA [auth B] Focus chain RA [auth C] Focus chain SA [auth C] Focus chain TA [auth C] Focus chain UA [auth C] Focus chain VA [auth C] Focus chain WA [auth C] Focus chain X [auth A] Focus chain XA [auth C] Focus chain Y [auth A] Focus chain YA [auth C] Focus chain Z [auth A] Focus chain ZA [auth C]
