7YU2

Structure of 6-aminohexanoate-oligomer hydrolase NylC, D122G/H130Y/T267C mutant, hydroxylamine-treated

  • Classification: HYDROLASE
  • Organism(s): Arthrobacter
  • Expression System: Escherichia coli
  • Mutation(s): Yes

  • Deposited: 2022-08-16 Released: 2023-03-29
  • Deposition Author(s): Negoro, S., Higuchi, Y.
  • Funding Organization(s): Ministry of Education, Culture, Sports, Science and Technology (Japan)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.21 Å
  • R-Value Free: 0.143
  • R-Value Work: 0.116

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

X-ray crystallographic and mutational analysis of the NylC precursor: catalytic mechanism of autocleavage and substrate hydrolysis of nylon hydrolase.

Negoro, S.Shibata, N.Kato, D.I.Tanaka, Y.Yasuhira, K.Nagai, K.Oshima, S.Furuno, Y.Yokoyama, R.Miyazaki, K.Takeo, M.Hengphasatporn, K.Shigeta, Y.Lee, Y.H.Higuchi, Y.

(2023) FEBS J 290: 3400-3421

  • DOI: https://doi.org/10.1111/febs.16755
  • Primary Citation of Related Structures:
    7YU0, 7YU1, 7YU2

  • PubMed Abstract:

    Nylon hydrolase (NylC), a member of the N-terminal nucleophile (Ntn) hydrolase superfamily, is responsible for the degradation of various aliphatic nylons, including nylon-6 and nylon-66. NylC is initially expressed as an inactive precursor (36 kDa), but the precursor is autocatalytically cleaved at Asn266/Thr267 to generate an active enzyme composed of 27 and 9 kDa subunits. We isolated various mutants with amino acid changes at the catalytic centre. X-ray crystallographic analysis revealed that the NylC precursor forms a doughnut-shaped quaternary structure composed of four monomers (molecules A-D) with D2 symmetry. Catalytic residues in the precursor are covered by loop regions at the A/B interface (equivalent to the C/D interface). However, the catalytic residues are exposed to the solvent environment through autocleavage followed by movements of the loop regions. T267A, D306A and D308A mutations resulted in a complete loss of autocleavage. By contrast, in the T267S mutant, autocleavage proceeded slowly at a constant reaction rate (k = 2.8 × 10 -5  s -1 ) until complete conversion, but the reaction was inhibited by K189A and N219A mutations. Based on the crystallographic and molecular dynamic simulation analyses, we concluded that the Asp308-Asp306-Thr267 triad, resembling the Glu-Ser-Ser triad conserved in Ntn-hydrolase family enzymes, is responsible for autocleavage and that hydrogen-bonding networks connecting Thr267 with Lys189 and Asn219 are required for increasing the nucleophilicity of Thr267-OH in both the water accessible and water inaccessible systems. Furthermore, we determined that NylC employs the Asp308-Asp306-Thr267 triad as catalytic residues for substrate hydrolysis, but the reaction requires Lys189 and Tyr146 as additional catalytic/substrate-binding residues specific for nylon hydrolysis.


  • Organizational Affiliation

    Department of Applied Chemistry, Graduate School of Engineering, University of Hyogo, Himeji, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
6-aminohexanoate-oligomer endohydrolase
A, B
355ArthrobacterMutation(s): 3
Gene Names: nylC
EC: 3.5.1.117
UniProt
Find proteins for Q79F77 (Paenarthrobacter ureafaciens)
Explore Q79F77
Go to UniProtKB:  Q79F77
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ79F77
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
H [auth A],
I [auth A],
M [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
C [auth A]
D [auth A]
E [auth A]
F [auth A]
G [auth A]
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
J [auth B],
K [auth B],
L [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.21 Å
  • R-Value Free: 0.143
  • R-Value Work: 0.116
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.27α = 90
b = 144.022β = 90
c = 128.262γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Education, Culture, Sports, Science and Technology (Japan)Japan26289317

Revision History  (Full details and data files)

  • Version 1.0: 2023-03-29
    Type: Initial release
  • Version 1.1: 2023-07-19
    Changes: Data collection, Database references, Structure summary
  • Version 1.2: 2023-11-29
    Changes: Data collection, Refinement description
