7UKG

Human Kv4.2-KChIP2-DPP6 channel complex in an open state, transmembrane region


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.24 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Activation and closed-state inactivation mechanisms of the human voltage-gated K V 4 channel complexes.

Ye, W.Zhao, H.Dai, Y.Wang, Y.Lo, Y.H.Jan, L.Y.Lee, C.H.

(2022) Mol Cell 82: 2427

  • DOI: 10.1016/j.molcel.2022.04.032
  • Primary Citation of Related Structures:
    7UK5, 7UKC, 7UKD, 7UKE, 7UKF, 7UKG, 7UKH

  • PubMed Abstract:
  • The voltage-gated ion channel activity depends on both activation (transition from the resting state to the open state) and inactivation. Inactivation is a self-restraint mechanism to limit ion conduction and is as crucial to membrane excitability as activation ...

    The voltage-gated ion channel activity depends on both activation (transition from the resting state to the open state) and inactivation. Inactivation is a self-restraint mechanism to limit ion conduction and is as crucial to membrane excitability as activation. Inactivation can occur when the channel is open or closed. Although open-state inactivation is well understood, the molecular basis of closed-state inactivation has remained elusive. We report cryo-EM structures of human K V 4.2 channel complexes in inactivated, open, and closed states. Closed-state inactivation of K V 4 involves an unprecedented symmetry breakdown for pore closure by only two of the four S4-S5 linkers, distinct from known mechanisms of open-state inactivation. We further capture K V 4 in a putative resting state, revealing how voltage sensor movements control the pore. Moreover, our structures provide insights regarding channel modulation by KChIP2 and DPP6 auxiliary subunits. Our findings elucidate mechanisms of closed-state inactivation and voltage-dependent activation of the K V 4 channel.


    Organizational Affiliation

    Department of Structural Biology, St. Jude Children's Research Hospital, Memphis, TN 38105, USA. Electronic address: chiahsueh.lee@stjude.org.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Potassium voltage-gated channel subfamily D member 2A, B, C, D524Homo sapiensMutation(s): 0
Gene Names: KCND2KIAA1044
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NZV8 (Homo sapiens)
Explore Q9NZV8
Go to UniProtKB:  Q9NZV8
PHAROS:  Q9NZV8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NZV8
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Dipeptidyl-peptidase 6E [auth I],
F [auth J],
G [auth K],
H [auth L]
801Homo sapiensMutation(s): 0
Gene Names: DPP6
Membrane Entity: Yes
UniProt
Find proteins for A7E2E4 (Homo sapiens)
Explore A7E2E4
Go to UniProtKB:  A7E2E4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA7E2E4
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.24 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM143282

Revision History  (Full details and data files)

  • Version 1.0: 2022-06-29
    Type: Initial release
  • Version 1.1: 2022-07-20
    Changes: Database references
