7BH1

Cryo-EM Structure of KdpFABC in E1 state with K


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.38 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structural basis for potassium transport in prokaryotes by KdpFABC.

Sweet, M.E.Larsen, C.Zhang, X.Schlame, M.Pedersen, B.P.Stokes, D.L.

(2021) Proc Natl Acad Sci U S A 118

  • DOI: https://doi.org/10.1073/pnas.2105195118
  • Primary Citation of Related Structures:
    7BGY, 7BH1, 7BH2, 7LC3, 7LC6

  • PubMed Abstract:

    KdpFABC is an oligomeric K + transport complex in prokaryotes that maintains ionic homeostasis under stress conditions. The complex comprises a channel-like subunit (KdpA) from the superfamily of K + transporters and a pump-like subunit (KdpB) from the superfamily of P-type ATPases. Recent structural work has defined the architecture and generated contradictory hypotheses for the transport mechanism. Here, we use substrate analogs to stabilize four key intermediates in the reaction cycle and determine the corresponding structures by cryogenic electron microscopy. We find that KdpB undergoes conformational changes consistent with other representatives from the P-type superfamily, whereas KdpA, KdpC, and KdpF remain static. We observe a series of spherical densities that we assign as K + or water and which define a pathway for K + transport. This pathway runs through an intramembrane tunnel in KdpA and delivers ions to sites in the membrane domain of KdpB. Our structures suggest a mechanism where ATP hydrolysis is coupled to K + transfer between alternative sites in KdpB, ultimately reaching a low-affinity site where a water-filled pathway allows release of K + to the cytoplasm.


  • Organizational Affiliation

    Skirball Institute of Biomolecular Medicine, Department of Cell Biology, New York University Grossman School of Medicine, New York, NY 10016.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Potassium-transporting ATPase potassium-binding subunit557Escherichia coli K-12Mutation(s): 1
Gene Names: kdpAb0698JW0686
Membrane Entity: Yes
UniProt
Find proteins for P03959 (Escherichia coli (strain K12))
Explore P03959
Go to UniProtKB:  P03959
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03959
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Potassium-transporting ATPase ATP-binding subunit682Escherichia coli K-12Mutation(s): 1
Gene Names: kdpBb0697JW0685
EC: 7.2.2.6
Membrane Entity: Yes
UniProt
Find proteins for P03960 (Escherichia coli (strain K12))
Explore P03960
Go to UniProtKB:  P03960
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03960
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Potassium-transporting ATPase KdpC subunit208Escherichia coli K-12Mutation(s): 0
Gene Names: kdpCb0696JW0684
Membrane Entity: Yes
UniProt
Find proteins for P03961 (Escherichia coli (strain K12))
Explore P03961
Go to UniProtKB:  P03961
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03961
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Potassium-transporting ATPase KdpF subunit29Escherichia coli K-12Mutation(s): 0
Gene Names: kdpFb4513JW0687
Membrane Entity: Yes
UniProt
Find proteins for P36937 (Escherichia coli (strain K12))
Explore P36937
Go to UniProtKB:  P36937
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP36937
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
9Y0 (Subject of Investigation/LOI)
Query on 9Y0

Download Ideal Coordinates CCD File
F [auth B](2R)-3-(((2-aminoethoxy)(hydroxy)phosphoryl)oxy)-2-(palmitoyloxy)propyl (E)-octadec-9-enoate
C39 H76 N O8 P
DVXMEPWDARXHCX-OTMQOFQLSA-N
K (Subject of Investigation/LOI)
Query on K

Download Ideal Coordinates CCD File
E [auth A]POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.38 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC2.9.0
MODEL REFINEMENTPHENIX1.18

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01 GM108043
European Research Council (ERC)Denmark637372
Danish Council for Independent ResearchDenmarkDFF-8021-00161

Revision History  (Full details and data files)

  • Version 1.0: 2021-01-27
    Type: Initial release
  • Version 1.1: 2021-08-11
    Changes: Database references
  • Version 1.2: 2021-09-29
    Changes: Data collection, Database references
  • Version 1.3: 2024-07-10
    Changes: Data collection, Refinement description
