6RD4 | pdb_00006rd4

CryoEM structure of Polytomella F-ATP synthase, Full dimer, composite map


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 6RD4

This is version 1.4 of the entry. See complete history

Literature

Rotary substates of mitochondrial ATP synthase reveal the basis of flexible F 1 -F o coupling.

Murphy, B.J.Klusch, N.Langer, J.Mills, D.J.Yildiz, O.Kuhlbrandt, W.

(2019) Science 364

  • DOI: https://doi.org/10.1126/science.aaw9128
  • Primary Citation Related Structures:
    6RD4, 6RD5, 6RD6, 6RD7, 6RD8, 6RD9, 6RDA, 6RDB, 6RDC, 6RDD, 6RDE, 6RDF, 6RDG, 6RDH, 6RDI, 6RDJ, 6RDK, 6RDL, 6RDM, 6RDN, 6RDO, 6RDP, 6RDQ, 6RDR, 6RDS, 6RDT, 6RDU, 6RDV, 6RDW, 6RDX, 6RDY, 6RDZ, 6RE0, 6RE1, 6RE2, 6RE3, 6RE4, 6RE5, 6RE6, 6RE7, 6RE8, 6RE9, 6REA, 6REB, 6REC, 6RED, 6REE, 6REF, 6REP, 6RER, ... Search all related entries

  • PubMed Abstract:

    F 1 F o -adenosine triphosphate (ATP) synthases make the energy of the proton-motive force available for energy-consuming processes in the cell. We determined the single-particle cryo-electron microscopy structure of active dimeric ATP synthase from mitochondria of Polytomella sp. at a resolution of 2.7 to 2.8 angstroms. Separation of 13 well-defined rotary substates by three-dimensional classification provides a detailed picture of the molecular motions that accompany c -ring rotation and result in ATP synthesis. Crucially, the F 1 head rotates along with the central stalk and c -ring rotor for the first ~30° of each 120° primary rotary step to facilitate flexible coupling of the stoichiometrically mismatched F 1 and F o subcomplexes. Flexibility is mediated primarily by the interdomain hinge of the conserved OSCP subunit. A conserved metal ion in the proton access channel may synchronize c -ring protonation with rotation.


  • Organizational Affiliation
    • Department of Structural Biology, Max Planck Institute of Biophysics, Frankfurt 60438, Germany.

Macromolecule Content

  • Total Structure Weight: 881.1 kDa
  • Atom Count: 53,776
  • Modeled Residue Count: 7,103
  • Deposited Residue Count: 8,234
  • Unique protein chains: 18

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ASA-10: Polytomella F-ATP synthase associated subunit 10A [auth 0]82Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A5H1ZR95 (Polytomella sp. Pringsheim 198.80)
Explore A0A5H1ZR95
Go to UniProtKB:  A0A5H1ZR95
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5H1ZR95
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP synthase associated protein ASA1B [auth 1]618Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for Q85JD5 (Polytomella sp. Pringsheim 198.80)
Explore Q85JD5
Go to UniProtKB:  Q85JD5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ85JD5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit ASA2C [auth 2]441Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for D7P6B9 (Polytomella sp. Pringsheim 198.80)
Explore D7P6B9
Go to UniProtKB:  D7P6B9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7P6B9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial F1F0 ATP synthase associated 32 kDa proteinD [auth 3]325Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for K0J903 (Polytomella sp. Pringsheim 198.80)
Explore K0J903
Go to UniProtKB:  K0J903
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupK0J903
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase associated protein ASA4E [auth 4]294Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for D7NIZ2 (Polytomella sp. Pringsheim 198.80)
Explore D7NIZ2
Go to UniProtKB:  D7NIZ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7NIZ2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial F1F0 ATP synthase associated 14 kDa proteinF [auth 5]123Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for A0A024FSR7 (Polytomella sp. Pringsheim 198.80)
Explore A0A024FSR7
Go to UniProtKB:  A0A024FSR7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A024FSR7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit ASA6G [auth 6]151Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for D7P897 (Polytomella sp. Pringsheim 198.80)
Explore D7P897
Go to UniProtKB:  D7P897
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7P897
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 8
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase associated protein ASA7H [auth 7]190Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for D8V7I2 (Polytomella sp. Pringsheim 198.80)
Explore D8V7I2
Go to UniProtKB:  D8V7I2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD8V7I2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 9
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit ASA8I [auth 8]89Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for D8V7I7 (Polytomella sp. Pringsheim 198.80)
Explore D8V7I7
Go to UniProtKB:  D8V7I7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD8V7I7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 10
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit ASA9J [auth 9]97Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0A5H1ZR73 (Polytomella sp. Pringsheim 198.80)
Explore A0A5H1ZR73
Go to UniProtKB:  A0A5H1ZR73
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5H1ZR73
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 11
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit c127Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for D7P7X5 (Polytomella sp. Pringsheim 198.80)
Explore D7P7X5
Go to UniProtKB:  D7P7X5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7P7X5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 12
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit 6U [auth M]327Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for H8PGG3 (Polytomella sp. Pringsheim 198.80)
Explore H8PGG3
Go to UniProtKB:  H8PGG3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupH8PGG3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 13
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit OSCPV [auth P]229Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for D8V7I1 (Polytomella sp. Pringsheim 198.80)
Explore D8V7I1
Go to UniProtKB:  D8V7I1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD8V7I1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 14
MoleculeChains  Sequence LengthOrganismDetailsImage
epsilon: Polytomella F-ATP synthase epsilon subunitW [auth Q]74Polytomella sp. Pringsheim 198.80Mutation(s): 0
UniProt
Find proteins for A0A5H1ZR74 (Polytomella sp. Pringsheim 198.80)
Explore A0A5H1ZR74
Go to UniProtKB:  A0A5H1ZR74
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5H1ZR74
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 15
MoleculeChains  Sequence LengthOrganismDetailsImage
Mitochondrial ATP synthase subunit deltaX [auth R]199Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for D7P7X6 (Polytomella sp. Pringsheim 198.80)
Explore D7P7X6
Go to UniProtKB:  D7P7X6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD7P7X6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 16
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP synthase gamma chain, mitochondrialY [auth S]317Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q4LDE7 (Polytomella sp. Pringsheim 198.80)
Explore Q4LDE7
Go to UniProtKB:  Q4LDE7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4LDE7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 17
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP synthase subunit alphaAA [auth U],
BA [auth V],
Z [auth T]
562Polytomella sp. Pringsheim 198.80Mutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for A0ZW40 (Polytomella sp. Pringsheim 198.80)
Explore A0ZW40
Go to UniProtKB:  A0ZW40
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ZW40
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 18
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP synthase subunit betaCA [auth X],
DA [auth Y],
EA [auth Z]
574Polytomella sp. Pringsheim 198.80Mutation(s): 0
EC: 7.1.2.2
Membrane Entity: Yes
UniProt
Find proteins for A0ZW41 (Polytomella sp. Pringsheim 198.80)
Explore A0ZW41
Go to UniProtKB:  A0ZW41
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ZW41
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP

Query on ATP



Download:Ideal Coordinates CCD File
GA [auth T],
IA [auth U],
KA [auth V]
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
ADP

Query on ADP



Download:Ideal Coordinates CCD File
MA [auth X],
OA [auth Y]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
FA [auth M]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
HA [auth T],
JA [auth U],
LA [auth V],
NA [auth X],
PA [auth Y]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.90 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.14
RECONSTRUCTIONRELION3

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Max Planck SocietyGermany--
European Molecular Biology OrganizationGermanyALTF 702 2016

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-03
    Type: Initial release
  • Version 1.1: 2019-07-10
    Changes: Data collection, Derived calculations
  • Version 1.2: 2019-12-18
    Changes: Data collection, Data processing, Other
  • Version 1.3: 2020-09-30
    Changes: Database references, Derived calculations
  • Version 1.4: 2024-05-22
    Changes: Data collection, Database references
