6P6Y

Crystal structure of voltage-gated sodium channel NavAb V100C/Q150C disulfide crosslinked mutant in the activated state


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.89 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.214
  • R-Value Observed: 0.217

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

Currently 6P6Y does not have a validation slider image.


This is version 1.3 of the entry. See complete history


Literature

Resting-State Structure and Gating Mechanism of a Voltage-Gated Sodium Channel.

Wisedchaisri, G.Tonggu, L.McCord, E.Gamal El-Din, T.M.Wang, L.Zheng, N.Catterall, W.A.

(2019) Cell 178: 993

  • DOI: https://doi.org/10.1016/j.cell.2019.06.031
  • Primary Citation of Related Structures:
    6P6W, 6P6X, 6P6Y

  • PubMed Abstract:

    Voltage-gated sodium (Na V ) channels initiate action potentials in nerve, muscle, and other electrically excitable cells. The structural basis of voltage gating is uncertain because the resting state exists only at deeply negative membrane potentials. To stabilize the resting conformation, we inserted voltage-shifting mutations and introduced a disulfide crosslink in the VS of the ancestral bacterial sodium channel Na V Ab. Here, we present a cryo-EM structure of the resting state and a complete voltage-dependent gating mechanism. The S4 segment of the VS is drawn intracellularly, with three gating charges passing through the transmembrane electric field. This movement forms an elbow connecting S4 to the S4-S5 linker, tightens the collar around the S6 activation gate, and prevents its opening. Our structure supports the classical "sliding helix" mechanism of voltage sensing and provides a complete gating mechanism for voltage sensor function, pore opening, and activation-gate closure based on high-resolution structures of a single sodium channel protein.


  • Organizational Affiliation

    Department of Pharmacology, University of Washington, Seattle, WA 98195, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ion transport protein257Aliarcobacter butzleri RM4018Mutation(s): 2
Gene Names: Abu_1752
Membrane Entity: Yes
UniProt
Find proteins for A8EVM5 (Aliarcobacter butzleri (strain RM4018))
Explore A8EVM5
Go to UniProtKB:  A8EVM5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8EVM5
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.89 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.214
  • R-Value Observed: 0.217
  • Space Group: I 4 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 125.83α = 90
b = 125.83β = 90
c = 189.292γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing
Cootmodel building
REFMACrefinement

Structure Validation

View Full Validation Report

Currently 6P6Y does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)United StatesR01 NS015751
National Institutes of Health/National Heart, Lung, and Blood Institute (NIH/NHLBI)United StatesR01 HL112808
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesT32 GM007750
Howard Hughes Medical Institute (HHMI)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2019-08-14
    Type: Initial release
  • Version 1.1: 2019-08-21
    Changes: Data collection, Database references
  • Version 1.2: 2019-11-20
    Changes: Author supporting evidence
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description
