6MZM

Human TFIID bound to promoter DNA and TFIIA


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structure of human TFIID and mechanism of TBP loading onto promoter DNA.

Patel, A.B.Louder, R.K.Greber, B.J.Grunberg, S.Luo, J.Fang, J.Liu, Y.Ranish, J.Hahn, S.Nogales, E.

(2018) Science 362

  • DOI: 10.1126/science.aau8872
  • Primary Citation of Related Structures:
    6MZC, 6MZD, 6MZL, 6MZM

  • PubMed Abstract:
  • The general transcription factor IID (TFIID) is a critical component of the eukaryotic transcription preinitiation complex (PIC) and is responsible for recognizing the core promoter DNA and initiating PIC assembly. We used cryo-electron microscopy, chemical cross-linking mass spectrometry, and biochemical reconstitution to determine the complete molecular architecture of TFIID and define the conformational landscape of TFIID in the process of TATA box-binding protein (TBP) loading onto promoter DNA ...

    The general transcription factor IID (TFIID) is a critical component of the eukaryotic transcription preinitiation complex (PIC) and is responsible for recognizing the core promoter DNA and initiating PIC assembly. We used cryo-electron microscopy, chemical cross-linking mass spectrometry, and biochemical reconstitution to determine the complete molecular architecture of TFIID and define the conformational landscape of TFIID in the process of TATA box-binding protein (TBP) loading onto promoter DNA. Our structural analysis revealed five structural states of TFIID in the presence of TFIIA and promoter DNA, showing that the initial binding of TFIID to the downstream promoter positions the upstream DNA and facilitates scanning of TBP for a TATA box and the subsequent engagement of the promoter. Our findings provide a mechanistic model for the specific loading of TBP by TFIID onto the promoter.


    Organizational Affiliation

    Department of Molecular and Cell Biology, University of California, Berkeley, CA 94720, USA.



Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 1, TAF1A496Homo sapiensMutation(s): 0
Gene Names: TAF1BA2RCCG1CCGSTAF2A
EC: 2.3.1.48 (UniProt), 2.7.11.1 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P21675 (Homo sapiens)
Explore P21675
Go to UniProtKB:  P21675
PHAROS:  P21675
GTEx:  ENSG00000147133
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21675
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 2, TAF2B1199Homo sapiensMutation(s): 0
Gene Names: TAF2CIF150TAF2B
UniProt & NIH Common Fund Data Resources
Find proteins for Q6P1X5 (Homo sapiens)
Explore Q6P1X5
Go to UniProtKB:  Q6P1X5
PHAROS:  Q6P1X5
GTEx:  ENSG00000064313
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6P1X5
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 4, TAF4C [auth D]1025Homo sapiensMutation(s): 0
Gene Names: TAF4TAF2CTAF2C1TAF4ATAFII130TAFII135
UniProt & NIH Common Fund Data Resources
Find proteins for O00268 (Homo sapiens)
Explore O00268
Go to UniProtKB:  O00268
PHAROS:  O00268
GTEx:  ENSG00000130699
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO00268
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 5,TAF5D [auth G]800Homo sapiensMutation(s): 0
Gene Names: TAF5
UniProt & NIH Common Fund Data Resources
Find proteins for Q15542 (Homo sapiens)
Explore Q15542
Go to UniProtKB:  Q15542
PHAROS:  Q15542
GTEx:  ENSG00000148835
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15542
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 6E [auth H]677Homo sapiensMutation(s): 0
Gene Names: TAF6TAF2ETAFII70
UniProt & NIH Common Fund Data Resources
Find proteins for P49848 (Homo sapiens)
Explore P49848
Go to UniProtKB:  P49848
PHAROS:  P49848
GTEx:  ENSG00000106290
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49848
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 6F [auth I]677Homo sapiensMutation(s): 0
Gene Names: TAF6
UniProt & NIH Common Fund Data Resources
Find proteins for P49848 (Homo sapiens)
Explore P49848
Go to UniProtKB:  P49848
PHAROS:  P49848
GTEx:  ENSG00000106290
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49848
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 7G [auth J]349Homo sapiensMutation(s): 0
Gene Names: TAF7TAF2FTAFII55
UniProt & NIH Common Fund Data Resources
Find proteins for Q15545 (Homo sapiens)
Explore Q15545
Go to UniProtKB:  Q15545
PHAROS:  Q15545
GTEx:  ENSG00000178913
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15545
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 8, TAF8H [auth K]310Homo sapiensMutation(s): 0
Gene Names: TAF8
UniProt & NIH Common Fund Data Resources
Find proteins for Q7Z7C8 (Homo sapiens)
Explore Q7Z7C8
Go to UniProtKB:  Q7Z7C8
PHAROS:  Q7Z7C8
GTEx:  ENSG00000137413
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Z7C8
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 9, TAF9I [auth L]264Homo sapiensMutation(s): 0
Gene Names: TAF9
UniProt & NIH Common Fund Data Resources
Find proteins for Q16594 (Homo sapiens)
Explore Q16594
Go to UniProtKB:  Q16594
PHAROS:  Q16594
GTEx:  ENSG00000273841
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16594
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 10J [auth O]218Homo sapiensMutation(s): 0
Gene Names: TAF10TAF2ATAF2HTAFII30
UniProt & NIH Common Fund Data Resources
Find proteins for Q12962 (Homo sapiens)
Explore Q12962
Go to UniProtKB:  Q12962
PHAROS:  Q12962
GTEx:  ENSG00000166337
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12962
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 12K [auth R]161Homo sapiensMutation(s): 0
Gene Names: TAF12TAF15TAF2JTAFII20
UniProt & NIH Common Fund Data Resources
Find proteins for Q16514 (Homo sapiens)
Explore Q16514
Go to UniProtKB:  Q16514
PHAROS:  Q16514
GTEx:  ENSG00000120656
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16514
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetailsImage
TATA-box-binding proteinL [auth T]339Homo sapiensMutation(s): 0
Gene Names: TBPGTF2D1TF2DTFIID
UniProt & NIH Common Fund Data Resources
Find proteins for P20226 (Homo sapiens)
Explore P20226
Go to UniProtKB:  P20226
PHAROS:  P20226
GTEx:  ENSG00000112592
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP20226
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor IIA subunit 1O [auth W]90Homo sapiensMutation(s): 0
Gene Names: GTF2A1TF2A1
UniProt & NIH Common Fund Data Resources
Find proteins for P52655 (Homo sapiens)
Explore P52655
Go to UniProtKB:  P52655
PHAROS:  P52655
GTEx:  ENSG00000165417
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP52655
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor IIA subunit 2P [auth X]97Homo sapiensMutation(s): 0
Gene Names: GTF2A2TF2A2
UniProt & NIH Common Fund Data Resources
Find proteins for P52657 (Homo sapiens)
Explore P52657
Go to UniProtKB:  P52657
PHAROS:  P52657
GTEx:  ENSG00000140307
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP52657
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetailsImage
UnkQ [auth Z]238Homo sapiensMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChainsLengthOrganismImage
SCP DNA (80-MER)M [auth U]80Homo sapiens
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChainsLengthOrganismImage
SCP DNA (80-MER)N [auth V]80Homo sapiens
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report




Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Howard Hughes Medical Institute (HHMI)United States--
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01-GM63072

Revision History  (Full details and data files)

  • Version 1.0: 2018-11-28
    Type: Initial release
  • Version 1.1: 2019-01-02
    Changes: Data collection, Database references
  • Version 1.2: 2019-11-20
    Changes: Author supporting evidence
  • Version 1.3: 2019-12-18
    Changes: Other
