6MZL

Human TFIID canonical state

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 23.0 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

Structure of human TFIID and mechanism of TBP loading onto promoter DNA.

Patel, A.B., Louder, R.K., Greber, B.J., Grunberg, S., Luo, J., Fang, J., Liu, Y., Ranish, J., Hahn, S., Nogales, E.

(2018) Science 362

  • DOI: 10.1126/science.aau8872
  • Primary Citation of Related Structures:
    6MZC, 6MZD, 6MZL, 6MZM

  • PubMed Abstract:

    • The general transcription factor IID (TFIID) is a critical component of the eukaryotic transcription preinitiation complex (PIC) and is responsible for recognizing the core promoter DNA and initiating PIC assembly. We used cryo-electron microscopy, chemical cross-linking mass spectrometry, and biochemical reconstitution to determine the complete molecular architecture of TFIID and define the conformational landscape of TFIID in the process of TATA box-binding protein (TBP) loading onto promoter DNA ...

    The general transcription factor IID (TFIID) is a critical component of the eukaryotic transcription preinitiation complex (PIC) and is responsible for recognizing the core promoter DNA and initiating PIC assembly. We used cryo-electron microscopy, chemical cross-linking mass spectrometry, and biochemical reconstitution to determine the complete molecular architecture of TFIID and define the conformational landscape of TFIID in the process of TATA box-binding protein (TBP) loading onto promoter DNA. Our structural analysis revealed five structural states of TFIID in the presence of TFIIA and promoter DNA, showing that the initial binding of TFIID to the downstream promoter positions the upstream DNA and facilitates scanning of TBP for a TATA box and the subsequent engagement of the promoter. Our findings provide a mechanistic model for the specific loading of TBP by TFIID onto the promoter.

    Organizational Affiliation:

    Department of Molecular and Cell Biology, University of California, Berkeley, CA 94720, USA.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 1A1,872Homo sapiensMutation(s): 0
Gene Names: TAF1, BA2R, CCG1, CCGS, TAF2A
EC: 2.3.1.48 (PDB Primary Data), 2.7.11.1 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for P21675 (Homo sapiens)
Explore P21675
Go to UniProtKB:  P21675
PHAROS:  P21675
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21675
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 2B1,199Homo sapiensMutation(s): 0
Gene Names: TAF2, CIF150, TAF2B
UniProt & NIH Common Fund Data Resources
Find proteins for Q6P1X5 (Homo sapiens)
Explore Q6P1X5
Go to UniProtKB:  Q6P1X5
PHAROS:  Q6P1X5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6P1X5
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 3C929Homo sapiensMutation(s): 0
Gene Names: TAF3
UniProt & NIH Common Fund Data Resources
Find proteins for Q5VWG9 (Homo sapiens)
Explore Q5VWG9
Go to UniProtKB:  Q5VWG9
PHAROS:  Q5VWG9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5VWG9
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 4D, E1,085Homo sapiensMutation(s): 0
Gene Names: TAF4, TAF2C, TAF2C1, TAF4A, TAFII130, TAFII135
UniProt & NIH Common Fund Data Resources
Find proteins for O00268 (Homo sapiens)
Explore O00268
Go to UniProtKB:  O00268
PHAROS:  O00268
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO00268
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 5,TAF5F, G800Homo sapiensMutation(s): 0
Gene Names: TAF5
UniProt & NIH Common Fund Data Resources
Find proteins for Q15542 (Homo sapiens)
Explore Q15542
Go to UniProtKB:  Q15542
PHAROS:  Q15542
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15542
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 6H677Homo sapiensMutation(s): 0
Gene Names: TAF6, TAF2E, TAFII70
UniProt & NIH Common Fund Data Resources
Find proteins for P49848 (Homo sapiens)
Explore P49848
Go to UniProtKB:  P49848
PHAROS:  P49848
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49848
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 6I677Homo sapiensMutation(s): 0
Gene Names: TAF6
UniProt & NIH Common Fund Data Resources
Find proteins for P49848 (Homo sapiens)
Explore P49848
Go to UniProtKB:  P49848
PHAROS:  P49848
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49848
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 7J349Homo sapiensMutation(s): 0
Gene Names: TAF7, TAF2F, TAFII55
UniProt & NIH Common Fund Data Resources
Find proteins for Q15545 (Homo sapiens)
Explore Q15545
Go to UniProtKB:  Q15545
PHAROS:  Q15545
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15545
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 8,TAF8K310Homo sapiensMutation(s): 0
Gene Names: TAF8
UniProt & NIH Common Fund Data Resources
Find proteins for Q7Z7C8 (Homo sapiens)
Explore Q7Z7C8
Go to UniProtKB:  Q7Z7C8
PHAROS:  Q7Z7C8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Z7C8
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 9, TAF9L, M264Homo sapiensMutation(s): 0
Gene Names: TAF9
UniProt & NIH Common Fund Data Resources
Find proteins for Q16594 (Homo sapiens)
Explore Q16594
Go to UniProtKB:  Q16594
PHAROS:  Q16594
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16594
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 10N, O218Homo sapiensMutation(s): 0
Gene Names: TAF10, TAF2A, TAF2H, TAFII30
UniProt & NIH Common Fund Data Resources
Find proteins for Q12962 (Homo sapiens)
Explore Q12962
Go to UniProtKB:  Q12962
PHAROS:  Q12962
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12962
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 11P211Homo sapiensMutation(s): 0
Gene Names: TAF11, TAF2I, PRO2134
UniProt & NIH Common Fund Data Resources
Find proteins for Q15544 (Homo sapiens)
Explore Q15544
Go to UniProtKB:  Q15544
PHAROS:  Q15544
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15544
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 12Q, R161Homo sapiensMutation(s): 0
Gene Names: TAF12, TAF15, TAF2J, TAFII20
UniProt & NIH Common Fund Data Resources
Find proteins for Q16514 (Homo sapiens)
Explore Q16514
Go to UniProtKB:  Q16514
PHAROS:  Q16514
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16514
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetailsImage
Transcription initiation factor TFIID subunit 13S124Homo sapiensMutation(s): 0
Gene Names: TAF13, TAF2K, TAFII18
UniProt & NIH Common Fund Data Resources
Find proteins for Q15543 (Homo sapiens)
Explore Q15543
Go to UniProtKB:  Q15543
PHAROS:  Q15543
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15543
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetailsImage
TATA-box-binding proteinT339Homo sapiensMutation(s): 0
Gene Names: TBP, GTF2D1, TF2D, TFIID
UniProt & NIH Common Fund Data Resources
Find proteins for P20226 (Homo sapiens)
Explore P20226
Go to UniProtKB:  P20226
PHAROS:  P20226
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP20226
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetailsImage
poly(UNK)U [auth Y]96Homo sapiensMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetailsImage
poly(UNK)V [auth Z]238Homo sapiensMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 23.0 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Howard Hughes Medical Institute (HHMI)United States--
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01-GM63072

Revision History  (Full details and data files)

  • Version 1.0: 2018-11-28
    Type: Initial release
  • Version 1.1: 2019-01-02
    Changes: Data collection, Database references
  • Version 1.2: 2019-11-20
    Changes: Author supporting evidence
