6GOB

X-ray structure of the adduct formed upon reaction of lysozyme with a Pd(II) complex bearing N,N-pyridylbenzimidazole derivative with an alkylated sulphonate side chain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.96 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.169
  • R-Value Observed: 0.173

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Exploring the interactions between model proteins and Pd(ii) or Pt(ii) compounds bearing charged N,N-pyridylbenzimidazole bidentate ligands by X-ray crystallography.

Ferraro, G.Mansour, A.M.Merlino, A.

(2018) Dalton Trans 47: 10130-10138

  • DOI: 10.1039/c8dt01663a
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Pd(ii) and Pt(ii) compounds bearing N,N-pyridylbenzimidazole derivatives with an alkylated sulfonate or phosphonium side chain are able to bind the model protein lysozyme both covalently and non-covalently as an entire compound or as a product of a h ...

    Pd(ii) and Pt(ii) compounds bearing N,N-pyridylbenzimidazole derivatives with an alkylated sulfonate or phosphonium side chain are able to bind the model protein lysozyme both covalently and non-covalently as an entire compound or as a product of a hydrolysis reaction. The interactions with the protein and the origin of the different behaviors of these complexes were unknown hitherto. Here, we present four crystal structures of their adducts with lysozyme. Pt- and Pd-containing fragments bind the protein with different stoichiometries close to the side chains of His15, Asp87, Asp101 and Asn77. The compounds bearing a phosphonium side chain degrade during the reaction with lysozyme. Data show the origin of the non-covalent mode of binding of Pd and Pt compounds bearing a sulfonate side chain, which drives the recognition process by forming a series of H-bonds and coulombic interactions with positively charged residue side chains. In a separate experiment, the structure of the adduct that is formed when the Pd(ii) compound containing an alkylated sulfonate group reacts with ribonuclease A was also determined. In this structure, the sulfonate-Pd(ii) complex binds the side chain of His105 on the surface of the protein and the side chain of the catalytically important His119 residue. Altogether, our data provide a structural basis for understanding the behavior of the analyzed Pd(ii)- and Pt(ii)-based cisplatin analogues in their reactions with proteins and show the first structural characterization of an adduct comprising a cisplatin analogue that is non-covalently bound to a protein. The results suggest that functionalization of a ligand system with a sulfonate group can significantly alter the protein-binding activity and thus the overall pharmacological profile of Pd(ii)- and Pt(ii)-based drugs.


    Organizational Affiliation

    Department of Chemical Sciences, University of Naples Federico II, Complesso Universitario di Monte Sant'Angelo, 80126 Napoli, Italy. antonello.merlino@unina.it.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Lysozyme C
A
129Gallus gallusMutation(s): 0
Gene Names: LYZ
EC: 3.2.1.17
Find proteins for P00698 (Gallus gallus)
Go to UniProtKB:  P00698
Small Molecules
Ligands 5 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
F6Q
Query on F6Q

Download CCD File
A
N,N-pyridylbenzimidazole derivative-Pd complex
C15 H15 Cl2 N3 O3 Pd S
DTXSGQZIKSCPLR-UHFFFAOYSA-L
 Ligand Interaction
PD
Query on PD

Download CCD File
A
PALLADIUM ION
Pd
MUJIDPITZJWBSW-UHFFFAOYSA-N
 Ligand Interaction
SO4
Query on SO4

Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
NO3
Query on NO3

Download CCD File
A
NITRATE ION
N O3
NHNBFGGVMKEFGY-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download CCD File
A
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.96 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.169
  • R-Value Observed: 0.173
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 79.487α = 90
b = 79.487β = 90
c = 37.309γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2018-07-25
    Type: Initial release
  • Version 1.1: 2018-08-08
    Changes: Data collection, Database references
