5Z0I | pdb_00005z0i

Crystal structure of copper-bound tyrosinase from Streptomyces castaneoglobisporus in complex with the caddie protein obtained by soaking in the hydroxylamine-containing solution for 1 h at 277 K

• PDB DOI: https://doi.org/10.2210/pdb5Z0I/pdb

• Classification: OXIDOREDUCTASE/METAL BINDING PROTEIN
• Organism(s): Streptomyces castaneoglobisporus
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2017-12-19 Released: 2018-12-26
• Deposition Author(s): Matoba, Y., Sugiyama, M.
• Funding Organization(s): KAKENHI

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.32 Å
• R-Value Free:
  0.188 (Depositor), 0.182 (DCC)
• R-Value Work:
  0.136 (Depositor), 0.139 (DCC)
• R-Value Observed:
  0.140 (Depositor)

Starting Model: experimental

Literature

Catalytic mechanism of tyrosinase implied from the quinone formation on the Tyr98 residue of the caddie protein

Matoba, Y., Sugiyama, M.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 46.79 kDa
• Atom Count: 3,237
• Modeled Residue Count: 347
• Deposited Residue Count: 415
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Tyrosinase	A	281	Streptomyces castaneoglobisporus	Mutation(s): 0  Gene Names: tyrC EC: 1.14.18.1
UniProt
Find proteins for Q83WS2 (Streptomyces castaneoglobisporus) Explore Q83WS2  Go to UniProtKB:  Q83WS2

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
MelC	B	134	Streptomyces castaneoglobisporus	Mutation(s): 0  Gene Names: orf378
UniProt
Find proteins for Q83WS1 (Streptomyces castaneoglobisporus) Explore Q83WS1  Go to UniProtKB:  Q83WS1

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CU	C [auth A], D [auth A], E [auth A], K [auth B]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N
NO3	G [auth A], H [auth A], I [auth A], J [auth A], L [auth B]	NITRATE ION N O3 NHNBFGGVMKEFGY-UHFFFAOYSA-N
PER	F [auth A]	PEROXIDE ION O2 ANAIPYUSIMHBEL-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
DAH	B	L-PEPTIDE LINKING	C9 H11 N O4		TYR

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.32 Å
• R-Value Free:  0.188 (Depositor), 0.182 (DCC)
• R-Value Work:  0.136 (Depositor), 0.139 (DCC)
• R-Value Observed: 0.140 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 64.93	α = 90
b = 97.33	β = 90
c = 54.84	γ = 90

Software Package:

Software Name	Purpose
CNS	phasing
SHELXL-97	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2018-12-26
Deposition Author(s): Matoba, Y., Sugiyama, M.

---

Funding Organization	Location	Grant Number
KAKENHI	Japan	25109530, 15H009470

Revision History

• Version 1.0: 2018-12-26
  Type: Initial release

• Version 1.1: 2023-11-22
  Changes: Data collection, Database references, Derived calculations, Refinement description
• Version 1.2: 2024-11-13
  Changes: Structure summary
• Version 2.0: 2025-09-17
  Changes: Atomic model, Data collection, Database references, Derived calculations, Polymer sequence, Source and taxonomy, Structure summary
