5Q0I

Ligand binding to FARNESOID-X-RECEPTOR


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.226
  • R-Value Work: 0.185
  • R-Value Observed: 0.187

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.7 of the entry. See complete history


Literature

D3R Grand Challenge 2: blind prediction of protein-ligand poses, affinity rankings, and relative binding free energies.

Gaieb, Z.Liu, S.Gathiaka, S.Chiu, M.Yang, H.Shao, C.Feher, V.A.Walters, W.P.Kuhn, B.Rudolph, M.G.Burley, S.K.Gilson, M.K.Amaro, R.E.

(2018) J Comput Aided Mol Des 32: 1-20

  • DOI: https://doi.org/10.1007/s10822-017-0088-4
  • Primary Citation of Related Structures:
    5Q0I, 5Q0J, 5Q0K, 5Q0L, 5Q0M, 5Q0N, 5Q0O, 5Q0P, 5Q0Q, 5Q0R, 5Q0S, 5Q0T, 5Q0U, 5Q0V, 5Q0W, 5Q0X, 5Q0Y, 5Q0Z, 5Q10, 5Q11, 5Q12, 5Q13, 5Q14, 5Q15, 5Q16, 5Q17, 5Q18, 5Q19, 5Q1A, 5Q1B, 5Q1C, 5Q1D, 5Q1E, 5Q1F, 5Q1G, 5Q1H, 5Q1I

  • PubMed Abstract:

    The Drug Design Data Resource (D3R) ran Grand Challenge 2 (GC2) from September 2016 through February 2017. This challenge was based on a dataset of structures and affinities for the nuclear receptor farnesoid X receptor (FXR), contributed by F. Hoffmann-La Roche. The dataset contained 102 IC50 values, spanning six orders of magnitude, and 36 high-resolution co-crystal structures with representatives of four major ligand classes. Strong global participation was evident, with 49 participants submitting 262 prediction submission packages in total. Procedurally, GC2 mimicked Grand Challenge 2015 (GC2015), with a Stage 1 subchallenge testing ligand pose prediction methods and ranking and scoring methods, and a Stage 2 subchallenge testing only ligand ranking and scoring methods after the release of all blinded co-crystal structures. Two smaller curated sets of 18 and 15 ligands were developed to test alchemical free energy methods. This overview summarizes all aspects of GC2, including the dataset details, challenge procedures, and participant results. We also consider implications for progress in the field, while highlighting methodological areas that merit continued development. Similar to GC2015, the outcome of GC2 underscores the pressing need for methods development in pose prediction, particularly for ligand scaffolds not currently represented in the Protein Data Bank ( http://www.pdb.org ), and in affinity ranking and scoring of bound ligands.


  • Organizational Affiliation

    Drug Design Data Resource, University of California, San Diego, La Jolla, CA, 92093, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bile acid receptor233Homo sapiensMutation(s): 0
Gene Names: NR1H4BARFXRHRR1RIP14
UniProt & NIH Common Fund Data Resources
Find proteins for Q96RI1 (Homo sapiens)
Explore Q96RI1
Go to UniProtKB:  Q96RI1
PHAROS:  Q96RI1
GTEx:  ENSG00000012504
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ96RI1
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
COACTIVATOR PEPTIDE PGC-1A PPAR GAMMA COACTIVATOR12Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UBK2 (Homo sapiens)
Explore Q9UBK2
Go to UniProtKB:  Q9UBK2
PHAROS:  Q9UBK2
GTEx:  ENSG00000109819
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9UBK2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
0X0
Query on 0X0

Download Ideal Coordinates CCD File
C [auth A]2-[(3,4-dimethoxyphenyl)-(4-methylphenyl)sulfonyl-amino]-N-(2,4-dimethylpentan-3-yl)ethanamide
C24 H34 N2 O5 S
WYLSGWZVDHQRNX-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.226
  • R-Value Work: 0.185
  • R-Value Observed: 0.187
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 35.648α = 90
b = 54.952β = 90
c = 108.801γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
HKL-2000data scaling
PDB_EXTRACTdata extraction
HKL-2000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-07-05
    Type: Initial release
  • Version 1.1: 2017-07-19
    Changes: Database references, Structure summary
  • Version 1.2: 2017-12-20
    Changes: Database references
  • Version 1.3: 2018-01-31
    Changes: Database references
  • Version 1.4: 2018-02-21
    Changes: Structure summary
  • Version 1.5: 2021-02-10
    Changes: Database references, Structure summary
  • Version 1.6: 2021-11-17
    Changes: Database references, Structure summary
  • Version 1.7: 2024-05-22
    Changes: Data collection
