5NPZ

Porcine (Sus scrofa) Major Histocompatibility Complex, class I, presenting EFEDLTFLA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.43 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.184
  • R-Value Observed: 0.185

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Induction of influenza-specific local CD8 T-cells in the respiratory tract after aerosol delivery of vaccine antigen or virus in the Babraham inbred pig.

Tungatt, K.Dolton, G.Morgan, S.B.Attaf, M.Fuller, A.Whalley, T.Hemmink, J.D.Porter, E.Szomolay, B.Montoya, M.Hammond, J.A.Miles, J.J.Cole, D.K.Townsend, A.Bailey, M.Rizkallah, P.J.Charleston, B.Tchilian, E.Sewell, A.K.

(2018) PLoS Pathog 14: e1007017-e1007017

  • DOI: 10.1371/journal.ppat.1007017
  • Primary Citation of Related Structures:
    5NQ1, 5NQ0, 5NQ3, 5NQ2, 5NPZ

  • PubMed Abstract:
  • There is increasing evidence that induction of local immune responses is a key component of effective vaccines. For respiratory pathogens, for example tuberculosis and influenza, aerosol delivery is being actively explored as a method to administer v ...

    There is increasing evidence that induction of local immune responses is a key component of effective vaccines. For respiratory pathogens, for example tuberculosis and influenza, aerosol delivery is being actively explored as a method to administer vaccine antigens. Current animal models used to study respiratory pathogens suffer from anatomical disparity with humans. The pig is a natural and important host of influenza viruses and is physiologically more comparable to humans than other animal models in terms of size, respiratory tract biology and volume. It may also be an important vector in the birds to human infection cycle. A major drawback of the current pig model is the inability to analyze antigen-specific CD8+ T-cell responses, which are critical to respiratory immunity. Here we address this knowledge gap using an established in-bred pig model with a high degree of genetic identity between individuals, including the MHC (Swine Leukocyte Antigen (SLA)) locus. We developed a toolset that included long-term in vitro pig T-cell culture and cloning and identification of novel immunodominant influenza-derived T-cell epitopes. We also generated structures of the two SLA class I molecules found in these animals presenting the immunodominant epitopes. These structures allowed definition of the primary anchor points for epitopes in the SLA binding groove and established SLA binding motifs that were used to successfully predict other influenza-derived peptide sequences capable of stimulating T-cells. Peptide-SLA tetramers were constructed and used to track influenza-specific T-cells ex vivo in blood, the lungs and draining lymph nodes. Aerosol immunization with attenuated single cycle influenza viruses (S-FLU) induced large numbers of CD8+ T-cells specific for conserved NP peptides in the respiratory tract. Collectively, these data substantially increase the utility of pigs as an effective model for studying protective local cellular immunity against respiratory pathogens.


    Organizational Affiliation

    Systems Immunity Research Institute, Cardiff University, Cardiff, Wales, United Kingdom.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
MHC class I antigenA277Sus scrofaMutation(s): 0
Gene Names: SLA-1
Find proteins for B1PJV3 (Sus scrofa)
Explore B1PJV3
Go to UniProtKB:  B1PJV3
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Beta-2-microglobulinB99Sus scrofaMutation(s): 0
Gene Names: B2M
Find proteins for Q07717 (Sus scrofa)
Explore Q07717
Go to UniProtKB:  Q07717
Protein Feature View
Expand
  • Reference Sequence
  • Find similar proteins by:  Sequence   |   Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
GLU-PHE-GLU-ASP-LEU-THR-PHE-LEU-ALAC9unidentified influenza virusMutation(s): 0
Find proteins for P03466 (Influenza A virus (strain A/Puerto Rico/8/1934 H1N1))
Explore P03466
Go to UniProtKB:  P03466
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
PEG
Query on PEG

Download CCD File
A
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
GOL
Query on GOL

Download CCD File
A, B
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
EDO
Query on EDO

Download CCD File
A, B, C
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.43 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.184
  • R-Value Observed: 0.185
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.034α = 90
b = 128.29β = 101.9
c = 46.794γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
xia2data reduction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2018-05-02
    Type: Initial release
  • Version 1.1: 2019-05-15
    Changes: Data collection, Database references
