Crystal structure of tryptophan synthase alpha beta complex from Streptococcus pneumoniae

Experimental Data Snapshot

  • Resolution: 2.45 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.180
  • R-Value Observed: 0.183

wwPDB Validation   3D Report Full Report

This is version 3.2 of the entry. See complete history


Conservation of the structure and function of bacterial tryptophan synthases.

Michalska, K.Gale, J.Joachimiak, G.Chang, C.Hatzos-Skintges, C.Nocek, B.Johnston, S.E.Bigelow, L.Bajrami, B.Jedrzejczak, R.P.Wellington, S.Hung, D.T.Nag, P.P.Fisher, S.L.Endres, M.Joachimiak, A.

(2019) IUCrJ 6: 649-664

  • DOI: https://doi.org/10.1107/S2052252519005955
  • Primary Citation of Related Structures:
    5KIN, 5KZM

  • PubMed Abstract:

    Tryptophan biosynthesis is one of the most characterized processes in bacteria, in which the enzymes from Salmonella typhimurium and Escherichia coli serve as model systems. Tryptophan synthase (TrpAB) catalyzes the final two steps of tryptophan biosynthesis in plants, fungi and bacteria. This pyridoxal 5'-phosphate (PLP)-dependent enzyme consists of two protein chains, α (TrpA) and β (TrpB), functioning as a linear αββα heterotetrameric complex containing two TrpAB units. The reaction has a complicated, multistep mechanism resulting in the β-replacement of the hydroxyl group of l-serine with an indole moiety. Recent studies have shown that functional TrpAB is required for the survival of pathogenic bacteria in macrophages and for evading host defense. Therefore, TrpAB is a promising target for drug discovery, as its orthologs include enzymes from the important human pathogens Streptococcus pneumoniae , Legionella pneumophila and Francisella tularensis , the causative agents of pneumonia, legionnaires' disease and tularemia, respectively. However, specific biochemical and structural properties of the TrpABs from these organisms have not been investigated. To fill the important phylogenetic gaps in the understanding of TrpABs and to uncover unique features of TrpAB orthologs to spearhead future drug-discovery efforts, the TrpABs from L. pneumophila , F. tularensis and S. pneumoniae have been characterized. In addition to kinetic properties and inhibitor-sensitivity data, structural information gathered using X-ray crystallo-graphy is presented. The enzymes show remarkable structural conservation, but at the same time display local differences in both their catalytic and allosteric sites that may be responsible for the observed differences in catalysis and inhibitor binding. This functional dissimilarity may be exploited in the design of species-specific enzyme inhibitors.

  • Organizational Affiliation

    Center for Structural Genomics of Infectious Diseases, University of Chicago, Chicago, IL 60367, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tryptophan synthase alpha chain
A, C
258Streptococcus pneumoniae TIGR4Mutation(s): 0
Gene Names: trpASP_1811
Find proteins for Q97P33 (Streptococcus pneumoniae serotype 4 (strain ATCC BAA-334 / TIGR4))
Explore Q97P33
Go to UniProtKB:  Q97P33
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ97P33
Sequence Annotations
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Tryptophan synthase beta chain
B, D
407Streptococcus pneumoniae TIGR4Mutation(s): 0
Gene Names: trpBSP_1812
Find proteins for Q97P32 (Streptococcus pneumoniae serotype 4 (strain ATCC BAA-334 / TIGR4))
Explore Q97P32
Go to UniProtKB:  Q97P32
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ97P32
Sequence Annotations
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
Query on LLP
B, D
Experimental Data & Validation

Experimental Data

Unit Cell:
Length ( Å )Angle ( ˚ )
a = 67.697α = 90
b = 71.16β = 101.69
c = 138.682γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
HKL-3000data reduction

Structure Validation

View Full Validation Report

Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2016-07-06
    Type: Initial release
  • Version 2.0: 2018-05-09
    Changes: Advisory, Atomic model, Data collection, Database references, Derived calculations, Polymer sequence, Source and taxonomy, Structure summary
  • Version 3.0: 2019-09-18
    Changes: Data collection, Database references, Polymer sequence
  • Version 3.1: 2023-09-27
    Changes: Data collection, Database references, Refinement description
  • Version 3.2: 2023-11-15
    Changes: Data collection
