5HOW

X-ray crystallographic structure of an Abeta 17-36 beta-hairpin. LV(PHI)FAEDCGSNKCAII(SAR)L(ORN)V


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.29 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.234
  • R-Value Observed: 0.236

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

X-ray Crystallographic Structures of a Trimer, Dodecamer, and Annular Pore Formed by an A beta 17-36 beta-Hairpin.

Kreutzer, A.G.Hamza, I.L.Spencer, R.K.Nowick, J.S.

(2016) J Am Chem Soc 138: 4634-4642

  • DOI: 10.1021/jacs.6b01332
  • Primary Citation of Related Structures:
    5HOW, 5HOY, 5HOX

  • PubMed Abstract:
  • High-resolution structures of oligomers formed by the β-amyloid peptide Aβ are needed to understand the molecular basis of Alzheimer's disease and develop therapies. This paper presents the X-ray crystallographic structures of oligomers formed by a 2 ...

    High-resolution structures of oligomers formed by the β-amyloid peptide Aβ are needed to understand the molecular basis of Alzheimer's disease and develop therapies. This paper presents the X-ray crystallographic structures of oligomers formed by a 20-residue peptide segment derived from Aβ. The development of a peptide in which Aβ17-36 is stabilized as a β-hairpin is described, and the X-ray crystallographic structures of oligomers it forms are reported. Two covalent constraints act in tandem to stabilize the Aβ17-36 peptide in a hairpin conformation: a δ-linked ornithine turn connecting positions 17 and 36 to create a macrocycle and an intramolecular disulfide linkage between positions 24 and 29. An N-methyl group at position 33 blocks uncontrolled aggregation. The peptide readily crystallizes as a folded β-hairpin, which assembles hierarchically in the crystal lattice. Three β-hairpin monomers assemble to form a triangular trimer, four trimers assemble in a tetrahedral arrangement to form a dodecamer, and five dodecamers pack together to form an annular pore. This hierarchical assembly provides a model, in which full-length Aβ transitions from an unfolded monomer to a folded β-hairpin, which assembles to form oligomers that further pack to form an annular pore. This model may provide a better understanding of the molecular basis of Alzheimer's disease at atomic resolution.


    Organizational Affiliation

    Department of Chemistry, University of California, Irvine , Irvine, California 92697-2025, United States.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Amyloid beta A4 proteinABCDEF21Homo sapiensMutation(s): 0
Gene Names: APPA4AD1
Find proteins for P05067 (Homo sapiens)
Explore P05067
Go to UniProtKB:  P05067
NIH Common Fund Data Resources
PHAROS  P05067
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  3 Unique
IDChainsTypeFormula2D DiagramParent
ORN
Query on ORN
A,B,C,D,E,FL-PEPTIDE LINKINGC5 H12 N2 O2ALA
PHI
Query on PHI
A,B,C,D,E,FL-PEPTIDE LINKINGC9 H10 I N O2PHE
SAR
Query on SAR
A,B,C,D,E,FPEPTIDE LINKINGC3 H7 N O2GLY
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.29 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.234
  • R-Value Observed: 0.236
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 97.31α = 90
b = 97.31β = 90
c = 97.621γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM097562

Revision History

  • Version 1.0: 2016-03-23
    Type: Initial release
  • Version 1.1: 2016-04-20
    Changes: Database references
  • Version 1.2: 2017-09-13
    Changes: Author supporting evidence, Derived calculations
  • Version 1.3: 2019-12-25
    Changes: Author supporting evidence
