4V8R

The crystal structures of the eukaryotic chaperonin CCT reveal its functional partitioning


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.80 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.248
  • R-Value Observed: 0.248

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Re-refinement Note

This entry reflects an alternative modeling of the original data in: 3P9D


Literature

The Crystal Structures of the Eukaryotic Chaperonin Cct Reveal its Functional Partitioning

Kalisman, N.Schroder, G.F.Levitt, M.

(2013) Structure 21: 540

  • DOI: https://doi.org/10.1016/j.str.2013.01.017
  • Primary Citation of Related Structures:
    4B2T, 4V8R

  • PubMed Abstract:

    In eukaryotes, CCT is essential for the correct and efficient folding of many cytosolic proteins, most notably actin and tubulin. Structural studies of CCT have been hindered by the failure of standard crystallographic analysis to resolve its eight different subunit types at low resolutions. Here, we exhaustively assess the R value fit of all possible CCT models to available crystallographic data of the closed and open forms with resolutions of 3.8 Å and 5.5 Å, respectively. This unbiased analysis finds the native subunit arrangements with overwhelming significance. The resulting structures provide independent crystallographic proof of the subunit arrangement of CCT and map major asymmetrical features of the particle onto specific subunits. The actin and tubulin substrates both bind around subunit CCT6, which shows other structural anomalies. CCT is thus clearly partitioned, both functionally and evolutionary, into a substrate-binding side that is opposite to the ATP-hydrolyzing side.


  • Organizational Affiliation

    Department of Structural Biology, Stanford University School of Medicine, Stanford, CA 94305, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
T-COMPLEX PROTEIN 1 SUBUNIT ALPHAA [auth AA],
I [auth Aa],
Q [auth BA],
Y [auth Ba]
559Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P12612 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P12612
Go to UniProtKB:  P12612
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP12612
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
T-COMPLEX PROTEIN 1 SUBUNIT BETAB [auth AB],
J [auth Ab],
R [auth BB],
Z [auth Bb]
527Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P39076 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P39076
Go to UniProtKB:  P39076
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39076
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
T-COMPLEX PROTEIN 1 SUBUNIT DELTAAA [auth Bd],
C [auth AD],
K [auth Ad],
S [auth BD]
528Saccharomyces cerevisiaeMutation(s): 1
UniProt
Find proteins for P39078 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P39078
Go to UniProtKB:  P39078
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39078
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
T-COMPLEX PROTEIN 1 SUBUNIT EPSILONBA [auth Be],
D [auth AE],
L [auth Ae],
T [auth BE]
562Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P40413 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P40413
Go to UniProtKB:  P40413
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP40413
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
T-COMPLEX PROTEIN 1 SUBUNIT GAMMACA [auth Bg],
E [auth AG],
M [auth Ag],
U [auth BG]
590Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P39077 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P39077
Go to UniProtKB:  P39077
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39077
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
T-COMPLEX PROTEIN 1 SUBUNIT ETADA [auth Bh],
F [auth AH],
N [auth Ah],
V [auth BH]
550Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P42943 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P42943
Go to UniProtKB:  P42943
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42943
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
T-COMPLEX PROTEIN 1 SUBUNIT THETAEA [auth Bq],
G [auth AQ],
O [auth Aq],
W [auth BQ]
568Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P47079 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P47079
Go to UniProtKB:  P47079
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP47079
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
T-COMPLEX PROTEIN 1 SUBUNIT ZETAFA [auth Bz],
H [auth AZ],
P [auth Az],
X [auth BZ]
546Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P39079 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P39079
Go to UniProtKB:  P39079
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39079
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ADP
Query on ADP

Download Ideal Coordinates CCD File
AD [auth Ba]
BB [auth AZ]
CC [auth BA]
DD [auth Bb]
EB [auth Aa]
AD [auth Ba],
BB [auth AZ],
CC [auth BA],
DD [auth Bb],
EB [auth Aa],
FC [auth BB],
GA [auth AA],
GD [auth Bd],
HB [auth Ab],
IC [auth BD],
JA [auth AB],
JD [auth Be],
KB [auth Ad],
LC [auth BE],
MA [auth AD],
MD [auth Bg],
NB [auth Ae],
OC [auth BG],
PA [auth AE],
PD [auth Bh],
QB [auth Ag],
RC [auth BH],
SA [auth AG],
SD [auth Bq],
TB [auth Ah],
UC [auth BQ],
VA [auth AH],
VD [auth Bz],
WB [auth Aq],
XC [auth BZ],
YA [auth AQ],
ZB [auth Az]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
BEF
Query on BEF

Download Ideal Coordinates CCD File
AC [auth Az]
BD [auth Ba]
CB [auth AZ]
DC [auth BA]
ED [auth Bb]
AC [auth Az],
BD [auth Ba],
CB [auth AZ],
DC [auth BA],
ED [auth Bb],
FB [auth Aa],
GC [auth BB],
HA [auth AA],
HD [auth Bd],
IB [auth Ab],
JC [auth BD],
KA [auth AB],
KD [auth Be],
LB [auth Ad],
MC [auth BE],
NA [auth AD],
ND [auth Bg],
OB [auth Ae],
PC [auth BG],
QA [auth AE],
QD [auth Bh],
RB [auth Ag],
SC [auth BH],
TA [auth AG],
TD [auth Bq],
UB [auth Ah],
VC [auth BQ],
WA [auth AH],
WD [auth Bz],
XB [auth Aq],
YC [auth BZ],
ZA [auth AQ]
BERYLLIUM TRIFLUORIDE ION
Be F3
OGIAHMCCNXDTIE-UHFFFAOYSA-K
MG
Query on MG

Download Ideal Coordinates CCD File
AB [auth AQ]
BC [auth Az]
CD [auth Ba]
DB [auth AZ]
EC [auth BA]
AB [auth AQ],
BC [auth Az],
CD [auth Ba],
DB [auth AZ],
EC [auth BA],
FD [auth Bb],
GB [auth Aa],
HC [auth BB],
IA [auth AA],
ID [auth Bd],
JB [auth Ab],
KC [auth BD],
LA [auth AB],
LD [auth Be],
MB [auth Ad],
NC [auth BE],
OA [auth AD],
OD [auth Bg],
PB [auth Ae],
QC [auth BG],
RA [auth AE],
RD [auth Bh],
SB [auth Ag],
TC [auth BH],
UA [auth AG],
UD [auth Bq],
VB [auth Ah],
WC [auth BQ],
XA [auth AH],
XD [auth Bz],
YB [auth Aq],
ZC [auth BZ]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.80 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.248
  • R-Value Observed: 0.248
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 159.1α = 85.23
b = 162.54β = 81.15
c = 268.1γ = 61.17
Software Package:
Software NamePurpose
CNSrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-07-09
    Type: Initial release
  • Version 1.1: 2014-12-10
    Changes: Other
  • Version 1.2: 2019-11-06
    Changes: Data collection, Database references
