Crystal structure of GFP-TAX1BP1 UBZ2 domain fusion protein

Experimental Data Snapshot

  • Resolution: 2.15 Å
  • R-Value Free: 0.298
  • R-Value Work: 0.234
  • R-Value Observed: 0.237

wwPDB Validation   3D Report Full Report

This is version 1.4 of the entry. See complete history


A novel mode of ubiquitin recognition by the ubiquitin-binding zinc finger domain of WRNIP1.

Suzuki, N.Rohaim, A.Kato, R.Dikic, I.Wakatsuki, S.Kawasaki, M.

(2016) FEBS J 283: 2004-2017

  • DOI: https://doi.org/10.1111/febs.13734
  • Primary Citation of Related Structures:
    3VHS, 3VHT, 3WUP, 4Z4K, 4Z4M

  • PubMed Abstract:

    The ubiquitin-binding zinc finger (UBZ) is a type of zinc-coordinating β-β-α fold domain found mainly in proteins involved in DNA repair and transcriptional regulation. Here, we report the crystal structure of the UBZ domain of Y-family DNA polymerase (pol) η and the crystal structure of the complex between the UBZ domain of Werner helicase-interacting protein 1 (WRNIP1) and ubiquitin, crystallized using the GFP fusion technique. In contrast to the pol η UBZ, which has been proposed to bind ubiquitin via its C-terminal α-helix, ubiquitin binds to a novel surface of WRNIP1 UBZ composed of the first β-strand and the C-terminal α-helix. In addition, we report the structure of the tandem UBZ domains of Tax1-binding protein 1 (TAX1BP1) and show that the second UBZ of TAX1BP1 binds ubiquitin, presumably in a manner similar to that of WRNIP1 UBZ. We propose that UBZ domains can be divided into at least two different types in terms of the ubiquitin-binding surfaces: the pol η type and the WRNIP1 type.

  • Organizational Affiliation

    Structural Biology Research Center, Photon Factory, Institute of Materials Structure Science, High Energy Accelerator Research Organization (KEK), Tsukuba, Ibaraki, Japan.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Green fluorescent protein,Tax1-binding protein 1
A, B
260Aequorea victoriaHomo sapiens
This entity is chimeric
Mutation(s): 2
Gene Names: GFPTAX1BP1T6BPPRO0105
UniProt & NIH Common Fund Data Resources
Find proteins for P42212 (Aequorea victoria)
Explore P42212
Go to UniProtKB:  P42212
Find proteins for Q86VP1 (Homo sapiens)
Explore Q86VP1
Go to UniProtKB:  Q86VP1
GTEx:  ENSG00000106052
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP42212Q86VP1
Sequence Annotations
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
Query on CR2
A, B
Experimental Data & Validation

Experimental Data

  • Resolution: 2.15 Å
  • R-Value Free: 0.298
  • R-Value Work: 0.234
  • R-Value Observed: 0.237
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 67.731α = 90
b = 88.773β = 90
c = 91.949γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-04-06
    Type: Initial release
  • Version 1.1: 2016-04-20
    Changes: Database references
  • Version 1.2: 2016-06-22
    Changes: Database references
  • Version 1.3: 2023-09-27
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.4: 2023-11-15
    Changes: Data collection
