4WL6

Raster-scanning protein crystallography using micro and nano-focused synchrotron beams


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.228

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Raster-scanning serial protein crystallography using micro- and nano-focused synchrotron beams.

Coquelle, N.Brewster, A.S.Kapp, U.Shilova, A.Weinhausen, B.Burghammer, M.Colletier, J.P.

(2015) Acta Crystallogr.,Sect.D 71: 1184-1196

  • DOI: 10.1107/S1399004715004514
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • High-resolution structural information was obtained from lysozyme microcrystals (20 µm in the largest dimension) using raster-scanning serial protein crystallography on micro- and nano-focused beamlines at the ESRF. Data were collected at room temper ...

    High-resolution structural information was obtained from lysozyme microcrystals (20 µm in the largest dimension) using raster-scanning serial protein crystallography on micro- and nano-focused beamlines at the ESRF. Data were collected at room temperature (RT) from crystals sandwiched between two silicon nitride wafers, thereby preventing their drying, while limiting background scattering and sample consumption. In order to identify crystal hits, new multi-processing and GUI-driven Python-based pre-analysis software was developed, named NanoPeakCell, that was able to read data from a variety of crystallographic image formats. Further data processing was carried out using CrystFEL, and the resultant structures were refined to 1.7 Å resolution. The data demonstrate the feasibility of RT raster-scanning serial micro- and nano-protein crystallography at synchrotrons and validate it as an alternative approach for the collection of high-resolution structural data from micro-sized crystals. Advantages of the proposed approach are its thriftiness, its handling-free nature, the reduced amount of sample required, the adjustable hit rate, the high indexing rate and the minimization of background scattering.


    Organizational Affiliation

    Université Grenoble Alpes, IBS, 38044 Grenoble, France.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Lysozyme C
A
147Gallus gallusMutation(s): 0
Gene Names: LYZ
EC: 3.2.1.17
Find proteins for P00698 (Gallus gallus)
Go to Gene View: LYZ
Go to UniProtKB:  P00698
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CL
Query on CL

Download SDF File
Download CCD File
A
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.228
  • Space Group: P 43 21 2
Unit Cell:
Length (Å)Angle (°)
a = 77.990α = 90.00
b = 77.990β = 90.00
c = 38.510γ = 90.00
Software Package:
Software NamePurpose
PHASERphasing
PHENIXrefinement
CrystFELdata scaling
CrystFELdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2015-05-06
    Type: Initial release
  • Version 1.1: 2015-05-13
    Type: Database references
  • Version 1.2: 2015-05-20
    Type: Database references
  • Version 1.3: 2016-07-20
    Type: Database references
