4NDK

Crystal structure of a computational designed engrailed homeodomain variant fused with YFP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.190
  • R-Value Observed: 0.193

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Using Molecular Dynamics Simulations as an Aid in the Prediction of Domain Swapping of Computationally Designed Protein Variants.

Mou, Y.Huang, P.S.Thomas, L.M.Mayo, S.L.

(2015) J Mol Biol 427: 2697-2706

  • DOI: 10.1016/j.jmb.2015.06.006
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • In standard implementations of computational protein design, a positive-design approach is used to predict sequences that will be stable on a given backbone structure. Possible competing states are typically not considered, primarily because appropri ...

    In standard implementations of computational protein design, a positive-design approach is used to predict sequences that will be stable on a given backbone structure. Possible competing states are typically not considered, primarily because appropriate structural models are not available. One potential competing state, the domain-swapped dimer, is especially compelling because it is often nearly identical with its monomeric counterpart, differing by just a few mutations in a hinge region. Molecular dynamics (MD) simulations provide a computational method to sample different conformational states of a structure. Here, we tested whether MD simulations could be used as a post-design screening tool to identify sequence mutations leading to domain-swapped dimers. We hypothesized that a successful computationally designed sequence would have backbone structure and dynamics characteristics similar to that of the input structure and that, in contrast, domain-swapped dimers would exhibit increased backbone flexibility and/or altered structure in the hinge-loop region to accommodate the large conformational change required for domain swapping. While attempting to engineer a homodimer from a 51-amino-acid fragment of the monomeric protein engrailed homeodomain (ENH), we had instead generated a domain-swapped dimer (ENH_DsD). MD simulations on these proteins showed increased B-factors derived from MD simulation in the hinge loop of the ENH_DsD domain-swapped dimer relative to monomeric ENH. Two point mutants of ENH_DsD designed to recover the monomeric fold were then tested with an MD simulation protocol. The MD simulations suggested that one of these mutants would adopt the target monomeric structure, which was subsequently confirmed by X-ray crystallography.


    Organizational Affiliation

    Division of Chemistry and Chemical Engineering, California Institute of Technology, Pasadena, CA 91125, USA; Division of Biology and Biological Engineering, California Institute of Technology, Pasadena, CA 91125, USA. Electronic address: steve@mayo.caltech.edu.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
E23P-YFP, GFP-like fluorescent chromoprotein FP506, related, chimeric construct,
A, B
297Aequorea victoriaEimeria acervulina
This entity is chimeric
Mutation(s): 1
Gene Names: GFP
Find proteins for U6GSR1 (Eimeria acervulina)
Go to UniProtKB:  U6GSR1
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
CR2
Query on CR2
A,B
L-PEPTIDE LINKINGC13 H13 N3 O4GLY,TYR,GLY
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.190
  • R-Value Observed: 0.193
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 75.89α = 90
b = 192.65β = 90
c = 107.61γ = 90
Software Package:
Software NamePurpose
BlueIcedata collection
PHENIXmodel building
PHENIXrefinement
MOSFLMdata reduction
SCALAdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2013-10-26
  • Released Date: 2014-11-05
  • Deposition Author(s): Mou, Y., Mayo, S.L.

Revision History

  • Version 1.0: 2014-11-05
    Type: Initial release
  • Version 1.1: 2015-07-15
    Changes: Database references
  • Version 1.2: 2015-08-19
    Changes: Database references
  • Version 1.3: 2017-10-18
    Changes: Advisory, Database references, Source and taxonomy, Structure summary
