4KEX

Crystal structure analysis of a single amino acid deletion mutation in EGFP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.209
  • R-Value Work: 0.182

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structural and dynamic changes associated with beneficial engineered single-amino-acid deletion mutations in enhanced green fluorescent protein.

Arpino, J.A.Rizkallah, P.J.Jones, D.D.

(2014) Acta Crystallogr.,Sect.D 70: 2152-2162

  • DOI: 10.1107/S139900471401267X
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Single-amino-acid deletions are a common part of the natural evolutionary landscape but are rarely sampled during protein engineering owing to limited and prejudiced molecular understanding of mutations that shorten the protein backbone. Single-amino ...

    Single-amino-acid deletions are a common part of the natural evolutionary landscape but are rarely sampled during protein engineering owing to limited and prejudiced molecular understanding of mutations that shorten the protein backbone. Single-amino-acid deletion variants of enhanced green fluorescent protein (EGFP) have been identified by directed evolution with the beneficial effect of imparting increased cellular fluorescence. Biophysical characterization revealed that increased functional protein production and not changes to the fluorescence parameters was the mechanism that was likely to be responsible. The structure EGFP(D190Δ) containing a deletion within a loop revealed propagated changes only after the deleted residue. The structure of EGFP(A227Δ) revealed that a `flipping' mechanism was used to adjust for residue deletion at the end of a β-strand, with amino acids C-terminal to the deletion site repositioning to take the place of the deleted amino acid. In both variants new networks of short-range and long-range interactions are generated while maintaining the integrity of the hydrophobic core. Both deletion variants also displayed significant local and long-range changes in dynamics, as evident by changes in B factors compared with EGFP. Rather than being detrimental, deletion mutations can introduce beneficial structural effects through altering core protein properties, folding and dynamics, as well as function.


    Organizational Affiliation

    School of Biosciences, Cardiff University, Park Place, Cardiff CF10 3AT, Wales.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Green fluorescent protein
A
238Aequorea victoriaMutation(s): 1
Gene Names: GFP
Find proteins for P42212 (Aequorea victoria)
Go to UniProtKB:  P42212
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
CRO
Query on CRO
A
L-PEPTIDE LINKINGC15 H17 N3 O5THR, TYR, GLY
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.209
  • R-Value Work: 0.182
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 51.450α = 90.00
b = 63.140β = 90.00
c = 65.700γ = 90.00
Software Package:
Software NamePurpose
PDB_EXTRACTdata extraction
REFMACrefinement
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-08-06
    Type: Initial release
  • Version 1.1: 2014-09-24
    Type: Database references
  • Version 1.2: 2015-11-25
    Type: Structure summary
