Structure of P22 Large terminase nuclease domain

Experimental Data Snapshot

  • Resolution: 2.02 Å
  • R-Value Free: 0.197
  • R-Value Work: 0.166
  • R-Value Observed: 0.167

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Structure of p22 headful packaging nuclease.

Roy, A.Cingolani, G.

(2012) J Biol Chem 287: 28196-28205

  • DOI: https://doi.org/10.1074/jbc.M112.349894
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Packaging of viral genomes into preformed procapsids requires the controlled and synchronized activity of an ATPase and a genome-processing nuclease, both located in the large terminase (L-terminase) subunit. In this paper, we have characterized the structure and regulation of bacteriophage P22 L-terminase (gp2). Limited proteolysis reveals a bipartite organization consisting of an N-terminal ATPase core flexibly connected to a C-terminal nuclease domain. The 2.02 Å crystal structure of P22 headful nuclease obtained by in-drop proteolysis of full-length L-terminase (FL-L-terminase) reveals a central seven-stranded β-sheet core that harbors two magnesium ions. Modeling studies with DNA suggest that the two ions are poised for two-metal ion-dependent catalysis, but the nuclease DNA binding surface is sterically hindered by a loop-helix (L(1)-α(2)) motif, which is incompatible with catalysis. Accordingly, the isolated nuclease is completely inactive in vitro, whereas it exhibits endonucleolytic activity in the context of FL-L-terminase. Deleting the autoinhibitory L(1)-α(2) motif (or just the loop L(1)) restores nuclease activity to a level comparable with FL-L-terminase. Together, these results suggest that the activity of P22 headful nuclease is regulated by intramolecular cross-talk with the N-terminal ATPase domain. This cross-talk allows for precise and controlled cleavage of DNA that is essential for genome packaging.

  • Organizational Affiliation

    Department of Biochemistry and Molecular Biology, Thomas Jefferson University, Philadelphia, Pennsylvania 19107, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Large terminase protein
A, B, C, D
211Lederbergvirus P22Mutation(s): 0
Gene Names: 2gene 2
Find proteins for P26745 (Salmonella phage P22)
Explore P26745
Go to UniProtKB:  P26745
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP26745
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on SO4

Download Ideal Coordinates CCD File
G [auth A],
J [auth B],
M [auth C],
P [auth D]
O4 S
Query on MG

Download Ideal Coordinates CCD File
E [auth A]
F [auth A]
H [auth B]
I [auth B]
K [auth C]
E [auth A],
F [auth A],
H [auth B],
I [auth B],
K [auth C],
L [auth C],
N [auth D],
O [auth D]
Experimental Data & Validation

Experimental Data

  • Resolution: 2.02 Å
  • R-Value Free: 0.197
  • R-Value Work: 0.166
  • R-Value Observed: 0.167
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.921α = 90
b = 139.795β = 95.1
c = 61.005γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-06-27
    Type: Initial release
  • Version 1.1: 2012-07-04
    Changes: Database references
  • Version 1.2: 2012-08-29
    Changes: Database references
  • Version 1.3: 2023-09-13
    Changes: Data collection, Database references, Derived calculations, Refinement description
