2WJV

Crystal structure of the complex between human nonsense mediated decay factors UPF1 and UPF2

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.200
  • R-Value Observed: 0.203

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

Unusual Bipartite Mode of Interaction between the Nonsense-Mediated Decay Factors, Upf1 and Upf2.

Clerici, M., Mourao, A., Gutsche, I., Gehring, N.H., Hentze, M.W., Kulozik, A., Kadlec, J., Sattler, M., Cusack, S.

(2009) EMBO J 28: 2293

  • DOI: 10.1038/emboj.2009.175
  • Primary Citation of Related Structures:
    2WJV, 2WJY

  • PubMed Abstract:

    • Nonsense-mediated decay (NMD) is a eukaryotic quality control mechanism that degrades mRNAs carrying premature stop codons. In mammalian cells, NMD is triggered when UPF2 bound to UPF3 on a downstream exon junction complex interacts with UPF1 bound to a stalled ribosome ...

    Nonsense-mediated decay (NMD) is a eukaryotic quality control mechanism that degrades mRNAs carrying premature stop codons. In mammalian cells, NMD is triggered when UPF2 bound to UPF3 on a downstream exon junction complex interacts with UPF1 bound to a stalled ribosome. We report structural studies on the interaction between the C-terminal region of UPF2 and intact UPF1. Crystal structures, confirmed by EM and SAXS, show that the UPF1 CH-domain is docked onto its helicase domain in a fixed configuration. The C-terminal region of UPF2 is natively unfolded but binds through separated alpha-helical and beta-hairpin elements to the UPF1 CH-domain. The alpha-helical region binds sixfold more weakly than the beta-hairpin, whereas the combined elements bind 80-fold more tightly. Cellular assays show that NMD is severely affected by mutations disrupting the beta-hairpin binding, but not by those only affecting alpha-helix binding. We propose that the bipartite mode of UPF2 binding to UPF1 brings the ribosome and the EJC in close proximity by forming a tight complex after an initial weak encounter with either element.

    Organizational Affiliation:

    European Molecular Biology Laboratory, Grenoble Outstation, Grenoble Cedex 9, France.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
REGULATOR OF NONSENSE TRANSCRIPTS 1A, B800Homo sapiensMutation(s): 0
Gene Names: UPF1, KIAA0221, RENT1
EC: 3.6.1 (PDB Primary Data), 3.6.4.12 (UniProt), 3.6.4.13 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q92900 (Homo sapiens)
Explore Q92900
Go to UniProtKB:  Q92900
PHAROS:  Q92900
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ92900
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
REGULATOR OF NONSENSE TRANSCRIPTS 2C [auth D],
D [auth E]		97Homo sapiensMutation(s): 0
Gene Names: UPF2, KIAA1408, RENT2
UniProt
Find proteins for Q9HAU5 (Homo sapiens)
Explore Q9HAU5
Go to UniProtKB:  Q9HAU5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9HAU5
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4
Download Ideal Coordinates CCD File
AA [auth B],
BA [auth B],
CA [auth B],
DA [auth B],
EA [auth B],
AA [auth B],
BA [auth B],
CA [auth B],
DA [auth B],
EA [auth B],
FA [auth B],
GA [auth B],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
R [auth A],
S [auth A],
T [auth A],
X [auth B],
Y [auth B],
Z [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L		 Ligand Interaction
ZN
Query on ZN
Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
G [auth A],
U [auth B],
V [auth B],
E [auth A],
F [auth A],
G [auth A],
U [auth B],
V [auth B],
W [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.200
  • R-Value Observed: 0.203
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 92.41α = 90
b = 97.29β = 102.38
c = 124.6γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-07-07
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Refinement description, Version format compliance
