2IUC | pdb_00002iuc

Structure of alkaline phosphatase from the Antarctic bacterium TAB5


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free:
    0.225 (Depositor), 0.226 (DCC)
  • R-Value Work:
    0.162 (Depositor), 0.164 (DCC)
  • R-Value Observed:
    0.165 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2IUC

This is version 1.5 of the entry. See complete history

Literature

Crystal Structure of Alkaline Phosphatase from the Antarctic Bacterium Tab5.

Wang, E.Koutsioulis, D.Leiros, H.K.S.Andersen, O.A.Bouriotis, V.Hough, E.Heikinheimo, P.

(2007) J Mol Biology 366: 1318

  • DOI: https://doi.org/10.1016/j.jmb.2006.11.079
  • Primary Citation Related Structures:
    2IUC

  • PubMed Abstract:

    Alkaline phosphatases (APs) are non-specific phosphohydrolases that are widely used in molecular biology and diagnostics. We describe the structure of the cold active alkaline phosphatase from the Antarctic bacterium TAB5 (TAP). The fold and the active site geometry are conserved with the other AP structures, where the monomer has a large central beta-sheet enclosed by alpha-helices. The dimer interface of TAP is relatively small, and only a single loop from each monomer replaces the typical crown domain. The structure also has typical cold-adapted features; lack of disulfide bridges, low number of salt-bridges, and a loose dimer interface that completely lacks charged interactions. The dimer interface is more hydrophobic than that of the Escherichia coli AP and the interactions have tendency to pair with backbone atoms, which we propose to result from the cold adaptation of TAP. The structure contains two additional magnesium ions outside of the active site, which we believe to be involved in substrate binding as well as contributing to the local stability. The M4 site stabilises an interaction that anchors the substrate-coordinating R148. The M5 metal-binding site is in a region that stabilises metal coordination in the active site. In other APs the M5 binding area is supported by extensive salt-bridge stabilisation, as well as positively charged patches around the active site. We propose that these charges, and the TAP M5 binding, influence the release of the product phosphate and thus might influence the rate-determining step of the enzyme.


  • Organizational Affiliation
    • Institutt for Kjemi, University of Tromsø, N-9037 Tromsø, Norway.

Macromolecule Content

  • Total Structure Weight: 81.2 kDa
  • Atom Count: 5,544
  • Modeled Residue Count: 682
  • Deposited Residue Count: 750
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ALKALINE PHOSPHATASE375Antarctic bacterium TAB5Mutation(s): 0
EC: 3.1.3.1
UniProt
Find proteins for Q9KWY4 (Antarctic bacterium TAB5)
Explore Q9KWY4
Go to UniProtKB:  Q9KWY4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9KWY4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
ALKALINE PHOSPHATASE375Antarctic bacterium TAB5Mutation(s): 0
EC: 3.1.3.1
UniProt
Find proteins for Q9KWY4 (Antarctic bacterium TAB5)
Explore Q9KWY4
Go to UniProtKB:  Q9KWY4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9KWY4
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CAC

Query on CAC



Download:Ideal Coordinates CCD File
N [auth B]CACODYLATE ION
C2 H6 As O2
OGGXGZAMXPVRFZ-UHFFFAOYSA-M
PO4

Query on PO4



Download:Ideal Coordinates CCD File
H [auth A],
O [auth B]
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
ZN

Query on ZN



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A],
I [auth B],
J [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
E [auth A]
F [auth A]
G [auth A]
K [auth B]
L [auth B]
E [auth A],
F [auth A],
G [auth A],
K [auth B],
L [auth B],
M [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free:  0.225 (Depositor), 0.226 (DCC)
  • R-Value Work:  0.162 (Depositor), 0.164 (DCC)
  • R-Value Observed: 0.165 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.043α = 90
b = 173.184β = 90
c = 55.34γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-11-28
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2019-04-03
    Changes: Advisory, Data collection, Experimental preparation, Other
  • Version 1.4: 2019-05-29
    Changes: Data collection, Experimental preparation
  • Version 1.5: 2023-12-13
    Changes: Advisory, Data collection, Database references, Derived calculations, Other, Refinement description
