1ZSZ

Crystal structure of a computationally designed SspB heterodimer


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.231

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Specificity versus stability in computational protein design.

Bolon, D.N.Grant, R.A.Baker, T.A.Sauer, R.T.

(2005) Proc.Natl.Acad.Sci.Usa 102: 12724-12729

  • DOI: 10.1073/pnas.0506124102

  • PubMed Abstract:
  • Protein-protein interactions can be designed computationally by using positive strategies that maximize the stability of the desired structure and/or by negative strategies that seek to destabilize competing states. Here, we compare the efficacy of t ...

    Protein-protein interactions can be designed computationally by using positive strategies that maximize the stability of the desired structure and/or by negative strategies that seek to destabilize competing states. Here, we compare the efficacy of these methods in reengineering a protein homodimer into a heterodimer. The stability-design protein (positive design only) was experimentally more stable than the specificity-design heterodimer (positive and negative design). By contrast, only the specificity-design protein assembled as a homogenous heterodimer in solution, whereas the stability-design protein formed a mixture of homodimer and heterodimer species. The experimental stabilities of the engineered proteins correlated roughly with their calculated stabilities, and the crystal structure of the specificity-design heterodimer showed most of the predicted side-chain packing interactions and a main-chain conformation indistinguishable from the wild-type structure. These results indicate that the design simulations capture important features of both stability and structure and demonstrate that negative design can be critical for attaining specificity when competing states are close in structure space.


    Organizational Affiliation

    Department of Biology, Massachusetts Institute of Technology, Cambridge, MA 02139, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Stringent starvation protein B homolog
A
110Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd)Mutation(s): 0
Gene Names: sspB
Find proteins for P45206 (Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd))
Go to UniProtKB:  P45206
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Stringent starvation protein B homolog
B
111Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd)Mutation(s): 3
Gene Names: sspB
Find proteins for P45206 (Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd))
Go to UniProtKB:  P45206
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Stringent starvation protein B homolog
C
129Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd)Mutation(s): 5
Gene Names: sspB
Find proteins for P45206 (Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd))
Go to UniProtKB:  P45206
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download SDF File
Download CCD File
A, B, C
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.231
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 120.004α = 90.00
b = 61.036β = 110.87
c = 62.385γ = 90.00
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
AMoREphasing
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2005-08-23
    Type: Initial release
  • Version 1.1: 2008-04-30
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
