1Y19

Structural basis for phosphatidylinositol phosphate kinase type I-gamma binding to talin at focal adhesions


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.253
  • R-Value Observed: 0.253

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structural bases for phosphatidylinositol phosphate kinase type I-gamma binding to talin at focal adhesions

de Pereda, J.M.Wegener, K.Santelli, E.Bate, N.Ginsberg, M.H.Critchley, D.R.Campbell, I.D.Liddington, R.C.

(2005) J Biol Chem 280: 8381-8386

  • DOI: 10.1074/jbc.M413180200
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • The cytoskeletal protein talin binds to a short C-terminal sequence in phosphatidylinositol phosphate kinase type Igamma (PIPKIgamma), activating the enzyme and promoting the local production of phosphatidylinositol 4,5 bisphosphate, which regulates ...

    The cytoskeletal protein talin binds to a short C-terminal sequence in phosphatidylinositol phosphate kinase type Igamma (PIPKIgamma), activating the enzyme and promoting the local production of phosphatidylinositol 4,5 bisphosphate, which regulates focal adhesion dynamics as well as clathrin-mediated endocytosis in neuronal cells. Here we show by crystallographic, NMR, and calorimetric analysis that the phosphotyrosine binding (PTB)-like domain of talin engages the PIPKIgamma C terminus in a mode very similar to that of integrin binding. However, PIPKIgamma binds in the canonical PTB-peptide mode with an SPLH motif replacing the classic NPXY motif. The tighter packing of the SPLH motif against the hydrophobic core of talin may explain the stronger binding of PIPKIgamma. Two tyrosine residues flanking the SPLH motif (Tyr-644 and Tyr-649) have been implicated in the regulation of talin binding. We show that phosphorylation at Tyr-644, a Src phosphorylation site in vivo, has little effect on the binding mode or strength, which is consistent with modeling studies in which the phosphotyrosine makes surface-exposed salt bridges, and we suggest that its strong activating effect arises from the release of autoinhibitory restraints in the full-length PIPKIgamma. Modeling studies suggest that phosphorylation of Tyr-649 will likewise have little effect on talin binding, whereas phosphorylation of the SPLH serine is predicted to be strongly disruptive. Our data are consistent with the proposal that Src activity promotes a switch from integrin binding to PIPKIgamma binding that regulates focal adhesion turnover.


    Organizational Affiliation

    Program on Cell Adhesion, The Burnham Institute, La Jolla, California 92037, USA.



Macromolecules
  • Find similar proteins by: Sequence   |   Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Phosphatidylinositol-4-phosphate 5-kinase, type 1 gamma
A, C, E, G, I, K
14Mus musculusMutation(s): 0
Gene Names: Pip5k1cKiaa0589
EC: 2.7.1.68
Find proteins for O70161 (Mus musculus)
Go to UniProtKB:  O70161
NIH Common Fund Data Resources

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Talin 1
B, D, F, H, J, L
202Mus musculusMutation(s): 0
Gene Names: Tln1Tln
Find proteins for P26039 (Mus musculus)
Go to UniProtKB:  P26039
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.253
  • R-Value Observed: 0.253
  • Space Group: P 32
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 118.102α = 90
b = 118.102β = 90
c = 93.308γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing
CNSrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2005-01-04
    Type: Initial release
  • Version 1.1: 2008-05-05
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2016-11-30
    Changes: Other
