9ITI | pdb_00009iti

Nav1.7 with mutations that eliminate beta1 binding

PDB DOI: https://doi.org/10.2210/pdb9ITI/pdb
EM Map EMD-60867: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes
Membrane Protein: Yes MemProtMD

Deposited: 2024-07-20 Released: 2025-08-20
Deposition Author(s): Yan, N., Li, Z., Wu, T.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.92 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Critical role of extracellular loops in differential modulations of TTX-sensitive and TTX-resistant Na v channels.

Wu, T., Yang, X., Jin, X., Yan, N., Li, Z.

(2025) Proc Natl Acad Sci U S A 122: e2510355122-e2510355122

PubMed: 40768348 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1073/pnas.2510355122
Primary Citation Related Structures:
9ITH, 9ITI

PubMed Abstract:
The cardiac voltage-gated sodium channel Na _v1.5 is resistant to tetrodotoxin (TTXr). Here, we report a cryo-electron microscopy (cryo-EM) structure of wild-type human Na _v1.5, coexpressed with the β1 auxiliary subunit and treated with high-concentration TTX, at 3.4 Å resolution. Structural comparison reveals the molecular determinants for the distinct responses to TTX as well as β subunits between TTXr and TTX-sensitive (TTXs) Na _v channels. A conserved cation-π interaction between the guanidinium group of TTX and Tyr or Phe on the P2 _I helix in TTXs Na _v channels is lost in all TTXr subtypes owing to the replacement by Cys/Ser at the corresponding locus, explaining their differential TTX sensitivities. The β1 subunit is invisible in the EM map. Comparison of Na _v1.5 with Na _v1.7 and Na _v1.8, which are, respectively, TTXs and TTXr, identifies four sites on the extracellular loops (ECLs) that may account for their different β1-binding abilities. When the corresponding residues in TTXs Na _v1.7 are replaced with those from Na _v1.5, the modulatory effects of β1 on channel activation and inactivation are diminished. Consistently, β1 is absent in the 3D EM reconstruction of this Na _v1.7 mutant. Together with our previous structure-guided discovery that TTXr channels lack a Cys on the ECL _II for disulfide bond formation with β2 or β4, the structure-function relationship studies underscore the importance of the ECLs in the mechanistic distinctions between TTXs and TTXr Na _v channels. The ECLs may be further explored for the development of subtype-specific drugs.

Organizational Affiliation

State Key Laboratory of Membrane Biology, Beijing Advanced Innovation Center for Structural Biology, Tsinghua-Peking Joint Center for Life Sciences, School of Life Sciences, Tsinghua University, Beijing 100084, China.

Macromolecule Content

Total Structure Weight: 245.99 kDa
Atom Count: 11,086
Modeled Residue Count: 1,268
Deposited Residue Count: 2,030
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sodium channel protein type 9 subunit alpha	A	2,030	Homo sapiens	Mutation(s): 11 Gene Names: SCN9A, NENA Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q15858 (Homo sapiens) Explore Q15858 Go to UniProtKB: Q15858
PHAROS: Q15858 GTEx: ENSG00000169432
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q15858
Glycosylation
Glycosylation Sites: 4	Glycosylation Focus chain A	Go to GlyGen: Q15858-1
