9ZGL | pdb_00009zgl

Ancestrally reconstructed acetolactate synthase - Ancestor N259 with bound ThDP and magnesium.

PDB DOI: https://doi.org/10.2210/pdb9ZGL/pdb

Classification: TRANSFERASE
Organism(s): synthetic construct
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-12-03 Released: 2025-12-17
Deposition Author(s): Douw, A., Guddat, L.W.
Funding Organization(s): Australian Research Council (ARC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.99 Å
R-Value Free:
0.255 (Depositor), 0.257 (DCC)
R-Value Work:
0.195 (Depositor), 0.195 (DCC)
R-Value Observed:
0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Engineering of Acetolactate Synthase for Isobutanol Production Using Ancestral Sequence Reconstruction

Douw, A., Krco, S., Bayaraa, T., Foley, G., Davis, S.J., Paredes Trujillo, O., Asser, L., Sieber, V., Boden, M., Hine, D., Guddat, L., Schenk, G.

To be published.

Macromolecule Content

Total Structure Weight: 247.89 kDa
Atom Count: 16,389
Modeled Residue Count: 2,156
Deposited Residue Count: 2,288
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ancestral acetolactate synthase, catabolic	A, B, C, D	572	synthetic construct	Mutation(s): 0 EC: 2.2.1.6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TPP (Subject of Investigation/LOI) Query on TPP Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain G [auth B] SDF format, chain I [auth C] SDF format, chain K [auth D] MOL2 format, chain E [auth A] MOL2 format, chain G [auth B] MOL2 format, chain I [auth C] MOL2 format, chain K [auth D] mmCIF format, chain E [auth A] mmCIF format, chain G [auth B] mmCIF format, chain I [auth C] mmCIF format, chain K [auth D]	E [auth A], G [auth B], I [auth C], K [auth D]	THIAMINE DIPHOSPHATE C₁₂ H₁₉ N₄ O₇ P₂ S AYEKOFBPNLCAJY-UHFFFAOYSA-O		Interactions Focus chain E [auth A] Focus chain G [auth B] Focus chain I [auth C] Focus chain K [auth D] Interactions & Density Focus chain E [auth A] Focus chain G [auth B] Focus chain I [auth C] Focus chain K [auth D]
MG (Subject of Investigation/LOI) Query on MG Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain H [auth B] SDF format, chain J [auth C] SDF format, chain L [auth D] MOL2 format, chain F [auth A] MOL2 format, chain H [auth B] MOL2 format, chain J [auth C] MOL2 format, chain L [auth D] mmCIF format, chain F [auth A] mmCIF format, chain H [auth B] mmCIF format, chain J [auth C] mmCIF format, chain L [auth D]	F [auth A], H [auth B], J [auth C], L [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain H [auth B] Focus chain J [auth C] Focus chain L [auth D] Interactions & Density Focus chain F [auth A] Focus chain H [auth B] Focus chain J [auth C] Focus chain L [auth D]
