9YKP | pdb_00009ykp

HIV-1 Protease WT (NL4-3) with Inhibitor NR01-141


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.96 Å
  • R-Value Free:
    0.227 (Depositor), 0.228 (DCC)
  • R-Value Work:
    0.181 (Depositor), 0.180 (DCC)
  • R-Value Observed:
    0.183 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Fluorinated HIV-1 protease inhibitors containing chiral hydroxyethylbenzene and indanol as P2' ligands with potent activity against drug-resistant variants.

Kaur, J.Spielvogel, E.Nageswara Rao, D.Rusere, L.N.Shaqra, A.M.Lockbaum, G.J.Maryam, A.Yilmaz, N.K.Swanstrom, R.Schiffer, C.A.Ali, A.

(2025) Eur J Med Chem 304: 118510-118510

  • DOI: https://doi.org/10.1016/j.ejmech.2025.118510
  • Primary Citation of Related Structures:
    9PYX, 9PZ1, 9Q0T, 9Q13, 9Q1C, 9Q1P, 9Q3P, 9Q3T, 9Q5D, 9YKP, 9YRA, 9YRR, 9YRY

  • PubMed Abstract:

    HIV-1 protease inhibitors are potent antiretroviral drugs, but their efficacy is often undermined by poor pharmacokinetics and drug resistance. Here, we employed a structure-guided design strategy to improve the potency and resistance profile of HIV-1 protease inhibitors by optimizing hydrogen bonding and van der Waals interactions within the protease substrate envelope. A series of darunavir analogs were designed by incorporating chiral 4-(1-hydroxyethyl)benzene and 1-indanol moieties as P2' ligands, in combination with P1 fluorination. The resulting compounds showed distinct potency profiles depending on the conformational flexibility of the P2' hydroxyl group. Notably, the P1 fluorinated compounds exhibited excellent antiviral potency against highly drug-resistant HIV-1 variants. Analysis of the protease-inhibitor cocrystal structures revealed that, similar to the 4-(1-hydroxyethyl)benzene moiety, both stereoisomers of the 1-indanol moiety make direct hydrogen bonding interactions with the backbone NH of Asp30'. To maintain polar interactions in the S2' subsite of HIV-1 protease, the orientation of the (R)-indanol moiety was flipped relative to the (S)-1-indanol moiety. The SAR data and structural analysis offer insights for further optimization to improve potency against drug-resistant HIV-1 variants.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biotechnology, University of Massachusetts Chan Medical School, Worcester, MA, 01605, United States.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ProteaseA [auth B],
B [auth A]
99Human immunodeficiency virus 1Mutation(s): 0
Gene Names: gag-pol
EC: 3.4.23.16
UniProt
Find proteins for P03367 (Human immunodeficiency virus type 1 group M subtype B (isolate BRU/LAI))
Explore P03367
Go to UniProtKB:  P03367
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03367
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.96 Å
  • R-Value Free:  0.227 (Depositor), 0.228 (DCC)
  • R-Value Work:  0.181 (Depositor), 0.180 (DCC)
  • R-Value Observed: 0.183 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.029α = 90
b = 58.508β = 90
c = 62.116γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data scaling
PHASERphasing
Cootmodel building

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesP01-GM109767

Revision History  (Full details and data files)

  • Version 1.0: 2025-12-24
    Type: Initial release
  • Version 1.1: 2025-12-31
    Changes: Database references
  • Version 1.2: 2026-01-07
    Changes: Database references
