9KPX | pdb_00009kpx

UDP-glycosyltransferase TsUGT1 with UDP and 3-Glc-30-S-Glc-GA

PDB DOI: https://doi.org/10.2210/pdb9KPX/pdb

Classification: TRANSFERASE
Organism(s): Trifolium subterraneum
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-11-24 Released: 2025-11-26
Deposition Author(s): Feng, X., Sun, Q., Meng, L.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.30 Å
R-Value Free:
0.209 (Depositor), 0.210 (DCC)
R-Value Work:
0.155 (Depositor), 0.156 (DCC)
R-Value Observed:
0.158 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Investigation of the bond cleavage mechanism of UDP-glycosyltransferase

Feng, X., Sun, Q., Meng, L.

To be published.

Macromolecule Content

Total Structure Weight: 217.37 kDa
Atom Count: 15,284
Modeled Residue Count: 1,884
Deposited Residue Count: 1,884
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycosyltransferase	A, B, C, D	471	Trifolium subterraneum	Mutation(s): 0 Gene Names: TSUD_196840 EC: 2.4.1
UniProt
Find proteins for A0A2Z6NA72 (Trifolium subterraneum) Explore A0A2Z6NA72 Go to UniProtKB: A0A2Z6NA72
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A2Z6NA72
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1L68 (Subject of Investigation/LOI) Query on A1L68 Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain I [auth B] SDF format, chain Q [auth D] SDF format, chain M [auth C] MOL2 format, chain E [auth A] MOL2 format, chain I [auth B] MOL2 format, chain Q [auth D] MOL2 format, chain M [auth C] mmCIF format, chain E [auth A] mmCIF format, chain I [auth B] mmCIF format, chain Q [auth D] mmCIF format, chain M [auth C]	E [auth A], I [auth B], M [auth C], Q [auth D]	(2~{S},4~{a}~{S},6~{a}~{R},6~{a}~{S},6~{b}~{R},8~{a}~{R},10~{S},12~{a}~{R},14~{b}~{R})-2,4~{a},6~{a},6~{b},9,9,12~{a}-heptamethyl-10-oxidanyl-13-oxidanylidene-3,4,5,6,6~{a},7,8,8~{a},10,11,12,14~{b}-dodecahydro-1~{H}-picene-2-carbothioic S-acid C₃₀ H₄₆ O₃ S SOGZTSGQAUOWBG-ZEYMVYSOSA-N		Interactions Focus chain E [auth A] Focus chain I [auth B] Focus chain M [auth C] Focus chain Q [auth D] Interactions & Density Focus chain E [auth A] Focus chain I [auth B] Focus chain M [auth C] Focus chain Q [auth D]
UDP Query on UDP Download Ideal Coordinates CCD File SDF format, chain L [auth B] SDF format, chain P [auth C] SDF format, chain T [auth D] SDF format, chain H [auth A] MOL2 format, chain L [auth B] MOL2 format, chain P [auth C] MOL2 format, chain T [auth D] MOL2 format, chain H [auth A] mmCIF format, chain L [auth B] mmCIF format, chain P [auth C] mmCIF format, chain T [auth D] mmCIF format, chain H [auth A]	H [auth A], L [auth B], P [auth C], T [auth D]	URIDINE-5'-DIPHOSPHATE C₉ H₁₄ N₂ O₁₂ P₂ XCCTYIAWTASOJW-XVFCMESISA-N		Interactions Focus chain H [auth A] Focus chain L [auth B] Focus chain P [auth C] Focus chain T [auth D] Interactions & Density Focus chain H [auth A] Focus chain L [auth B] Focus chain P [auth C] Focus chain T [auth D]
BMA (Subject of Investigation/LOI) Query on BMA Download Ideal Coordinates CCD File SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain O [auth C] SDF format, chain R [auth D] SDF format, chain S [auth D] SDF format, chain N [auth C] SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain O [auth C] MOL2 format, chain R [auth D] MOL2 format, chain S [auth D] MOL2 format, chain N [auth C] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain O [auth C] mmCIF format, chain R [auth D] mmCIF format, chain S [auth D] mmCIF format, chain N [auth C] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A] G [auth A] J [auth B] K [auth B] N [auth C] F [auth A], G [auth A], J [auth B], K [auth B], N [auth C], O [auth C], R [auth D], S [auth D]	beta-D-mannopyranose C₆ H₁₂ O₆ WQZGKKKJIJFFOK-RWOPYEJCSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain R [auth D] Focus chain S [auth D] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain R [auth D] Focus chain S [auth D]
