9KAU | pdb_00009kau

Three-dimensional structure of homo-dimer of cystathione beta lyase/PLP/+L-alliin complex from Bacillus cereus(BcPatB)

PDB DOI: https://doi.org/10.2210/pdb9KAU/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Bacillus cereus ATCC 14579
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2024-10-29 Released: 2024-11-20
Deposition Author(s): Liu, Y., Yang, C.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.88 Å
R-Value Free:
0.393 (Depositor), 0.405 (DCC)
R-Value Work:
0.359 (Depositor), 0.361 (DCC)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9KAU

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Homodimer of cystatohinine beta lyase PatB/PLP/L-(+)-alliin complex from Bacillus cereus(NCBI Reference Sequence: WP_001974105.1)

Liu, Y., Yang, C.

To be published.

Macromolecule Content

Total Structure Weight: 88.96 kDa
Atom Count: 6,217
Modeled Residue Count: 750
Deposited Residue Count: 766
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
cysteine-S-conjugate beta-lyase	A, B	383	Bacillus cereus ATCC 14579	Mutation(s): 13 Gene Names: BK746_00885 EC: 4.4.1.13
UniProt
Find proteins for A0A9X7GT53 (Bacillus cereus) Explore A0A9X7GT53 Go to UniProtKB: A0A9X7GT53
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A9X7GT53
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
OO0 Query on OO0 Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	ALLIIN C₆ H₁₁ N O₃ S XUHLIQGRKRUKPH-ULHQUTTKSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
LLP Query on LLP	A, B	L-PEPTIDE LINKING	C₁₄ H₂₂ N₃ O₇ P		LYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.88 Å
R-Value Free: 0.393 (Depositor), 0.405 (DCC)
R-Value Work: 0.359 (Depositor), 0.361 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.223	α = 90
b = 85.522	β = 91.12
c = 168.077	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-11-20

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	Project no. 42077214

Revision History (Full details and data files)

Version 1.0: 2024-11-20
Type: Initial release
