9J25 | pdb_00009j25

Structural basis of the bifunctionality of M. salinexigens ZYF650T glucosylglycerol phosphorylase in glucosylglycerol catabolism


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.74 Å
  • R-Value Free:
    0.260 (Depositor), 0.260 (DCC)
  • R-Value Work:
    0.222 (Depositor), 0.226 (DCC)
  • R-Value Observed:
    0.224 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Structural basis of the bifunctionality of Marinobacter salinexigens ZYF650 T glucosylglycerol phosphorylase in glucosylglycerol catabolism.

Lu, D.Zhang, K.Cheng, C.Wu, D.Yin, L.Luo, Q.Shi, M.Ma, H.Lu, X.

(2025) J Biological Chem 301: 108127-108127

  • DOI: https://doi.org/10.1016/j.jbc.2024.108127
  • Primary Citation of Related Structures:
    9J1U, 9J22, 9J24, 9J25

  • PubMed Abstract:

    2-O-α-Glucosylglycerol (GG) is a natural heteroside synthesized by many cyanobacteria and a few heterotrophic bacteria under salt stress conditions. Bacteria produce GG in response to stimuli and degrade it once the stimulus diminishes. Heterotrophic bacteria utilize GG phosphorylase (GGP), a member of the GH13_18 family, via a two-step process consisting of phosphorolysis and hydrolysis for GG catabolism. However, the precise mechanism by which GGP degrades GG remains elusive. We determined the 3D structure of a recently identified GGP (MsGGP) of the deep-sea bacterium Marinobacter salinexigens ZYF650 T , in complex with glucose and glycerol, α-d-glucose-1-phosphate (αGlc1-P), and orthophosphate (inorganic phosphate) at resolutions of 2.5, 2.7, and 2.7 Å, respectively. Notably, the first αGlc1-P complex structure in the GH13_18 family, the complex of MsGGP and αGlc1-P, validates that GGP catalyzes GG decomposition through consecutive phosphorolysis and hydrolysis. In addition, the structure reveals the mechanism of high stereoselectivity on αGlc1-P. Glu231 and Asp190 were identified as the catalytic residues. Interestingly, these structures closely resemble each other, indicating minimal conformational changes upon binding end-product glucose and glycerol, or the intermediate αGlc1-P. The structures also indicate that the substrates may follow a specific trajectory and a precise order toward the active center in close proximity and in a geometrically favorable orientation for catalysis in a double displacement mechanism.


  • Organizational Affiliation
    • School of Chemical Engineering, Marine and Life Sciences, Dalian University of Technology, Panjin, China; Key Laboratory of Biofuels, Qingdao Institute of Bioenergy and Bioprocess Technology, Chinese Academy of Sciences, Qingdao, China.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Sucrose phosphorylase
A, B, C
480Marinobacter salinexigensMutation(s): 0
Gene Names: gtfAFWJ25_14990
EC: 2.4.1.7
UniProt
Find proteins for A0A5B0VBK8 (Marinobacter salinexigens)
Explore A0A5B0VBK8
Go to UniProtKB:  A0A5B0VBK8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5B0VBK8
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TRS
Query on TRS

Download Ideal Coordinates CCD File
E [auth A]2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
PEG
Query on PEG

Download Ideal Coordinates CCD File
D [auth A]DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
G [auth A],
J [auth C]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
PO4 (Subject of Investigation/LOI)
Query on PO4

Download Ideal Coordinates CCD File
F [auth A],
H [auth B],
I [auth C]
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.74 Å
  • R-Value Free:  0.260 (Depositor), 0.260 (DCC)
  • R-Value Work:  0.222 (Depositor), 0.226 (DCC)
  • R-Value Observed: 0.224 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 107.244α = 90
b = 176.117β = 90
c = 177.369γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China32271358

Revision History  (Full details and data files)

  • Version 1.0: 2025-09-03
    Type: Initial release
