9HQ3 | pdb_00009hq3

Crystal structure of human carbonic anhydrase II in complex with N-(2-(benzylamino)-2-oxo-1-(4-sulfamoylphenyl)ethyl)-N-(3-chloro-4-methoxyphenyl)-3-(trimethylsilyl)propiolamide

• PDB DOI: https://doi.org/10.2210/pdb9HQ3/pdb

• Classification: LYASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2024-12-16 Released: 2025-12-24
• Deposition Author(s): Angeli, A., Ferraroni, M.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:
  0.185 (Depositor), 0.189 (DCC)
• R-Value Work:
  0.161 (Depositor), 0.169 (DCC)

Starting Model: experimental

Literature

Crystal structure of human carbonic anhydrase II in complex with N-(2-(benzylamino)-2-oxo-1-(4-sulfamoylphenyl)ethyl)-N-(3-chloro-4-methoxyphenyl)-3-(trimethylsilyl)propiolamide

Angeli, A., Ferraroni, M.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 30 kDa
• Atom Count: 2,327
• Modeled Residue Count: 258
• Deposited Residue Count: 260
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carbonic anhydrase 2	A [auth AAA]	260	Homo sapiens	Mutation(s): 0  Gene Names: CA2 EC: 4.2.1.1 (PDB Primary Data), 4.2.1.69 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P00918 (Homo sapiens) Explore P00918  Go to UniProtKB:  P00918
PHAROS:  P00918 GTEx:  ENSG00000104267

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
A1IWY (Subject of Investigation/LOI)	D [auth AAA]	~{N}-(3-chloranyl-4-methoxy-phenyl)-~{N}-[(1~{S})-2-oxidanylidene-2-[(phenylmethyl)amino]-1-(4-sulfamoylphenyl)ethyl]-3-trimethylsilyl-prop-2-ynamide C28 H30 Cl N3 O5 S Si SCSIQQONVAYEDI-HHHXNRCGSA-N
ZN	C [auth AAA]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
EDO	B [auth AAA]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:  0.185 (Depositor), 0.189 (DCC)
• R-Value Work:  0.161 (Depositor), 0.169 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.393	α = 90
b = 41.493	β = 104.414
c = 72.309	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
REFMAC	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2025-12-24
Deposition Author(s): Angeli, A., Ferraroni, M.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2025-12-24
  Type: Initial release
