9GCJ | pdb_00009gcj

The crystal structure of beta-glucosidase from the thermophilic bacterium Caldicellulosiruptor saccharolyticus in complex with beta-D-glucose determined at 1.95 A resolution

PDB DOI: https://doi.org/10.2210/pdb9GCJ/pdb

Classification: HYDROLASE
Organism(s): Caldicellulosiruptor saccharolyticus DSM 8903
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2024-08-01 Released: 2024-10-16
Deposition Author(s): Chrysina, E.D., Sotiropoulou, A.I.
Funding Organization(s): Other government, European Commission

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free:
0.207 (Depositor), 0.211 (DCC)
R-Value Work:
0.171 (Depositor), 0.175 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Structural studies of beta-glucosidase from the thermophilic bacterium Caldicellulosiruptor saccharolyticus.

Sotiropoulou, A.I., Hatzinikolaou, D.G., Chrysina, E.D.

(2024) Acta Crystallogr D Struct Biol 80: 733-743

PubMed: 39361356 Search on PubMedSearch on PubMed Central
DOI: https://doi.org/10.1107/S2059798324009252
Primary Citation of Related Structures:
9GCI, 9GCJ

PubMed Abstract:
β-Glucosidase from the thermophilic bacterium Caldicellulosiruptor saccharolyticus (Bgl1) has been denoted as having an attractive catalytic profile for various industrial applications. Bgl1 catalyses the final step of in the decomposition of cellulose, an unbranched glucose polymer that has attracted the attention of researchers in recent years as it is the most abundant renewable source of reduced carbon in the biosphere. With the aim of enhancing the thermostability of Bgl1 for a broad spectrum of biotechnological processes, it has been subjected to structural studies. Crystal structures of Bgl1 and its complex with glucose were determined at 1.47 and 1.95 Å resolution, respectively. Bgl1 is a member of glycosyl hydrolase family 1 (GH1 superfamily, EC 3.2.1.21) and the results showed that the 3D structure of Bgl1 follows the overall architecture of the GH1 family, with a classical (β/α) ₈ TIM-barrel fold. Comparisons of Bgl1 with sequence or structural homologues of β-glucosidase reveal quite similar structures but also unique structural features in Bgl1 with plausible functional roles.

Organizational Affiliation

Institute of Chemical Biology, National Hellenic Research Foundation, 48 Vassileos Constantinou Avenue, 116 35 Athens, Greece.

Macromolecule Content

Total Structure Weight: 109.33 kDa
Atom Count: 8,058
Modeled Residue Count: 911
Deposited Residue Count: 922
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
beta-glucosidase	A, B	461	Caldicellulosiruptor saccharolyticus DSM 8903	Mutation(s): 0 Gene Names: Csac_1089 EC: 3.2.1.21
UniProt
Find proteins for A4XIG7 (Caldicellulosiruptor saccharolyticus (strain ATCC 43494 / DSM 8903 / Tp8T 6331)) Explore A4XIG7 Go to UniProtKB: A4XIG7
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A4XIG7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download Ideal Coordinates CCD File SDF format, chain H [auth B] SDF format, chain D [auth A] MOL2 format, chain H [auth B] MOL2 format, chain D [auth A] mmCIF format, chain H [auth B] mmCIF format, chain D [auth A]	D [auth A], H [auth B]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain H [auth B] Interactions & Density Focus chain D [auth A] Focus chain H [auth B]
BGC (Subject of Investigation/LOI) Query on BGC Download Ideal Coordinates CCD File SDF format, chain G [auth B] SDF format, chain C [auth A] MOL2 format, chain G [auth B] MOL2 format, chain C [auth A] mmCIF format, chain G [auth B] mmCIF format, chain C [auth A]	C [auth A], G [auth B]	beta-D-glucopyranose C₆ H₁₂ O₆ WQZGKKKJIJFFOK-VFUOTHLCSA-N		Interactions Focus chain C [auth A] Focus chain G [auth B] Interactions & Density Focus chain C [auth A] Focus chain G [auth B]
PEG Query on PEG Download Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
