9DSC | pdb_00009dsc

Crystal structure of Apo-241_2F04-A95a mutant Fab

  • Classification: IMMUNE SYSTEM
  • Organism(s): Homo sapiens
  • Expression System: Cricetulus griseus
  • Mutation(s): No

  • Deposited: 2024-09-26 Released: 2025-03-19
  • Deposition Author(s): Lin, T.H., Wilson, I.A.
  • Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.01 Å
  • R-Value Free:
    0.236 (Depositor), 0.238 (DCC)
  • R-Value Work:
    0.200 (Depositor), 0.202 (DCC)
  • R-Value Observed:
    0.202 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structurally convergent antibodies derived from different vaccine strategies target the influenza virus HA anchor epitope with a subset of V H 3 and V K 3 genes.

Lin, T.H.Lee, C.D.Fernandez-Quintero, M.L.Ferguson, J.A.Han, J.Zhu, X.Yu, W.Guthmiller, J.J.Krammer, F.Wilson, P.C.Ward, A.B.Wilson, I.A.

(2025) Nat Commun 16: 1268-1268

  • DOI: https://doi.org/10.1038/s41467-025-56496-4
  • Primary Citation of Related Structures:
    9DM0, 9DRU, 9DS1, 9DS2, 9DSC

  • PubMed Abstract:

    H1N1 influenza viruses are responsible for both seasonal and pandemic influenza. The continual antigenic shift and drift of these viruses highlight the urgent need for a universal influenza vaccine to elicit broadly neutralizing antibodies (bnAbs). Identification and characterization of bnAbs elicited in natural infection and immunization to influenza virus hemagglutinin (HA) can provide insights for development of a universal influenza vaccine. Here, we structurally and biophysically characterize four antibodies that bind to a conserved region on the HA membrane-proximal region known as the anchor epitope. Despite some diversity in their V H and V K genes, the antibodies interact with the HA through germline-encoded residues in HCDR2 and LCDR3. Somatic mutations on HCDR3 also contribute hydrophobic interactions with the conserved HA epitope. This convergent binding mode provides extensive neutralization breadth against H1N1 viruses and suggests possible countermeasures against H1N1 viruses.


  • Organizational Affiliation
    • Department of Integrative Structural and Computational Biology, The Scripps Research Institute, La Jolla, CA, 92037, USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
241_2F04-A95a, Heavy chainA,
C [auth B]
227Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
241_2F04-A95a, Light chainB [auth F],
D [auth C]
215Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.01 Å
  • R-Value Free:  0.236 (Depositor), 0.238 (DCC)
  • R-Value Work:  0.200 (Depositor), 0.202 (DCC)
  • R-Value Observed: 0.202 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.254α = 90
b = 113.659β = 90
c = 160.812γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United States75N93019C00051

Revision History  (Full details and data files)

  • Version 1.0: 2025-03-19
    Type: Initial release
