9DHN | pdb_00009dhn

Crystal structure of PIsnA complexed with an imine intermediate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.94 Å
  • R-Value Free:
    0.259 (Depositor), 0.259 (DCC)
  • R-Value Work:
    0.238 (Depositor), 0.238 (DCC)
  • R-Value Observed:
    0.240 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Studies of Isonitrile Synthases Help Elucidate the Mechanism of Isonitrile Installation.

Chen, T.Y.Kim, W.Guo, M.Yao, A.Zhang, Y.J.Chang, W.C.

(2025) ACS Catal 15: 12005-12013

  • DOI: https://doi.org/10.1021/acscatal.5c03282
  • Primary Citation of Related Structures:
    9DH4, 9DHM, 9DHN

  • PubMed Abstract:

    Isonitrile functional group is abundant in natural products and associated with various biological properties. To date, two pathways are known for isonitrile group installation. One is catalyzed by mononuclear nonheme iron dependent isonitrilases in which the reaction mechanism involves consecutive desaturation and decarboxylation processes. The other pathway includes isonitrile synthases, however, how isonitrile synthases enable the condensation of a sugar phosphate and an aromatic amino acid to install isonitrile group remains understudied. In this study, we examine substrate analogs and quantify reaction products using isotopologues to establish the substrate requirements of two isonitrile synthases, WelI1 and PIsnA, providing insights into their spatial and substrate requirements. Under experimental conditions, isonitrile synthases can only enable single turnover, with product binding likely associated with this observation. To reveal the reaction mechanism, we solved substrate- and product-bound protein structures. Furthermore, using a sequential soaking approach, we successfully trapped a plausible intermediate in crystallo. Observation of the plausible C2-imine intermediate in the active site suggests the reaction starts from the imine installation between the carbonyl group of the sugar phosphate and the amine group of the amino acid. Altogether, these studies provide insights into substrate recognition, i.e., pentose phosphate and L-aromatic amino acid, and the reaction mechanism of isonitrile synthases.


  • Organizational Affiliation
    • Department of Chemistry, North Carolina State University, Raleigh, NC 27695, USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
L-tyrosine/L-tryptophan isonitrile synthase family protein
A, B
315Photorhabdus luminescensMutation(s): 0
Gene Names: GPY51_01455
UniProt
Find proteins for A0A1G5Q840 (Photorhabdus luminescens)
Explore A0A1G5Q840
Go to UniProtKB:  A0A1G5Q840
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1G5Q840
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1A46 (Subject of Investigation/LOI)
Query on A1A46

Download Ideal Coordinates CCD File
E [auth A](2S)-2-{[(2S,3S)-1,3-dihydroxy-4-oxopentan-2-yl]amino}-3-(4-hydroxyphenyl)propanoic acid
C14 H19 N O6
FFYADCDWUVDZPP-RWMBFGLXSA-N
PG6 (Subject of Investigation/LOI)
Query on PG6

Download Ideal Coordinates CCD File
I [auth B]1-(2-METHOXY-ETHOXY)-2-{2-[2-(2-METHOXY-ETHOXY]-ETHOXY}-ETHANE
C12 H26 O6
DMDPGPKXQDIQQG-UHFFFAOYSA-N
PG4 (Subject of Investigation/LOI)
Query on PG4

Download Ideal Coordinates CCD File
C [auth A],
D [auth A]
TETRAETHYLENE GLYCOL
C8 H18 O5
UWHCKJMYHZGTIT-UHFFFAOYSA-N
PG0 (Subject of Investigation/LOI)
Query on PG0

Download Ideal Coordinates CCD File
H [auth B]2-(2-METHOXYETHOXY)ETHANOL
C5 H12 O3
SBASXUCJHJRPEV-UHFFFAOYSA-N
PO4 (Subject of Investigation/LOI)
Query on PO4

Download Ideal Coordinates CCD File
F [auth A],
J [auth B]
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
EDO (Subject of Investigation/LOI)
Query on EDO

Download Ideal Coordinates CCD File
G [auth B]1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.94 Å
  • R-Value Free:  0.259 (Depositor), 0.259 (DCC)
  • R-Value Work:  0.238 (Depositor), 0.238 (DCC)
  • R-Value Observed: 0.240 (Depositor)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 133.734α = 90
b = 133.734β = 90
c = 109.075γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data scaling
HKL-2000data reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35 GM148356

Revision History  (Full details and data files)

  • Version 1.0: 2025-07-16
    Type: Initial release
  • Version 1.1: 2025-09-17
    Changes: Database references
