9CQG

CRYSTAL STRUCTURE OF APO C-TERMINAL HIS-TAG DOG HSP47(36-418) IN A P 1 CRYSTAL FORM


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.47 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.243
  • R-Value Observed: 0.244

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Improving the diffraction quality of heat-shock protein 47 crystals.

Kish, K.Cobell, S.Szapiel, N.Yan, C.Newitt, J.A.Tredup, J.Rodrigo, I.Tomasco, E.Gao, M.Marsilio, F.Haugner, J.Lipovsek, D.Deng, B.Bousquet, P.Zhang, Y.Schmidt, H.Sheriff, S.

(2024) Acta Crystallogr F Struct Biol Commun

  • DOI: https://doi.org/10.1107/S2053230X24009233
  • Primary Citation of Related Structures:
    9CQE, 9CQF, 9CQG, 9CQH, 9CQI, 9CQJ

  • PubMed Abstract:

    Heat-shock protein 47 (HSP47) is a potential target for inhibitors that ameliorate fibrosis by reducing collagen assembly. In an effort to develop a structure-based drug-design system, it was not possible to replicate a previous literature result (PDB entry 4au4) for apo dog HSP47; instead, crystal forms were obtained in which pairs of dog HSP47 molecules interacted through a noncleavable C-terminal His-tag to build up tetramers, all of which had multiple molecules of HSP47 in the asymmetric unit and none of which diffracted as well as the literature precedent. To overcome these difficulties, a two-pronged approach was followed: (i) the His-tag was moved from the C-terminus to the N-terminus and was made cleavable, and (ii) Adnectin (derived from the tenth domain of human fibronectin type III) crystallization chaperones were developed. Both approaches provided well diffracting crystals, but the latter approach yielded crystal forms with only one or two HSP47 complexes per asymmetric unit, which made model building less onerous.


  • Organizational Affiliation

    Molecular Structure & Design, Bristol Myers Squibb Research & Development, PO Box 4000, Princeton, NJ 08543-4000, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Serpin H1392Canis lupus familiarisMutation(s): 0
Gene Names: SERPINH1
UniProt
Find proteins for C7C419 (Canis lupus familiaris)
Explore C7C419
Go to UniProtKB:  C7C419
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC7C419
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.47 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.243
  • R-Value Observed: 0.244
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.299α = 85.23
b = 91.995β = 70.69
c = 123.58γ = 83.23
Software Package:
Software NamePurpose
autoPROCdata processing
XDSdata reduction
Aimlessdata scaling
STARANISOdata scaling
BUSTERrefinement
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data

  • Released Date: 2024-10-30
  • Deposition Author(s): Sheriff, S.

Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-10-30
    Type: Initial release
