8XOO

Cryo-EM structure of the ClpC1:ClpP1P2 degradation complex in Streptomyces hawaiiensis


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 1.84 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural insights into the Clp protein degradation machinery.

Xu, X.Wang, Y.Huang, W.Li, D.Deng, Z.Long, F.

(2024) mBio 15: e0003124-e0003124

  • DOI: https://doi.org/10.1128/mbio.00031-24
  • Primary Citation of Related Structures:
    8XN4, 8XON, 8XOO, 8XOP

  • PubMed Abstract:

    The Clp protease system is important for maintaining proteostasis in bacteria. It consists of ClpP serine proteases and an AAA+ Clp-ATPase such as ClpC1. The hexameric ATPase ClpC1 utilizes the energy of ATP binding and hydrolysis to engage, unfold, and translocate substrates into the proteolytic chamber of homo- or hetero-tetradecameric ClpP for degradation. The assembly between the hetero-tetradecameric ClpP1P2 chamber and the Clp-ATPases containing tandem ATPase domains from the same species has not been studied in depth. Here, we present cryo-EM structures of the substrate-bound ClpC1:shClpP1P2 from Streptomyces hawaiiensis , and shClpP1P2 in complex with ADEP1, a natural compound produced by S. hawaiiensis and known to cause over-activation and dysregulation of the ClpP proteolytic core chamber. Our structures provide detailed information on the shClpP1-shClpP2, shClpP2-ClpC1, and ADEP1-shClpP1/P2 interactions, reveal conformational transition of ClpC1 during the substrate translocation, and capture a rotational ATP hydrolysis mechanism likely dominated by the D1 ATPase activity of chaperones.IMPORTANCEThe Clp-dependent proteolysis plays an important role in bacterial homeostasis and pathogenesis. The ClpP protease system is an effective drug target for antibacterial therapy. Streptomyces hawaiiensis can produce a class of potent acyldepsipeptide antibiotics such as ADEP1, which could affect the ClpP protease activity. Although S. hawaiiensis hosts one of the most intricate ClpP systems in nature, very little was known about its Clp protease mechanism and the impact of ADEP molecules on ClpP. The significance of our research is in dissecting the functional mechanism of the assembled Clp degradation machinery, as well as the interaction between ADEP1 and the ClpP proteolytic chamber, by solving high-resolution structures of the substrate-bound Clp system in S. hawaiiensis . The findings shed light on our understanding of the Clp-dependent proteolysis in bacteria, which will enhance the development of antimicrobial drugs targeting the Clp protease system, and help fighting against bacterial multidrug resistance.


  • Organizational Affiliation

    Department of Neurosurgery, Zhongnan Hospital of Wuhan University, School of Pharmaceutical Sciences, Wuhan University, Wuhan, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ATP-dependent Clp protease proteolytic subunit
A, B, C, D, E
A, B, C, D, E, F, G
226Streptomyces hawaiiensisMutation(s): 1
Gene Names: clpP1clpPCEB94_14110
EC: 3.4.21.92
UniProt
Find proteins for A0A5B9BGY8 (Streptomyces hawaiiensis)
Explore A0A5B9BGY8
Go to UniProtKB:  A0A5B9BGY8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5B9BGY8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
ATP-dependent Clp protease proteolytic subunit
H, I, J, K, L
H, I, J, K, L, M, N
207Streptomyces hawaiiensisMutation(s): 1
Gene Names: clpP2clpPCEB94_14105
EC: 3.4.21.92
UniProt
Find proteins for A0A5B9BIX9 (Streptomyces hawaiiensis)
Explore A0A5B9BIX9
Go to UniProtKB:  A0A5B9BIX9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A5B9BIX9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
NDP-hexose 4-ketoreductase696Streptomyces hawaiiensisMutation(s): 3
Gene Names: CEB94_23085
UniProt
Find proteins for A0A6G5RIJ6 (Streptomyces hawaiiensis)
Explore A0A6G5RIJ6
Go to UniProtKB:  A0A6G5RIJ6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A6G5RIJ6
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
caseinU [auth X]24Bos taurusMutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP (Subject of Investigation/LOI)
Query on ATP

Download Ideal Coordinates CCD File
AA [auth Q]
DA [auth P]
GA [auth O]
JA [auth T]
MA [auth S]
AA [auth Q],
DA [auth P],
GA [auth O],
JA [auth T],
MA [auth S],
V [auth R],
W [auth R]
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
ADP
Query on ADP

Download Ideal Coordinates CCD File
CA [auth P],
FA [auth O],
IA [auth T],
LA [auth S],
Z [auth Q]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
BA [auth Q]
EA [auth P]
HA [auth O]
KA [auth T]
NA [auth S]
BA [auth Q],
EA [auth P],
HA [auth O],
KA [auth T],
NA [auth S],
X [auth R],
Y [auth R]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 1.84 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.19.2_4158:

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (MoST, China)China2021YFA0909500

Revision History  (Full details and data files)

  • Version 1.0: 2024-03-27
    Type: Initial release
  • Version 1.1: 2024-04-24
    Changes: Database references
  • Version 1.2: 2024-05-01
    Changes: Database references
