8G6G

H2BK120ub+H3K79me2-modified nucleosome ubiquitin position 5

• PDB DOI: https://doi.org/10.2210/pdb8G6G/pdb
• EM Map EMD-29767: EMDB EMDataResource
• NAKB: 8G6G

• Classification: DNA BINDING PROTEIN/DNA
• Organism(s): Xenopus laevis, synthetic construct, Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2023-02-15 Released: 2024-02-21
• Deposition Author(s): Hicks, C.W., Wolberger, C.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 2.93 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Ubiquitinated H2B as gatekeeper of the nucleosome acidic patch

Hicks, C.W., Rahman, S., Fields, J.K., Morgan, M.T., Wolberger, C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 9-mer - A2B2C2D2E1 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 9-mer - A7B1C1 Local Symmetry: Cyclic - C2  (Explore in 3D)
Local Stoichiometry: Hetero 8-mer - A2B2C2D2

Local Symmetry: Cyclic - C2  (Explore in 3D)
Local Stoichiometry: Hetero 8-mer - A2B2C2D2

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: native gel electrophoresis

Macromolecule Content

• Total Structure Weight: 232.4 kDa
• Atom Count: 12,985
• Modelled Residue Count: 1,139
• Deposited Residue Count: 1,434
• Unique protein chains: 5
• Unique nucleic acid chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H3	A, E	136	Xenopus laevis	Mutation(s): 1  Gene Names: LOC121398065
UniProt
Find proteins for A0A310TTQ1 (Xenopus laevis) Explore A0A310TTQ1  Go to UniProtKB:  A0A310TTQ1

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H4	B, F	103	Xenopus laevis	Mutation(s): 0
UniProt
Find proteins for P62799 (Xenopus laevis) Explore P62799  Go to UniProtKB:  P62799

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H2A	C, G	130	Xenopus laevis	Mutation(s): 0  Gene Names: hist1h2aj, LOC494591, XELAEV_18003602mg
UniProt
Find proteins for Q6AZJ8 (Xenopus laevis) Explore Q6AZJ8  Go to UniProtKB:  Q6AZJ8

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H2B 1.1	D, H	123	Xenopus laevis	Mutation(s): 2
UniProt
Find proteins for P02281 (Xenopus laevis) Explore P02281  Go to UniProtKB:  P02281

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
Ubiquitin	K	80	Homo sapiens	Mutation(s): 1  Gene Names: UBB
UniProt & NIH Common Fund Data Resources
Find proteins for P0CG47 (Homo sapiens) Explore P0CG47  Go to UniProtKB:  P0CG47
PHAROS:  P0CG47 GTEx:  ENSG00000170315

Entity ID: 5
Molecule	Chains	Length	Organism	Image
601 DNA (185-MER)	I	185	synthetic construct

Entity ID: 6
Molecule	Chains	Length	Organism	Image
601 DNA (185-MER)	J	185	synthetic construct

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MLY	A, E	L-PEPTIDE LINKING	C8 H18 N2 O2		LYS

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 2.93 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-02-21
Deposition Author(s): Hicks, C.W., Wolberger, C.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	5R35GM130393

Revision History

• Version 1.0: 2024-02-21
  Type: Initial release
