8BCV

Photosystem I assembly intermediate of Avena sativa

PDB DOI: https://doi.org/10.2210/pdb8BCV/pdb
EM Map EMD-15969: EMDB EMDataResource

Classification: PHOTOSYNTHESIS
Organism(s): Avena sativa
Mutation(s): No
Membrane Protein: Yes PDBTMMemProtMD

Deposited: 2022-10-17 Released: 2023-11-01
Deposition Author(s): Naschberger, A., Amunts, A., Nelson, N.
Funding Organization(s): The Swedish Foundation for Strategic Research, Knut and Alice Wallenberg Foundation, Israel Science Foundation

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.20 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Photosystem I assembly intermediate of Avena sativa

Naschberger, A., Amunts, A., Nelson, N.

To be published.

Macromolecule Content

Total Structure Weight: 586.62 kDa
Atom Count: 37,485
Modelled Residue Count: 3,258
Deposited Residue Count: 3,735
Unique protein chains: 16

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I P700 chlorophyll a apoprotein A1	A	750	Avena sativa	Mutation(s): 0 EC: 1.97.1.12 Membrane Entity: Yes
UniProt
Find proteins for A0A3G1AUL2 (Avena sativa) Explore A0A3G1AUL2 Go to UniProtKB: A0A3G1AUL2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A3G1AUL2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I P700 chlorophyll a apoprotein A2	B	734	Avena sativa	Mutation(s): 0 EC: 1.97.1.12 Membrane Entity: Yes
UniProt
Find proteins for A0A3G1AZK6 (Avena sativa) Explore A0A3G1AZK6 Go to UniProtKB: A0A3G1AZK6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A3G1AZK6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I iron-sulfur center	C	81	Avena sativa	Mutation(s): 0 EC: 1.97.1.12 Membrane Entity: Yes
UniProt
Find proteins for A0A3G1ATU7 (Avena sativa) Explore A0A3G1ATU7 Go to UniProtKB: A0A3G1ATU7
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A3G1ATU7
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit II	D	206	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit IV	E	143	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit VI	F [auth H]	94	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit VIII	G [auth I]	36	Avena sativa	Mutation(s): 0 Membrane Entity: Yes
UniProt
Find proteins for A0A3G1AZM6 (Avena sativa) Explore A0A3G1AZM6 Go to UniProtKB: A0A3G1AZM6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A3G1AZM6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 8
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit XI	H [auth L]	213	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 9
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit III	I [auth F]	178	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 10
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit V	J [auth G]	144	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 11
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit IX	K [auth J]	52	Avena sativa	Mutation(s): 0 Membrane Entity: Yes
UniProt
Find proteins for A0A3G1AZP2 (Avena sativa) Explore A0A3G1AZP2 Go to UniProtKB: A0A3G1AZP2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A3G1AZP2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 12
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem I reaction center subunit X	L [auth K]	130	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 13
Molecule	Chains	Sequence Length	Organism	Details	Image
Chlorophyll a-b binding protein 1, chloroplastic	M [auth 1]	242	Avena sativa	Mutation(s): 0
UniProt
Find proteins for A0A482JYH1 (Avena sativa) Explore A0A482JYH1 Go to UniProtKB: A0A482JYH1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A482JYH1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 14
Molecule	Chains	Sequence Length	Organism	Details	Image
Chlorophyll a-b binding protein 2, chloroplastic	N [auth 2]	207	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 15
Molecule	Chains	Sequence Length	Organism	Details	Image
Chlorophyll a-b binding protein 3, chloroplastic	O [auth 3]	269	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 16
Molecule	Chains	Sequence Length	Organism	Details	Image
Chlorophyll a-b binding protein 4, chloroplastic	P [auth 4]	256	Avena sativa	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 14 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
DGD Query on DGD Download Ideal Coordinates CCD File SDF format, chain DI [auth 4] SDF format, chain PD [auth B] SDF format, chain ZE [auth J] MOL2 format, chain DI [auth 4] MOL2 format, chain PD [auth B] MOL2 format, chain ZE [auth J]	DI [auth 4], PD [auth B], ZE [auth J]	DIGALACTOSYL DIACYL GLYCEROL (DGDG) C₅₁ H₉₆ O₁₅ LDQFLSUQYHBXSX-HXXRYREZSA-N		Interactions Focus chain DI [auth 4] Focus chain PD [auth B] Focus chain ZE [auth J] Interactions & Density Focus chain DI [auth 4] Focus chain PD [auth B] Focus chain ZE [auth J]
CHL (Subject of Investigation/LOI) Query on CHL Download Ideal Coordinates CCD File SDF format, chain FG [auth 2] SDF format, chain GF [auth 1] SDF format, chain GG [auth 2] SDF format, chain HG [auth 2] SDF format, chain LF [auth 1] SDF format, chain MH [auth 4] SDF format, chain NH [auth 4] SDF format, chain OG [auth 2] SDF format, chain OH [auth 4] SDF format, chain TG [auth 3] SDF format, chain WH [auth 4] SDF format, chain YG [auth 3] MOL2 format, chain FG [auth 2] MOL2 format, chain GF [auth 1] MOL2 format, chain GG [auth 2] MOL2 format, chain HG [auth 2] MOL2 format, chain LF [auth 1] MOL2 format, chain MH [auth 4] MOL2 format, chain NH [auth 4] MOL2 format, chain OG [auth 2] MOL2 format, chain OH [auth 4] MOL2 format, chain TG [auth 3] MOL2 format, chain WH [auth 4] MOL2 format, chain YG [auth 3]	FG [auth 2] GF [auth 1] GG [auth 2] HG [auth 2] LF [auth 1] FG [auth 2], GF [auth 1], GG [auth 2], HG [auth 2], LF [auth 1], MH [auth 4], NH [auth 4], OG [auth 2], OH [auth 4], TG [auth 3], WH [auth 4], YG [auth 3]	CHLOROPHYLL B C₅₅ H₇₀ Mg N₄ O₆ MWVCRINOIIOUAU-UYSPMESUSA-M		Interactions Focus chain FG [auth 2] Focus chain GF [auth 1] Focus chain GG [auth 2] Focus chain HG [auth 2] Focus chain LF [auth 1] Focus chain MH [auth 4] Focus chain NH [auth 4] Focus chain OG [auth 2] Focus chain OH [auth 4] Focus chain TG [auth 3] Focus chain WH [auth 4] Focus chain YG [auth 3] Interactions & Density Focus chain FG [auth 2] Focus chain GF [auth 1] Focus chain GG [auth 2] Focus chain HG [auth 2] Focus chain LF [auth 1] Focus chain MH [auth 4] Focus chain NH [auth 4] Focus chain OG [auth 2] Focus chain OH [auth 4] Focus chain TG [auth 3] Focus chain WH [auth 4] Focus chain YG [auth 3]
CLA (Subject of Investigation/LOI) Query on CLA Download Ideal Coordinates CCD File SDF format, chain AA [auth A] SDF format, chain AB [auth A] SDF format, chain AC [auth B] SDF format, chain AD [auth B] SDF format, chain AE [auth L] SDF format, chain AF [auth K] SDF format, chain AH [auth 3] SDF format, chain BA [auth A] SDF format, chain BB [auth A] SDF format, chain BC [auth B] SDF format, chain BD [auth B] SDF format, chain BE [auth L] SDF format, chain BG [auth 2] SDF format, chain BH [auth 3] SDF format, chain CA [auth A] SDF format, chain CB [auth A] SDF format, chain CC [auth B] SDF format, chain CD [auth B] SDF format, chain CE [auth L] SDF format, chain CF [auth K] SDF format, chain CG [auth 2] SDF format, chain CH [auth 3] SDF format, chain DA [auth A] SDF format, chain DB [auth A] SDF format, chain DC [auth B] SDF format, chain DD [auth B] SDF format, chain DF [auth K] SDF format, chain DG [auth 2] SDF format, chain DH [auth 3] SDF format, chain EA [auth A] SDF format, chain EB [auth A] SDF format, chain EC [auth B] SDF format, chain ED [auth B] SDF format, chain EG [auth 2] SDF format, chain EH [auth 3] SDF format, chain FA [auth A] SDF format, chain FB [auth A] SDF format, chain FC [auth B] SDF format, chain FD [auth B] SDF format, chain GA [auth A] SDF format, chain GB [auth A] SDF format, chain GC [auth B] SDF format, chain GD [auth B] SDF format, chain GE [auth F] SDF format, chain HA [auth A] SDF format, chain HC [auth B] SDF format, chain HD [auth B] SDF format, chain HF [auth 1] SDF format, chain IA [auth A] SDF format, chain IB [auth A] SDF format, chain IC [auth B] SDF format, chain IE [auth F] SDF format, chain IF [auth 1] SDF format, chain IG [auth 2] SDF format, chain IH [auth 4] SDF format, chain JA [auth A] SDF format, chain JC [auth B] SDF format, chain JD [auth B] SDF format, chain JE [auth F] SDF format, chain JF [auth 1] SDF format, chain JG [auth 2] SDF format, chain JH [auth 4] SDF format, chain KA [auth A] SDF format, chain KC [auth B] SDF format, chain KF [auth 1] SDF format, chain KG [auth 2] SDF format, chain KH [auth 4] SDF format, chain LA [auth A] SDF format, chain LC [auth B] SDF format, chain LG [auth 2] SDF format, chain LH [auth 4] SDF format, chain MA [auth A] SDF format, chain MC [auth B] SDF format, chain MF [auth 1] SDF format, chain MG [auth 2] SDF format, chain NA [auth A] SDF format, chain NC [auth B] SDF format, chain NF [auth 1] SDF format, chain NG [auth 2] SDF format, chain OA [auth A] SDF format, chain OC [auth B] SDF format, chain OF [auth 1] SDF format, chain PA [auth A] SDF format, chain PC [auth B] SDF format, chain PE [auth G] SDF format, chain PF [auth 1] SDF format, chain PH [auth 4] SDF format, chain QA [auth A] SDF format, chain QC [auth B] SDF format, chain QF [auth 1] SDF format, chain QH [auth 4] SDF format, chain R [auth A] SDF format, chain RA [auth A] SDF format, chain RB [auth A] SDF format, chain RC [auth B] SDF format, chain RF [auth 1] SDF format, chain RH [auth 4] SDF format, chain S [auth A] SDF format, chain SA [auth A] SDF format, chain SB [auth A] SDF format, chain SC [auth B] SDF format, chain SE [auth G] SDF format, chain SF [auth 1] SDF format, chain SH [auth 4] SDF format, chain T [auth A] SDF format, chain TA [auth A] SDF format, chain TB [auth A] SDF format, chain TC [auth B] SDF format, chain TE [auth G] SDF format, chain TF [auth 1] SDF format, chain TH [auth 4] SDF format, chain U [auth A] SDF format, chain UA [auth A] SDF format, chain UC [auth B] SDF format, chain UG [auth 3] SDF format, chain UH [auth 4] SDF format, chain V [auth A] SDF format, chain VA [auth A] SDF format, chain VC [auth B] SDF format, chain VG [auth 3] SDF format, chain VH [auth 4] SDF format, chain W [auth A] SDF format, chain WA [auth A] SDF format, chain WC [auth B] SDF format, chain WG [auth 3] SDF format, chain X [auth A] SDF format, chain XA [auth A] SDF format, chain XB [auth B] SDF format, chain XC [auth B] SDF format, chain XE [auth J] SDF format, chain XG [auth 3] SDF format, chain Y [auth A] SDF format, chain YA [auth A] SDF format, chain YB [auth B] SDF format, chain YC [auth B] SDF format, chain Z [auth A] SDF format, chain ZA [auth A] SDF format, chain ZB [auth B] SDF format, chain ZC [auth B] SDF format, chain ZG [auth 3] MOL2 format, chain AA [auth A] MOL2 format, chain AB [auth A] MOL2 format, chain AC [auth B] MOL2 format, chain AD [auth B] MOL2 format, chain AE [auth L] MOL2 format, chain AF [auth K] MOL2 format, chain AH [auth 3] MOL2 format, chain BA [auth A] MOL2 format, chain BB [auth A] MOL2 format, chain BC [auth B] MOL2 format, chain BD [auth B] MOL2 format, chain BE [auth L] MOL2 format, chain BG [auth 2] MOL2 format, chain BH [auth 3] MOL2 format, chain CA [auth A] MOL2 format, chain CB [auth A] MOL2 format, chain CC [auth B] MOL2 format, chain CD [auth B] MOL2 format, chain CE [auth L] MOL2 format, chain CF [auth K] MOL2 format, chain CG [auth 2] MOL2 format, chain CH [auth 3] MOL2 format, chain DA [auth A] MOL2 format, chain DB [auth A] MOL2 format, chain DC [auth B] MOL2 format, chain DD [auth B] MOL2 format, chain DF [auth K] MOL2 format, chain DG [auth 2] MOL2 format, chain DH [auth 3] MOL2 format, chain EA [auth A] MOL2 format, chain EB [auth A] MOL2 format, chain EC [auth B] MOL2 format, chain ED [auth B] MOL2 format, chain EG [auth 2] MOL2 format, chain EH [auth 3] MOL2 format, chain FA [auth A] MOL2 format, chain FB [auth A] MOL2 format, chain FC [auth B] MOL2 format, chain FD [auth B] MOL2 format, chain GA [auth A] MOL2 format, chain GB [auth A] MOL2 format, chain GC [auth B] MOL2 format, chain GD [auth B] MOL2 format, chain GE [auth F] MOL2 format, chain HA [auth A] MOL2 format, chain HC [auth B] MOL2 format, chain HD [auth B] MOL2 format, chain HF [auth 1] MOL2 format, chain IA [auth A] MOL2 format, chain IB [auth A] MOL2 format, chain IC [auth B] MOL2 format, chain IE [auth F] MOL2 format, chain IF [auth 1] MOL2 format, chain IG [auth 2] MOL2 format, chain IH [auth 4] MOL2 format, chain JA [auth A] MOL2 format, chain JC [auth B] MOL2 format, chain JD [auth B] MOL2 format, chain JE [auth F] MOL2 format, chain JF [auth 1] MOL2 format, chain JG [auth 2] MOL2 format, chain JH [auth 4] MOL2 format, chain KA [auth A] MOL2 format, chain KC [auth B] MOL2 format, chain KF [auth 1] MOL2 format, chain KG [auth 2] MOL2 format, chain KH [auth 4] MOL2 format, chain LA [auth A] MOL2 format, chain LC [auth B] MOL2 format, chain LG [auth 2] MOL2 format, chain LH [auth 4] MOL2 format, chain MA [auth A] MOL2 format, chain MC [auth B] MOL2 format, chain MF [auth 1] MOL2 format, chain MG [auth 2] MOL2 format, chain NA [auth A] MOL2 format, chain NC [auth B] MOL2 format, chain NF [auth 1] MOL2 format, chain NG [auth 2] MOL2 format, chain OA [auth A] MOL2 format, chain OC [auth B] MOL2 format, chain OF [auth 1] MOL2 format, chain PA [auth A] MOL2 format, chain PC [auth B] MOL2 format, chain PE [auth G] MOL2 format, chain PF [auth 1] MOL2 format, chain PH [auth 4] MOL2 format, chain QA [auth A] MOL2 format, chain QC [auth B] MOL2 format, chain QF [auth 1] MOL2 format, chain QH [auth 4] MOL2 format, chain R [auth A] MOL2 format, chain RA [auth A] MOL2 format, chain RB [auth A] MOL2 format, chain RC [auth B] MOL2 format, chain RF [auth 1] MOL2 format, chain RH [auth 4] MOL2 format, chain S [auth A] MOL2 format, chain SA [auth A] MOL2 format, chain SB [auth A] MOL2 format, chain SC [auth B] MOL2 format, chain SE [auth G] MOL2 format, chain SF [auth 1] MOL2 format, chain SH [auth 4] MOL2 format, chain T [auth A] MOL2 format, chain TA [auth A] MOL2 format, chain TB [auth A] MOL2 format, chain TC [auth B] MOL2 format, chain TE [auth G] MOL2 format, chain TF [auth 1] MOL2 format, chain TH [auth 4] MOL2 format, chain U [auth A] MOL2 format, chain UA [auth A] MOL2 format, chain UC [auth B] MOL2 format, chain UG [auth 3] MOL2 format, chain UH [auth 4] MOL2 format, chain V [auth A] MOL2 format, chain VA [auth A] MOL2 format, chain VC [auth B] MOL2 format, chain VG [auth 3] MOL2 format, chain VH [auth 4] MOL2 format, chain W [auth A] MOL2 format, chain WA [auth A] MOL2 format, chain WC [auth B] MOL2 format, chain WG [auth 3] MOL2 format, chain X [auth A] MOL2 format, chain XA [auth A] MOL2 format, chain XB [auth B] MOL2 format, chain XC [auth B] MOL2 format, chain XE [auth J] MOL2 format, chain XG [auth 3] MOL2 format, chain Y [auth A] MOL2 format, chain YA [auth A] MOL2 format, chain YB [auth B] MOL2 format, chain YC [auth B] MOL2 format, chain Z [auth A] MOL2 format, chain ZA [auth A] MOL2 format, chain ZB [auth B] MOL2 format, chain ZC [auth B] MOL2 format, chain ZG [auth 3]	AA [auth A] AB [auth A] AC [auth B] AD [auth B] AE [auth L] AA [auth A], AB [auth A], AC [auth B], AD [auth B], AE [auth L], AF [auth K], AH [auth 3], BA [auth A], BB [auth A], BC [auth B], BD [auth B], BE [auth L], BG [auth 2], BH [auth 3], CA [auth A], CB [auth A], CC [auth B], CD [auth B], CE [auth L], CF [auth K], CG [auth 2], CH [auth 3], DA [auth A], DB [auth A], DC [auth B], DD [auth B], DF [auth K], DG [auth 2], DH [auth 3], EA [auth A], EB [auth A], EC [auth B], ED [auth B], EG [auth 2], EH [auth 3], FA [auth A], FB [auth A], FC [auth B], FD [auth B], GA [auth A], GB [auth A], GC [auth B], GD [auth B], GE [auth F], HA [auth A], HC [auth B], HD [auth B], HF [auth 1], IA [auth A], IB [auth A], IC [auth B], IE [auth F], IF [auth 1], IG [auth 2], IH [auth 4], JA [auth A], JC [auth B], JD [auth B], JE [auth F], JF [auth 1], JG [auth 2], JH [auth 4], KA [auth A], KC [auth B], KF [auth 1], KG [auth 2], KH [auth 4], LA [auth A], LC [auth B], LG [auth 2], LH [auth 4], MA [auth A], MC [auth B], MF [auth 1], MG [auth 2], NA [auth A], NC [auth B], NF [auth 1], NG [auth 2], OA [auth A], OC [auth B], OF [auth 1], PA [auth A], PC [auth B], PE [auth G], PF [auth 1], PH [auth 4], QA [auth A], QC [auth B], QF [auth 1], QH [auth 4], R [auth A], RA [auth A], RB [auth A], RC [auth B], RF [auth 1], RH [auth 4], S [auth A], SA [auth A], SB [auth A], SC [auth B], SE [auth G], SF [auth 1], SH [auth 4], T [auth A], TA [auth A], TB [auth A], TC [auth B], TE [auth G], TF [auth 1], TH [auth 4], U [auth A], UA [auth A], UC [auth B], UG [auth 3], UH [auth 4], V [auth A], VA [auth A], VC [auth B], VG [auth 3], VH [auth 4], W [auth A], WA [auth A], WC [auth B], WG [auth 3], X [auth A], XA [auth A], XB [auth B], XC [auth B], XE [auth J], XG [auth 3], Y [auth A], YA [auth A], YB [auth B], YC [auth B], Z [auth A], ZA [auth A], ZB [auth B], ZC [auth B], ZG [auth 3]	CHLOROPHYLL A C₅₅ H₇₂ Mg N₄ O₅ ATNHDLDRLWWWCB-AENOIHSZSA-M		Interactions Focus chain AA [auth A] Focus chain AB [auth A] Focus chain AC [auth B] Focus chain AD [auth B] Focus chain AE [auth L] Focus chain AF [auth K] Focus chain AH [auth 3] Focus chain BA [auth A] Focus chain BB [auth A] Focus chain BC [auth B] Focus chain BD [auth B] Focus chain BE [auth L] Focus chain BG [auth 2] Focus chain BH [auth 3] Focus chain CA [auth A] Focus chain CB [auth A] Focus chain CC [auth B] Focus chain CD [auth B] Focus chain CE [auth L] Focus chain CF [auth K] Focus chain CG [auth 2] Focus chain CH [auth 3] Focus chain DA [auth A] Focus chain DB [auth A] Focus chain DC [auth B] Focus chain DD [auth B] Focus chain DF [auth K] Focus chain DG [auth 2] Focus chain DH [auth 3] Focus chain EA [auth A] Focus chain EB [auth A] Focus chain EC [auth B] Focus chain ED [auth B] Focus chain EG [auth 2] Focus chain EH [auth 3] Focus chain FA [auth A] Focus chain FB [auth A] Focus chain FC [auth B] Focus chain FD [auth B] Focus chain GA [auth A] Focus chain GB [auth A] Focus chain GC [auth B] Focus chain GD [auth B] Focus chain GE [auth F] Focus chain HA [auth A] Focus chain HC [auth B] Focus chain HD [auth B] Focus chain HF [auth 1] Focus chain IA [auth A] Focus chain IB [auth A] Focus chain IC [auth B] Focus chain IE [auth F] Focus chain IF [auth 1] Focus chain IG [auth 2] Focus chain IH [auth 4] Focus chain JA [auth A] Focus chain JC [auth B] Focus chain JD [auth B] Focus chain JE [auth F] Focus chain JF [auth 1] Focus chain JG [auth 2] Focus chain JH [auth 4] Focus chain KA [auth A] Focus chain KC [auth B] Focus chain KF [auth 1] Focus chain KG [auth 2] Focus chain KH [auth 4] Focus chain LA [auth A] Focus chain LC [auth B] Focus chain LG [auth 2] Focus chain LH [auth 4] Focus chain MA [auth A] Focus chain MC [auth B] Focus chain MF [auth 1] Focus chain MG [auth 2] Focus chain NA [auth A] Focus chain NC [auth B] Focus chain NF [auth 1] Focus chain NG [auth 2] Focus chain OA [auth A] Focus chain OC [auth B] Focus chain OF [auth 1] Focus chain PA [auth A] Focus chain PC [auth B] Focus chain PE [auth G] Focus chain PF [auth 1] Focus chain PH [auth 4] Focus chain QA [auth A] Focus chain QC [auth B] Focus chain QF [auth 1] Focus chain QH [auth 4] Focus chain R [auth A] Focus chain RA [auth A] Focus chain RB [auth A] Focus chain RC [auth B] Focus chain RF [auth 1] Focus chain RH [auth 4] Focus chain S [auth A] Focus chain SA [auth A] Focus chain SB [auth A] Focus chain SC [auth B] Focus chain SE [auth G] Focus chain SF [auth 1] Focus chain SH [auth 4] Focus chain T [auth A] Focus chain TA [auth A] Focus chain TB [auth A] Focus chain TC [auth B] Focus chain TE [auth G] Focus chain TF [auth 1] Focus chain TH [auth 4] Focus chain U [auth A] Focus chain UA [auth A] Focus chain UC [auth B] Focus chain UG [auth 3] Focus chain UH [auth 4] Focus chain V [auth A] Focus chain VA [auth A] Focus chain VC [auth B] Focus chain VG [auth 3] Focus chain VH [auth 4] Focus chain W [auth A] Focus chain WA [auth A] Focus chain WC [auth B] Focus chain WG [auth 3] Focus chain X [auth A] Focus chain XA [auth A] Focus chain XB [auth B] Focus chain XC [auth B] Focus chain XE [auth J] Focus chain XG [auth 3] Focus chain Y [auth A] Focus chain YA [auth A] Focus chain YB [auth B] Focus chain YC [auth B] Focus chain Z [auth A] Focus chain ZA [auth A] Focus chain ZB [auth B] Focus chain ZC [auth B] Focus chain ZG [auth 3] Interactions & Density Focus chain AA [auth A] Focus chain AB [auth A] Focus chain AC [auth B] Focus chain AD [auth B] Focus chain AE [auth L] Focus chain AF [auth K] Focus chain AH [auth 3] Focus chain BA [auth A] Focus chain BB [auth A] Focus chain BC [auth B] Focus chain BD [auth B] Focus chain BE [auth L] Focus chain BG [auth 2] Focus chain BH [auth 3] Focus chain CA [auth A] Focus chain CB [auth A] Focus chain CC [auth B] Focus chain CD [auth B] Focus chain CE [auth L] Focus chain CF [auth K] Focus chain CG [auth 2] Focus chain CH [auth 3] Focus chain DA [auth A] Focus chain DB [auth A] Focus chain DC [auth B] Focus chain DD [auth B] Focus chain DF [auth K] Focus chain DG [auth 2] Focus chain DH [auth 3] Focus chain EA [auth A] Focus chain EB [auth A] Focus chain EC [auth B] Focus chain ED [auth B] Focus chain EG [auth 2] Focus chain EH [auth 3] Focus chain FA [auth A] Focus chain FB [auth A] Focus chain FC [auth B] Focus chain FD [auth B] Focus chain GA [auth A] Focus chain GB [auth A] Focus chain GC [auth B] Focus chain GD [auth B] Focus chain GE [auth F] Focus chain HA [auth A] Focus chain HC [auth B] Focus chain HD [auth B] Focus chain HF [auth 1] Focus chain IA [auth A] Focus chain IB [auth A] Focus chain IC [auth B] Focus chain IE [auth F] Focus chain IF [auth 1] Focus chain IG [auth 2] Focus chain IH [auth 4] Focus chain JA [auth A] Focus chain JC [auth B] Focus chain JD [auth B] Focus chain JE [auth F] Focus chain JF [auth 1] Focus chain JG [auth 2] Focus chain JH [auth 4] Focus chain KA [auth A] Focus chain KC [auth B] Focus chain KF [auth 1] Focus chain KG [auth 2] Focus chain KH [auth 4] Focus chain LA [auth A] Focus chain LC [auth B] Focus chain LG [auth 2] Focus chain LH [auth 4] Focus chain MA [auth A] Focus chain MC [auth B] Focus chain MF [auth 1] Focus chain MG [auth 2] Focus chain NA [auth A] Focus chain NC [auth B] Focus chain NF [auth 1] Focus chain NG [auth 2] Focus chain OA [auth A] Focus chain OC [auth B] Focus chain OF [auth 1] Focus chain PA [auth A] Focus chain PC [auth B] Focus chain PE [auth G] Focus chain PF [auth 1] Focus chain PH [auth 4] Focus chain QA [auth A] Focus chain QC [auth B] Focus chain QF [auth 1] Focus chain QH [auth 4] Focus chain R [auth A] Focus chain RA [auth A] Focus chain RB [auth A] Focus chain RC [auth B] Focus chain RF [auth 1] Focus chain RH [auth 4] Focus chain S [auth A] Focus chain SA [auth A] Focus chain SB [auth A] Focus chain SC [auth B] Focus chain SE [auth G] Focus chain SF [auth 1] Focus chain SH [auth 4] Focus chain T [auth A] Focus chain TA [auth A] Focus chain TB [auth A] Focus chain TC [auth B] Focus chain TE [auth G] Focus chain TF [auth 1] Focus chain TH [auth 4] Focus chain U [auth A] Focus chain UA [auth A] Focus chain UC [auth B] Focus chain UG [auth 3] Focus chain UH [auth 4] Focus chain V [auth A] Focus chain VA [auth A] Focus chain VC [auth B] Focus chain VG [auth 3] Focus chain VH [auth 4] Focus chain W [auth A] Focus chain WA [auth A] Focus chain WC [auth B] Focus chain WG [auth 3] Focus chain X [auth A] Focus chain XA [auth A] Focus chain XB [auth B] Focus chain XC [auth B] Focus chain XE [auth J] Focus chain XG [auth 3] Focus chain Y [auth A] Focus chain YA [auth A] Focus chain YB [auth B] Focus chain YC [auth B] Focus chain Z [auth A] Focus chain ZA [auth A] Focus chain ZB [auth B] Focus chain ZC [auth B] Focus chain ZG [auth 3]
CL0 (Subject of Investigation/LOI) Query on CL0 Download Ideal Coordinates CCD File SDF format, chain Q [auth A] SDF format, chain WD [auth H] MOL2 format, chain Q [auth A] MOL2 format, chain WD [auth H]	Q [auth A], WD [auth H]	CHLOROPHYLL A ISOMER C₅₅ H₇₂ Mg N₄ O₅ VIQFHHZSLDFWDU-DVXFRRMCSA-M		Interactions Focus chain Q [auth A] Focus chain WD [auth H] Interactions & Density Focus chain Q [auth A] Focus chain WD [auth H]
LMG (Subject of Investigation/LOI) Query on LMG Download Ideal Coordinates CCD File SDF format, chain AI [auth 4] SDF format, chain BI [auth 4] SDF format, chain OE [auth F] SDF format, chain UB [auth A] MOL2 format, chain AI [auth 4] MOL2 format, chain BI [auth 4] MOL2 format, chain OE [auth F] MOL2 format, chain UB [auth A]	AI [auth 4], BI [auth 4], OE [auth F], UB [auth A]	1,2-DISTEAROYL-MONOGALACTOSYL-DIGLYCERIDE C₄₅ H₈₆ O₁₀ DCLTVZLYPPIIID-CVELTQQQSA-N		Interactions Focus chain AI [auth 4] Focus chain BI [auth 4] Focus chain OE [auth F] Focus chain UB [auth A] Interactions & Density Focus chain AI [auth 4] Focus chain BI [auth 4] Focus chain OE [auth F] Focus chain UB [auth A]
LHG Query on LHG Download Ideal Coordinates CCD File SDF format, chain JB [auth A] SDF format, chain KB [auth A] SDF format, chain QD [auth B] SDF format, chain RD [auth B] SDF format, chain RG [auth 2] SDF format, chain XF [auth 1] MOL2 format, chain JB [auth A] MOL2 format, chain KB [auth A] MOL2 format, chain QD [auth B] MOL2 format, chain RD [auth B] MOL2 format, chain RG [auth 2] MOL2 format, chain XF [auth 1]	JB [auth A] KB [auth A] QD [auth B] RD [auth B] RG [auth 2] JB [auth A], KB [auth A], QD [auth B], RD [auth B], RG [auth 2], XF [auth 1]	1,2-DIPALMITOYL-PHOSPHATIDYL-GLYCEROLE C₃₈ H₇₅ O₁₀ P BIABMEZBCHDPBV-MPQUPPDSSA-N		Interactions Focus chain JB [auth A] Focus chain KB [auth A] Focus chain QD [auth B] Focus chain RD [auth B] Focus chain RG [auth 2] Focus chain XF [auth 1] Interactions & Density Focus chain JB [auth A] Focus chain KB [auth A] Focus chain QD [auth B] Focus chain RD [auth B] Focus chain RG [auth 2] Focus chain XF [auth 1]
XAT (Subject of Investigation/LOI) Query on XAT Download Ideal Coordinates CCD File SDF format, chain QG [auth 2] SDF format, chain VF [auth 1] MOL2 format, chain QG [auth 2] MOL2 format, chain VF [auth 1]	QG [auth 2], VF [auth 1]	(3S,5R,6S,3'S,5'R,6'S)-5,6,5',6'-DIEPOXY-5,6,5',6'- TETRAHYDRO-BETA,BETA-CAROTENE-3,3'-DIOL C₄₀ H₅₆ O₄ SZCBXWMUOPQSOX-WVJDLNGLSA-N		Interactions Focus chain QG [auth 2] Focus chain VF [auth 1] Interactions & Density Focus chain QG [auth 2] Focus chain VF [auth 1]
QDL (Subject of Investigation/LOI) Query on QDL Download Ideal Coordinates CCD File SDF format, chain YH [auth 4] MOL2 format, chain YH [auth 4]	YH [auth 4]	Antheraxanthin C₄₀ H₅₆ O₃ OFNSUWBAQRCHAV-OYQUVCAXSA-N		Interactions Focus chain YH [auth 4] Interactions & Density Focus chain YH [auth 4]
C7Z (Subject of Investigation/LOI) Query on C7Z Download Ideal Coordinates CCD File SDF format, chain AG [auth 1] MOL2 format, chain AG [auth 1]	AG [auth 1]	(1~{S})-3,5,5-trimethyl-4-[(1~{E},3~{E},5~{E},7~{E},9~{E},11~{E},13~{E},15~{E},17~{E})-3,7,12,16-tetramethyl-18-[(4~{S})-2,6,6-trimethyl-4-oxidanyl-cyclohexen-1-yl]octadeca-1,3,5,7,9,11,13,15,17-nonaenyl]cyclohex-3-en-1-ol C₄₀ H₅₆ O₂ JKQXZKUSFCKOGQ-ANDPMPNWSA-N		Interactions Focus chain AG [auth 1] Interactions & Density Focus chain AG [auth 1]
LUT (Subject of Investigation/LOI) Query on LUT Download Ideal Coordinates CCD File SDF format, chain GH [auth 3] SDF format, chain HH [auth 3] SDF format, chain PG [auth 2] SDF format, chain UF [auth 1] SDF format, chain WE [auth J] SDF format, chain WF [auth 1] SDF format, chain XH [auth 4] MOL2 format, chain GH [auth 3] MOL2 format, chain HH [auth 3] MOL2 format, chain PG [auth 2] MOL2 format, chain UF [auth 1] MOL2 format, chain WE [auth J] MOL2 format, chain WF [auth 1] MOL2 format, chain XH [auth 4]	GH [auth 3] HH [auth 3] PG [auth 2] UF [auth 1] WE [auth J] GH [auth 3], HH [auth 3], PG [auth 2], UF [auth 1], WE [auth J], WF [auth 1], XH [auth 4]	(3R,3'R,6S)-4,5-DIDEHYDRO-5,6-DIHYDRO-BETA,BETA-CAROTENE-3,3'-DIOL C₄₀ H₅₆ O₂ KBPHJBAIARWVSC-NSIPBSJQSA-N		Interactions Focus chain GH [auth 3] Focus chain HH [auth 3] Focus chain PG [auth 2] Focus chain UF [auth 1] Focus chain WE [auth J] Focus chain WF [auth 1] Focus chain XH [auth 4] Interactions & Density Focus chain GH [auth 3] Focus chain HH [auth 3] Focus chain PG [auth 2] Focus chain UF [auth 1] Focus chain WE [auth J] Focus chain WF [auth 1] Focus chain XH [auth 4]
BCR (Subject of Investigation/LOI) Query on BCR Download Ideal Coordinates CCD File SDF format, chain BF [auth K] SDF format, chain DE [auth L] SDF format, chain EE [auth L] SDF format, chain EF [auth K] SDF format, chain FE [auth F] SDF format, chain FH [auth 3] SDF format, chain KD [auth B] SDF format, chain KE [auth F] SDF format, chain LB [auth A] SDF format, chain LD [auth B] SDF format, chain MB [auth A] SDF format, chain MD [auth B] SDF format, chain NB [auth A] SDF format, chain ND [auth B] SDF format, chain OB [auth A] SDF format, chain OD [auth B] SDF format, chain PB [auth A] SDF format, chain QE [auth G] SDF format, chain UE [auth G] SDF format, chain XD [auth I] SDF format, chain YE [auth J] SDF format, chain ZD [auth L] SDF format, chain ZH [auth 4] MOL2 format, chain BF [auth K] MOL2 format, chain DE [auth L] MOL2 format, chain EE [auth L] MOL2 format, chain EF [auth K] MOL2 format, chain FE [auth F] MOL2 format, chain FH [auth 3] MOL2 format, chain KD [auth B] MOL2 format, chain KE [auth F] MOL2 format, chain LB [auth A] MOL2 format, chain LD [auth B] MOL2 format, chain MB [auth A] MOL2 format, chain MD [auth B] MOL2 format, chain NB [auth A] MOL2 format, chain ND [auth B] MOL2 format, chain OB [auth A] MOL2 format, chain OD [auth B] MOL2 format, chain PB [auth A] MOL2 format, chain QE [auth G] MOL2 format, chain UE [auth G] MOL2 format, chain XD [auth I] MOL2 format, chain YE [auth J] MOL2 format, chain ZD [auth L] MOL2 format, chain ZH [auth 4]	BF [auth K] DE [auth L] EE [auth L] EF [auth K] FE [auth F] BF [auth K], DE [auth L], EE [auth L], EF [auth K], FE [auth F], FH [auth 3], KD [auth B], KE [auth F], LB [auth A], LD [auth B], MB [auth A], MD [auth B], NB [auth A], ND [auth B], OB [auth A], OD [auth B], PB [auth A], QE [auth G], UE [auth G], XD [auth I], YE [auth J], ZD [auth L], ZH [auth 4]	BETA-CAROTENE C₄₀ H₅₆ OENHQHLEOONYIE-JLTXGRSLSA-N		Interactions Focus chain BF [auth K] Focus chain DE [auth L] Focus chain EE [auth L] Focus chain EF [auth K] Focus chain FE [auth F] Focus chain FH [auth 3] Focus chain KD [auth B] Focus chain KE [auth F] Focus chain LB [auth A] Focus chain LD [auth B] Focus chain MB [auth A] Focus chain MD [auth B] Focus chain NB [auth A] Focus chain ND [auth B] Focus chain OB [auth A] Focus chain OD [auth B] Focus chain PB [auth A] Focus chain QE [auth G] Focus chain UE [auth G] Focus chain XD [auth I] Focus chain YE [auth J] Focus chain ZD [auth L] Focus chain ZH [auth 4] Interactions & Density Focus chain BF [auth K] Focus chain DE [auth L] Focus chain EE [auth L] Focus chain EF [auth K] Focus chain FE [auth F] Focus chain FH [auth 3] Focus chain KD [auth B] Focus chain KE [auth F] Focus chain LB [auth A] Focus chain LD [auth B] Focus chain MB [auth A] Focus chain MD [auth B] Focus chain NB [auth A] Focus chain ND [auth B] Focus chain OB [auth A] Focus chain OD [auth B] Focus chain PB [auth A] Focus chain QE [auth G] Focus chain UE [auth G] Focus chain XD [auth I] Focus chain YE [auth J] Focus chain ZD [auth L] Focus chain ZH [auth 4]
LMU (Subject of Investigation/LOI) Query on LMU Download Ideal Coordinates CCD File SDF format, chain CI [auth 4] SDF format, chain EI [auth 4] SDF format, chain FF [auth 1] SDF format, chain FI [auth 4] SDF format, chain HE [auth F] SDF format, chain LE [auth F] SDF format, chain ME [auth F] SDF format, chain NE [auth F] SDF format, chain RE [auth G] SDF format, chain SD [auth B] SDF format, chain SG [auth 2] SDF format, chain VB [auth A] SDF format, chain VD [auth H] SDF format, chain VE [auth G] SDF format, chain WB [auth A] SDF format, chain YD [auth L] SDF format, chain YF [auth 1] SDF format, chain ZF [auth 1] MOL2 format, chain CI [auth 4] MOL2 format, chain EI [auth 4] MOL2 format, chain FF [auth 1] MOL2 format, chain FI [auth 4] MOL2 format, chain HE [auth F] MOL2 format, chain LE [auth F] MOL2 format, chain ME [auth F] MOL2 format, chain NE [auth F] MOL2 format, chain RE [auth G] MOL2 format, chain SD [auth B] MOL2 format, chain SG [auth 2] MOL2 format, chain VB [auth A] MOL2 format, chain VD [auth H] MOL2 format, chain VE [auth G] MOL2 format, chain WB [auth A] MOL2 format, chain YD [auth L] MOL2 format, chain YF [auth 1] MOL2 format, chain ZF [auth 1]	CI [auth 4] EI [auth 4] FF [auth 1] FI [auth 4] HE [auth F] CI [auth 4], EI [auth 4], FF [auth 1], FI [auth 4], HE [auth F], LE [auth F], ME [auth F], NE [auth F], RE [auth G], SD [auth B], SG [auth 2], VB [auth A], VD [auth H], VE [auth G], WB [auth A], YD [auth L], YF [auth 1], ZF [auth 1]	DODECYL-ALPHA-D-MALTOSIDE C₂₄ H₄₆ O₁₁ NLEBIOOXCVAHBD-YHBSTRCHSA-N		Interactions Focus chain CI [auth 4] Focus chain EI [auth 4] Focus chain FF [auth 1] Focus chain FI [auth 4] Focus chain HE [auth F] Focus chain LE [auth F] Focus chain ME [auth F] Focus chain NE [auth F] Focus chain RE [auth G] Focus chain SD [auth B] Focus chain SG [auth 2] Focus chain VB [auth A] Focus chain VD [auth H] Focus chain VE [auth G] Focus chain WB [auth A] Focus chain YD [auth L] Focus chain YF [auth 1] Focus chain ZF [auth 1] Interactions & Density Focus chain CI [auth 4] Focus chain EI [auth 4] Focus chain FF [auth 1] Focus chain FI [auth 4] Focus chain HE [auth F] Focus chain LE [auth F] Focus chain ME [auth F] Focus chain NE [auth F] Focus chain RE [auth G] Focus chain SD [auth B] Focus chain SG [auth 2] Focus chain VB [auth A] Focus chain VD [auth H] Focus chain VE [auth G] Focus chain WB [auth A] Focus chain YD [auth L] Focus chain YF [auth 1] Focus chain ZF [auth 1]
PQN (Subject of Investigation/LOI) Query on PQN Download Ideal Coordinates CCD File SDF format, chain HB [auth A] SDF format, chain ID [auth B] MOL2 format, chain HB [auth A] MOL2 format, chain ID [auth B]	HB [auth A], ID [auth B]	PHYLLOQUINONE C₃₁ H₄₆ O₂ MBWXNTAXLNYFJB-NKFFZRIASA-N		Interactions Focus chain HB [auth A] Focus chain ID [auth B] Interactions & Density Focus chain HB [auth A] Focus chain ID [auth B]
SF4 (Subject of Investigation/LOI) Query on SF4 Download Ideal Coordinates CCD File SDF format, chain QB [auth A] SDF format, chain TD [auth C] SDF format, chain UD [auth C] MOL2 format, chain QB [auth A] MOL2 format, chain TD [auth C] MOL2 format, chain UD [auth C]	QB [auth A], TD [auth C], UD [auth C]	IRON/SULFUR CLUSTER Fe₄ S₄ LJBDFODJNLIPKO-UHFFFAOYSA-N		Interactions Focus chain QB [auth A] Focus chain TD [auth C] Focus chain UD [auth C] Interactions & Density Focus chain QB [auth A] Focus chain TD [auth C] Focus chain UD [auth C]
