8BCJ | pdb_00008bcj

Crystal structure of short-chain dehydrogenase PA3128 from Pseudomonas aeruginosa PAO1 in complex with NADP+

PDB DOI: https://doi.org/10.2210/pdb8BCJ/pdb

Classification: UNKNOWN FUNCTION
Organism(s): Pseudomonas aeruginosa PAO1
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2022-10-16 Released: 2022-11-30
Deposition Author(s): Popp, M.A., Vit, A., Blankenfeldt, W.
Funding Organization(s): German Research Foundation (DFG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.15 Å
R-Value Free:
0.149 (Depositor), 0.150 (DCC)
R-Value Work:
0.135 (Depositor), 0.130 (DCC)
R-Value Observed:
0.136 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

The structure of short-chain dehydrogenase PA3128 from Pseudomonas aeruginosa PAO1

Popp, M.A., Vit, A., Blankenfeldt, W.

To be published.

Macromolecule Content

Total Structure Weight: 109.57 kDa
Atom Count: 10,023
Modeled Residue Count: 995
Deposited Residue Count: 1,000
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable short-chain dehydrogenase	A, B, C, D	250	Pseudomonas aeruginosa PAO1	Mutation(s): 0 Gene Names: PA3128
UniProt
Find proteins for Q9HZ96 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9HZ96 Go to UniProtKB: Q9HZ96
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9HZ96
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAP (Subject of Investigation/LOI) Query on NAP Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain I [auth B] SDF format, chain L [auth C] SDF format, chain O [auth D] MOL2 format, chain F [auth A] MOL2 format, chain I [auth B] MOL2 format, chain L [auth C] MOL2 format, chain O [auth D] mmCIF format, chain F [auth A] mmCIF format, chain I [auth B] mmCIF format, chain L [auth C] mmCIF format, chain O [auth D]	F [auth A], I [auth B], L [auth C], O [auth D]	NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C₂₁ H₂₈ N₇ O₁₇ P₃ XJLXINKUBYWONI-NNYOXOHSSA-N		Interactions Focus chain F [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain O [auth D] Interactions & Density Focus chain F [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain O [auth D]
TLA Query on TLA Download Ideal Coordinates CCD File SDF format, chain N [auth D] SDF format, chain K [auth C] SDF format, chain H [auth B] SDF format, chain E [auth A] MOL2 format, chain N [auth D] MOL2 format, chain K [auth C] MOL2 format, chain H [auth B] MOL2 format, chain E [auth A] mmCIF format, chain N [auth D] mmCIF format, chain K [auth C] mmCIF format, chain H [auth B] mmCIF format, chain E [auth A]	E [auth A], H [auth B], K [auth C], N [auth D]	L(+)-TARTARIC ACID C₄ H₆ O₆ FEWJPZIEWOKRBE-JCYAYHJZSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain K [auth C] Focus chain N [auth D] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain K [auth C] Focus chain N [auth D]
IMD Query on IMD Download Ideal Coordinates CCD File SDF format, chain M [auth C] SDF format, chain J [auth B] SDF format, chain G [auth A] MOL2 format, chain M [auth C] MOL2 format, chain J [auth B] MOL2 format, chain G [auth A] mmCIF format, chain M [auth C] mmCIF format, chain J [auth B] mmCIF format, chain G [auth A]	G [auth A], J [auth B], M [auth C]	IMIDAZOLE C₃ H₅ N₂ RAXXELZNTBOGNW-UHFFFAOYSA-O		Interactions Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Interactions & Density Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C]
