8ZJT | pdb_00008zjt

Structure of free nucleosome


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structural basis of nucleosome binding and destabilization by the extended DNA binding domain of RFX5.

Xue, W.Han, Y.Tian, Y.Wang, J.Xie, Z.Zheng, X.Yue, X.Dong, S.Li, H.Luo, Z.Zhang, S.Yang, Y.Zou, Z.Li, W.Ma, N.Zhu, F.Chen, C.Yin, Y.Zhang, Y.Xu, K.

(2025) Nucleic Acids Res 53

  • DOI: https://doi.org/10.1093/nar/gkaf734
  • Primary Citation of Related Structures:
    8ZJR, 8ZJT

  • PubMed Abstract:

    Among the regulatory factor X (RFX) transcription factor family, RFX5 is uniquely reported to bind nucleosomes and induce nucleosome remodeling in vivo. Dysfunctions in RFX5 have been implicated in various diseases. Here, we present the cryogenic electron microscopy (cryo-EM) structure of the RFX5-nucleosome complex, revealing that the extended DNA binding domain (eDBD) of RFX5 binds to the nucleosome at superhelical location +2. RFX5 eDBD engages not only with nucleosomal DNA but also with histones through extensive interactions. Compared to the structure of a free nucleosome, RFX5 eDBD induces localized distortion of the bound DNA gyre and detachment of the adjacent DNA gyre in the RFX5-nucleosome complex. This structural alteration could potentially increase DNA accessibility and enhance transcriptional activity in vivo. Overall, our study provides novel insights into the mechanisms by which RFX5 eDBD interacts with and destabilizes nucleosomes.


  • Organizational Affiliation
    • Shanghai Key Laboratory of Anesthesiology and Brain Functional Modulation, Clinical Research Center for Anesthesiology and Perioperative Medicine, Translational Research Institute of Brain and Brain-Like Intelligence, Shanghai Fourth People's Hospital, School of Medicine, Tongji University, Shanghai 200434, China.

Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H3.2
A, E
138Homo sapiensMutation(s): 0
Gene Names: H3C15HIST2H3AH3C14H3F2H3FMHIST2H3CH3C13HIST2H3D
UniProt & NIH Common Fund Data Resources
Find proteins for Q71DI3 (Homo sapiens)
Explore Q71DI3
Go to UniProtKB:  Q71DI3
PHAROS:  Q71DI3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ71DI3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H4
B, F
107Homo sapiensMutation(s): 0
Gene Names:
UniProt & NIH Common Fund Data Resources
Find proteins for P62805 (Homo sapiens)
Explore P62805
Go to UniProtKB:  P62805
PHAROS:  P62805
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62805
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2A type 1-B/E
C, G
132Homo sapiensMutation(s): 0
Gene Names: H2AC4H2AFMHIST1H2ABH2AC8H2AFAHIST1H2AE
UniProt & NIH Common Fund Data Resources
Find proteins for P04908 (Homo sapiens)
Explore P04908
Go to UniProtKB:  P04908
PHAROS:  P04908
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04908
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2B type 1-K
D, H
130Homo sapiensMutation(s): 0
Gene Names: H2BC12H2BFTHIRIP1HIST1H2BK
UniProt & NIH Common Fund Data Resources
Find proteins for O60814 (Homo sapiens)
Explore O60814
Go to UniProtKB:  O60814
PHAROS:  O60814
GTEx:  ENSG00000197903
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO60814
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains LengthOrganismImage
DNA (147-MER)147synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains LengthOrganismImage
DNA (147-MER)147synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China32301018

Revision History  (Full details and data files)

  • Version 1.0: 2025-08-13
    Type: Initial release
