8WX3 | pdb_00008wx3

Cryo-EM structure of human SLC15A4 (outward-facing open)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.83 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

The structures of the peptide transporters SLC15A3 and SLC15A4 reveal the recognition mechanisms for substrate and TASL.

Zhang, Z.Kasai, S.Sakaniwa, K.Fujimura, A.Ohto, U.Shimizu, T.

(2025) Structure 33: 330

  • DOI: https://doi.org/10.1016/j.str.2024.11.019
  • Primary Citation of Related Structures:
    8WX1, 8WX2, 8WX3, 8WX4, 8WX5

  • PubMed Abstract:

    The solute carrier family 15 members 3 and 4 (SLC15A3 and SLC15A4) are closely related endolysosomal peptide transporters that transport free histidine and certain dipeptides from the lumen to cytosol. Besides, SLC15A4 also functions as a scaffold protein for the recruitment of the adapter TASL for interferon regulatory factor 5 (IRF5) activation downstream of innate immune TLR7-9 signaling. However, the molecular basis for the substrate recognition and TASL recruitment by these membrane proteins is not well understood. Here, we report the cryoelectron microscopy (cryo-EM) structure of apo SLC15A3 and structures of SLC15A4 in the absence or presence of the substrate, revealing the specific dipeptide recognition mechanism. Each SLC15A3 and SLC15A4 protomer adopts an outward-facing conformation. Furthermore, we also present the cryo-EM structure of a SLC15A4-TASL complex. The N terminal region of TASL forms a helical structure that inserts deeply into the inward-facing cavity of SLC15A4.


  • Organizational Affiliation
    • Graduate School of Pharmaceutical Sciences, The University of Tokyo, 7-3-1 Hongo, Bunkyo-ku, Tokyo 113-0033, Japan.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Solute carrier family 15 member 4
A, B
600Homo sapiensMutation(s): 0
Gene Names: SLC15A4
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N697 (Homo sapiens)
Explore Q8N697
Go to UniProtKB:  Q8N697
PHAROS:  Q8N697
GTEx:  ENSG00000139370
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8N697
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.83 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2023-12-06
    Type: Initial release
  • Version 1.1: 2024-10-30
    Changes: Data collection, Structure summary
  • Version 1.2: 2025-06-18
    Changes: Data collection, Database references
  • Version 1.3: 2025-06-25
    Changes: Data collection, Database references
  • Version 1.4: 2025-07-02
    Changes: Data collection
