8UKE

Crystal Structure of Norbelladine O-methyltransferase variant in complex with SAH


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.189
  • R-Value Observed: 0.192

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Biosensor and machine learning-aided engineering of an amaryllidaceae enzyme.

d'Oelsnitz, S.Diaz, D.J.Kim, W.Acosta, D.J.Dangerfield, T.L.Schechter, M.W.Minus, M.B.Howard, J.R.Do, H.Loy, J.M.Alper, H.S.Zhang, Y.J.Ellington, A.D.

(2024) Nat Commun 15: 2084-2084

  • DOI: https://doi.org/10.1038/s41467-024-46356-y
  • Primary Citation of Related Structures:
    8UKE

  • PubMed Abstract:

    A major challenge to achieving industry-scale biomanufacturing of therapeutic alkaloids is the slow process of biocatalyst engineering. Amaryllidaceae alkaloids, such as the Alzheimer's medication galantamine, are complex plant secondary metabolites with recognized therapeutic value. Due to their difficult synthesis they are regularly sourced by extraction and purification from the low-yielding daffodil Narcissus pseudonarcissus. Here, we propose an efficient biosensor-machine learning technology stack for biocatalyst development, which we apply to engineer an Amaryllidaceae enzyme in Escherichia coli. Directed evolution is used to develop a highly sensitive (EC 50  = 20 μM) and specific biosensor for the key Amaryllidaceae alkaloid branchpoint 4'-O-methylnorbelladine. A structure-based residual neural network (MutComputeX) is subsequently developed and used to generate activity-enriched variants of a plant methyltransferase, which are rapidly screened with the biosensor. Functional enzyme variants are identified that yield a 60% improvement in product titer, 2-fold higher catalytic activity, and 3-fold lower off-product regioisomer formation. A solved crystal structure elucidates the mechanism behind key beneficial mutations.


  • Organizational Affiliation

    Department of Molecular Biosciences, University of Texas at Austin, Austin, TX, 78712, USA. simonsnitz@gmail.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Norbelladine 4'-O-methyltransferase
A, B, C, D, E
A, B, C, D, E, F
239Narcissus aff. pseudonarcissus MK-2014Mutation(s): 3
Gene Names: N4OMT
UniProt
Find proteins for A0A077EWA5 (Narcissus aff. pseudonarcissus MK-2014)
Explore A0A077EWA5
Go to UniProtKB:  A0A077EWA5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A077EWA5
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SAH (Subject of Investigation/LOI)
Query on SAH

Download Ideal Coordinates CCD File
G [auth A]
J [auth B]
M [auth C]
O [auth D]
Q [auth E]
G [auth A],
J [auth B],
M [auth C],
O [auth D],
Q [auth E],
T [auth F]
S-ADENOSYL-L-HOMOCYSTEINE
C14 H20 N6 O5 S
ZJUKTBDSGOFHSH-WFMPWKQPSA-N
CA (Subject of Investigation/LOI)
Query on CA

Download Ideal Coordinates CCD File
H [auth A]
I [auth A]
K [auth B]
L [auth B]
N [auth C]
H [auth A],
I [auth A],
K [auth B],
L [auth B],
N [auth C],
P [auth D],
R [auth E],
S [auth E],
U [auth F]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.189
  • R-Value Observed: 0.192
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 95.973α = 90
b = 79.581β = 105.62
c = 98.379γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data scaling
HKL-2000data reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35GM148356

Revision History  (Full details and data files)

  • Version 1.0: 2024-03-20
    Type: Initial release
